Page 1: Quick Guide
Digital Recorder Quick Guide This Vicon Quick Guide is intended to get you up and running quickly. See the complete manual for in-depth information on the AurorAcorD. A World Leader in Digital Video Communications Systems... - Page 2 Otherwise, remove appropriate jumpers before using the AurorANet termination box as AurorANet Termination Box RS-232/RS-422 Termination Box discussed in the Reference chapter of Instruction Manual XX091. (part # 1298-3190-01-00) (part # 1298-3140-01-00) Vicon Industries Inc. 89 Arkay Drive, Hauppauge, NY 11788...
- Page 3 Terminate with 75 ohms at the destination devices. The Looping 1 connector provides outputs 1-8. Use the "A2K Video" labels for outputs 1-8. Do not refer to the "Video" label. For complete instructions, see Instruction Manual XX091. Visit our home page at: http://www.vicon-cctv.com...
-
Page 4: Operation
Operation There are three monitors for the AurorAcorD system, the spot monitor and two main display monitors. The spot monitor is used as a monitoring station and does not have the capability of multi-picture display. Use the main display monitors to take advantage of all AurorAcorD features. - Page 5 Quick Guide Operation Digital Pan, Tilt and Zoom Pan/Tilt Zoom In/Out When you are completely 1-16 Press a camera number Press once ZOOM zoomed out on a scene, RECORD key to select a camera in to enter digital – press to exit digital ZOOM ZOOM...
-
Page 6: Telemetry Control
Quick Guide Operation Telemetry Control Note: To access the telemetry features, press as described below. MECH P/T ZOOM • Press and hold for 5 Press to activate seconds to access pan/tilt auxiliary receiver Press to toggle speed settings table. devices. Press through Use to pan Use to tilt up... -
Page 7: Defining Macros
ENTER P/T ZOOM IRIS AurorAcorD Digital Recorder Front Panel Note: The instructions for choosing a setting are on the bottom of each menu. Because of space constraints, they are not repeated in the programming procedures in this quick guide. Configuring Multi-Picture Display Formats... -
Page 8: Enabling Motion Detection
Loopback Mode. you can set record quality. Selecting the Playback Source Select hard drive, CD- MENU RW or floppy disk. AUX2 AUX6 AUX2 AUX3 For complete instructions, see Instruction Manual XX091. Visit our home page at: http://www.vicon-cctv.com... - Page 9 Lowest (9 Kb) The second table shows the estimated number of days that the AurorAcorD can be expected to record before hard drives of various (12 Kb) sizes are filled. "Max" frame rate changes from 18 fps to 24 fps, Normal depending upon the synchronization of all cameras in the system.
-
Page 10: Frequently Asked Questions
Enter Menu/Setup Password screen, Front Panel Password or Menu/Setup Password. The help system will display an encrypted version of your Menu/Setup password. Call Vicon Technical Support at 1-800-34-VICON (1-800-348-4266) and give them the encrypted password so that they can determine the password for you. - Page 11 Yes, it can be controlled from up to 16 combined System Consoles or A2K-KBD Keypads. It is necessary to use the current model of the System Console (V1400X-DVC-3), which has the ability to control up to 16 AurorAcorDs. Each AurorAcorD uses one device address and one VCR address.
