Double pole isolating switch:
pull cord or wall mounted in accordance
with IEE regulations
Consumer unit
Figure 4
Figure 5 - Rear cable entry
8
RCD (can be part of the
consumer unit)
PowerPack unit
(use rear entry when it is
possible)
80A or 100A main switch
Meter 'tails'
Meter
Make cut-out
using sharp knife
