Supero X9DR7-LN4F User Manual

Hide thumbs Also See for X9DR7-LN4F:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
X9DR7-LN4F
X9DR7-JLN4F
X9DRE-LN4F
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X9DR7-LN4F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supero X9DR7-LN4F

Summary of Contents for Supero X9DR7-LN4F

  • Page 1 X9DR7-LN4F X9DR7-JLN4F X9DRE-LN4F USER’S MANUAL Revision 1.0...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Motherboard

    This manual is written for system integrators, PC technicians and knowledgeable PC users. It provides information for the installation and use of the X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F motherboard. About This Motherboard The Super X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F motherboard supports dual Intel E5-2600 Series Processors (Socket R) that offer QPI (Intel QuickPath ®...

  • Page 4: Conventions Used In The Manual

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Conventions Used in the Manual Pay special attention to the following symbols for proper system installation and to prevent damage to the system or injury to yourself: Danger/Caution: Instructions to be strictly followed to prevent catastrophic...

  • Page 5: Contacting Supermicro

    Preface Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...

  • Page 6: Table Of Contents

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Table of Contents Preface Chapter 1 Overview Overview ......................1-1 Processor and Chipset Overview..............1-11 Special Features ................... 1-12 PC Health Monitoring ..................1-12 ACPI Features ....................1-13 Power Supply ....................1-13 Advanced Power Management ..............1-14 Intel Intelligent Power Node Manager (IPNM) ..........
  • Page 7 IPMI Dedicated LAN LEDs ............... 2-34 Onboard Power LED ................2-35 BMC Heartbeat LED ................2-35 Serial ATA Connections ................. 2-36 Serial ATA Ports..................2-36 SAS Ports (X9DR7-LN4F Only) ............... 2-36 Chapter 3 Troubleshooting Troubleshooting Procedures ................3-1 Before Power On .................... 3-1...
  • Page 8 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual No Power ......................3-1 No Video ......................3-2 System Boot Failure ..................3-2 Losing the System’s Setup Configuration ............3-2 Memory Errors ....................3-3 When the System Becomes Unstable ............3-3 Technical Support Procedures ................ 3-5 Battery Removal and Installation ..............

  • Page 9: Chapter 1 Overview

    Two (2) Serial ATA cables (CBL-0044Lx2) (X9DR7-LN4F/JLN4F Only) • Six (6) Serial ATA cables (CBL-0044Lx6) (X9DRE-LN4F Only) • Two (2) I-Pass to Serial ATA cables (CBL-097L-03 x2) (X9DR7-LN4F/JLN4F Only) • One (1) I/O Shield (MCP-260-00042-0N) Note: For your system to work properly, please follow the links below to download all necessary drivers/utilities and the user's manual for your motherboard.
  • Page 10 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Motherboard Image Note: All graphics shown in this manual were based upon the latest PCB Revision available at the time of publishing of the manual. The motherboard you've received may or may not look exactly the same as the graphics...

  • Page 11: Motherboard Layout

    Chapter 1: Overview Motherboard Layout COM1 USB2&3 USB0&1 CTRL CTRL KB/Mouse IPMI_LAN LAN2/4 LAN1/3 CPU2 X9DR7/E-LN4F Rev. 1.00 T-SGPIO1 BIOS CPU1 JBT1 Battery JPW2 JBAT1 CTRL L-SAS 4~7 L-SAS 0~3 FAN2 FAN3 Note: For the latest CPU/Memory updates, please refer to our Website at http://www.supermicro.com/products/motherboard/ for details.
  • Page 12 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual COM1 USB2&3 USB0&1 CTRL CTRL KB/Mouse IPMI_LAN LAN2/4 LAN1/3 CPU2 X9DR7/E-LN4F Rev. 1.00 T-SGPIO1 BIOS CPU1 JBT1 Battery JPW2 JBAT1 CTRL L-SAS 4~7 L-SAS 0~3 FAN2 FAN3 Notes: • See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front panel connections.
  • Page 13 (S-)SATA 0-3 Intel SCU SATA Connectors 0-3 (L)SAS SAS Connections 0-3, 4-7 supported by LSI SAS Con- troller (for X9DR7-LN4F) Onboard Buzzer (Internal Speaker) SCU-SGPIO 1 SCU-SGPIO (Serial_Link General Purpose I/O) Header 1 to support S-SATA 0-3 from Intel SCU...
  • Page 14 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual T-SGPIO 1/2 T-SGPIO (Serial_Link General Purpose I/O) Headers 1/2 to support I-SATA 0-5 (CPU2)Slots 3/5 CPU2 Slot3/Slot5 PCI-Exp. 3.0 x16 Slots (CPU1)Slots1/2/6 CPU1 Slot1/Slot2/Slot6 PCI-Exp. 3.0 x8 Slots (Available when CPU1 is installed) (CPU2)Slot4 PCI-Exp. 3.0 x8 Slots (Available when CPU2 is installed)

  • Page 15: Motherboard Features

    (I-SATA 2-5) Ports, Four (4) SATA 2.0 from Intel SCU (S-SATA0-3) Eight (8) SAS Connections sup- ported by the LSI 2308 SAS controller (for X9DR7-LN4F) Eight (8) SAS 2.0 (IT Mode) Connections supported by the LSI 2308 SAS 2.0 controller (for X9DR7-JLN4F) •...

