2. Product Features and Specifications

Temperature:

Operating Range: 4.4°C (40°F) to 37.8°C (100°F)

Humidity:

Operating range: 0-95% relative humidity, non-condensing

Audible Alarm:

85+ dB at 10' @ 3.2±0.5 KHz pulsing alarm, with voice messages "Fire!
Feu!" NOTE: This is not a CO alarm, but it will receive and transmit a CO
alarm signal (with voice message "Warning! Carbon Monoxide. Monoxide
de carbone!") from an interconnected CO or combination smoke/CO alarm.

Sensor:

Photoelectric
Mounting:
Wall or ceiling
Applications:
Primary Direct or Indirect and Supplementary
Light Output:
177 Candela minimum (on axis measurement)
The following diagrams show that the light intensity gradually decreases
as the viewing angle is increased. Use this information to determine the
best location for the strobe light.
90° 90°
45° 45°
90°
LIGHT LIGHT
SOURCE SOURCE
CEILING CEILING
90° 90°
45° 45°
0° 0°
ZERO AXIS
60 55 50
PERCENT PERCENT
(LIGHT INTENSITY) (LIGHT INTENSITY)
100 100
90 90
75 75
55 55
45 45
40 40
35 35
35 35
30 30
30 30
25 25
25 25
45 40 35
FLOOR
ANGLE ANGLE
(IN DEGREES) (IN DEGREES)
0 0
5-25 5-25
30-45 30-45
50 50
55 55
60 60
65 65
70 70
75 75
80 80
85 85
90 90
0
5
10
15
20
25
30
