WARNING:
Improper installation, adjustment,
alteration, service or maintenance can cause
property damage, injury or death.
the installation, operating and maintenance
instructions thoroughly before installing or
servicing this equipment.
FOR YOUR SAFETY:
gasoline or other flammable vapors or liquids
in the vicinity of this or any other appliance.
VBG30
Read
Do not store or use
Retain this manual for future reference.
VERTICAL
BROILER
ELECTRIC: VBE30
Installation and
Instructions
2M-Z13927 Rev. C 12-2018
WARNING:
This appliance shall be installed
in accordance with current regulations and
used only in well-ventilated space. Refer to
instructions before installing and using this
appliance.
In addition, there should be posted, in a
prominent location, detailed instructions to
be followed in the event the operator smells
gas. Obtain the instructions from the local
gas supplier.
GAS: VBG30
Operation
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Star VBE30
Summary of Contents for Star VBE30
- Page 1 VERTICAL BROILER ELECTRIC: VBE30 GAS: VBG30 Installation and Operation Instructions 2M-Z13927 Rev. C 12-2018 VBG30 WARNING: WARNING: Improper installation, adjustment, This appliance shall be installed alteration, service or maintenance can cause in accordance with current regulations and property damage, injury or death.
-
Page 2: Safety Symbol
RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. -
Page 3: Specifications
Input Amps Plug Type (cm) (cm) (cm) Type Total Shipping Installed BTU’s 208V 21.6 NEMA 6-30P VBE30 16.08” 24.97” 32” 230V 18.2 240V 18.8 NEMA 6-30P NAT* VBG30 (40.79) (63.42) (81.28) 120V 30,000 NEMA 5-15P *Natural gas - 5" WC *Liquid propane - 10"... -
Page 4: General Installation Data
CAUTION The Star series gas vertical broiler is equipped for the type of gas indicated on the nameplate mounted on the unit. All gas units are shipped from the factory for use with natural gas. -
Page 5: Assembly And Installation
INSTALLATION INSTRUCTIONS UNCRATING AND INSPECTING Unpack the unit and components from the shipping container. Remove all visible packing material and those from inside the cooking chamber. If damage is discovered, file a claim immediately with the carrier that handled the shipment. Do not operate the unit if it was damaged during shipping. ASSEMBLY AND INSTALLATION The unit was shipped fully assembled and ready to plug into a standard outlet specified for its voltage and amp draw. If improper electrical supply is determined, contact a qualified electrician prior to using the unit. Removal and replacement of the power cord and plug will void the warranty. For assistance, contact your local authorized service agent for service or required maintenance. Place unit on a level surface. This broiler can be very hot during operation. Use care when carving the mead during use. Allow enough space around the unit for adequate ventilation. Read all labels on the unit and follow their instructions. -
Page 6: Gas Model
INSTALLATION INSTRUCTIONS continued GAS MODEL Check unit nameplate for correct gas supply to the appliance. Be sure to remove all paper protection and packing material from the unit prior to lighting. Provide adequate air supply and ventilation to the appliance. A manual shut-off valve (not supplied) should be installed upstream from the unit & within 6 ft of the appliance. -
Page 7: Burner Operation
INSTALLATION INSTRUCTIONS continued BURNER OPERATION Each burner is controlled by an individual high-low, on-off valve. A variety of broiling temperatures may be obtained by turning the burner valve knob to any position between ON and LO. It is possible through this arrangement to have a high heat or searing section, while having a low heat finishing or holding section. For the searing operation, turn the valve counter clockwise for the section to a position of “ON” or close to it. For holding or finishing, turn the valves closer to the “LO” position on the dial. You select the heat pattern you like, and set the valves accordingly. Be sure burners are staying fully lit when set in low positions. - Page 8 Star’s discretion or water connection. Star is not liable for any unit which has have the parts replaced or repaired by Star or a Star-authorized service been mishandled, abused, misapplied, subjected to chlorides, harsh agency.
- Page 9 ELEMENT ELECTRIC BROILER WIRING DIAGRAM FOR SUPPLY USE COPPER CONDUCTORS SWITCH RATED FOR 75°C. MINIMUM. TERMINAL SEE NAMEPLATE FOR VOLTAGE BLOCK SUPPLY WIRES SWITCH SWITCH FUSE- 3A. FUSE- 3A. ELEMENT PILOT LAMP MOTOR Z13920 TERMINAL BLOCK SWITCH POWER CORD 120V. PILOT LAMP VERTICAL BROILER-GAS...
- Page 10 Nameplate SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE This drawing contains information confidential to Star Manufacturing International, Inc. No reproduction or disclosure of it's contents is permitted. SK2523 Rev.- 6-28-2011 Model: VBE Vertical Broiler...
-
Page 11: Parts List
PARTS LIST February 27, 2014, Rev B VERTICAL ELECTRIC BROILER - VBE30 Fig No Part Number Description Application K8-Z13909 BACK PANEL 2R-Z9686 KNOB,DAVIES 2860AP 1/4-20 K8-VB0002 V.B. TOP ROD HOLDER BRKT K8-VB0012 V.B. MEAT SUPPRT PLATE 2V-VB0006 V.B. MEAT ROD ASSY. 2C-Z13914 HAIRPIN COTTER PIN... - Page 12 18 2 MODEL: VBG Gas Vertical Broiler SK2567, Rev. A 12/17/2014...
- Page 13 V.B. MEAT SUPPRT PLATE 2K-Z13933 PILOT TUBE, 1/4” 2K-70101-122 BRASS COUPLING 1/4” COMP 2A-Z0790 FITTING STRAIGHT 2K-Z13936 BURNER TUBE 3/8” 2A-Z13931 LP ORFICE LP ONLY 2M-Z13926 FRONT LABEL-GAS 2M-Z13922 WIRING DIAGRAM-GAS K8-VB0013 V.B. POWER CORD ASSY Star International Holding, Inc.
- Page 16 STAR MANUFACTURING INTERNATIONAL INC. Star - Holman - Lang - Wells - Toastmaster 265 HOBSON ST. SMITHVILLE, TN 37166 (800) 264-7827 www.star-mfg.com...