  • Page 16: Peripheral Devices

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Integrated IPMI 2.0 • IPMI 2.0 supported by the WPCM450R BMC Serial (COM) Port • Two (2) Fast UART 16550 Connection: 9-pin RS- 232 port Super I/O • Winbond Super I/O 83527 (Optional) Peripheral USB Devices Devices •...
  • Page 17 Chapter 1: Overview • Low noise fan speed control • System PECI (Platform Environment Configuration Interface) Management 2.0 support • System resource alert via SuperDoctor III • SuperDoctor III, Watch Dog, NMI • Chassis Intrusion Header and Detection • Dimensions 12.00"...

  • Page 18: System Block Diagram

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual #H-2 #H-1 #G-2 #G-1 #D-2 #F-2 #D-1 #F-1 #C-2 (CPU2) #E-2 #C-1 E5-2600 (CPU1) E5-2600 8 SNB CORE 8 SNB CORE #E-1 #B-2 DDR3 DDR3 #B-1 #A-2 #A-1 #2A #1 #3C DMI2 DMI2 PCI-E X16 G3...

  • Page 19: Processor And Chipset Overview

    Built upon the functionality and the capability of Intel E5-2600 Series Proces- ® sor (Socket R) and the PCH C602 chipset, the X9DR7-LN4F/X9DR7-JLN4F/ X9DRE-LN4F motherboard provides the performance and feature sets required for dual_processor-based high-end servers. With support of Intel QuickPath interconnect (QPI) Technology, the X9DR7-LN4F/ X9DR7-JLN4F/X9DRE-LN4F offers point-to-point serial interconnect interface with a transfer speed of up to 8.0 GT/s, providing superb system performance.

  • Page 20: Special Features

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Special Features Recovery from AC Power Loss The Basic I/O System (BIOS) provides a setting that determines how the system will respond when AC power is lost and then restored to the system. You can choose for the system to remain powered off (in which case you must press the power switch to turn it back on), or for it to automatically return to the power-on state.

  • Page 21: Acpi Features

    It is even more important for processors that have high CPU clock rates. The X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F motherboard accommodates 24- pin ATX power supplies. Although most power supplies generally meet the specifica- tions required by the CPU, some are inadequate. In addition, two 12V 8-pin power connections are also required to ensure adequate power supply to the system.

  • Page 22: Advanced Power Management

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual It is strongly recommended that you use a high quality power supply that meets ATX power supply Specification 2.02 or above. It must also be SSI compliant. (For more information, please refer to the Website at http://www.ssiforum.org/). Additionally, in areas where noisy power transmission is present, you may choose to install a line filter to shield the computer from noise.

  • Page 23: Other Features Supported By The Wpcm Bmc Controller

    Chapter 1: Overview The WPCM450R Controller interfaces with the host system via PCI connections to communicate with the graphics cores. It supports USB 2.0 and 1.1 for remote keyboard/mouse/virtual media emulation. It also provides LPC interface support to control Super IO functions. The WPCM450R Controller is connected to the network via an external Ethernet PHY module or shared NCSI connections.
  • Page 24 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual • Supports the following Management tools: IPMIView, CLI (Command Line Interface) • RMCP+ protocol supported Note 1: For more information on IPMI configuration, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com/ support/manuals/.

  • Page 25: Chapter 2 Installation

    Chapter 2: Installation Chapter 2 Installation Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam- aging your system board, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. Precautions •...

  • Page 26: Processor And Heatsink Installation

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Processor and Heatsink Installation Warning: When handling the processor package, avoid placing direct pressure on the label area. Refer to our website for CPU updates/support. Notes: 1. Always connect the power cord last, and always remove it before adding, removing or changing any hardware components.
  • Page 27 Chapter 2: Installation 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Pull lever away from Press down on 0the Load the socket Lever labeled 'Close 1st' 3.
  • Page 28 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual 1. Use your index finger and your thumb to loosen the lever and open the load plate. Align Pin1 of the CPU with Pin 1 of the CPU Socket. 2. Once they are aligned, carefully lower the CPU straight down into the socket.
  • Page 29 Chapter 2: Installation 4. Close the load plate with the CPU inside the socket. Lock the lever labeled 'Close 1st' first, then lock the lever labeled 'Open 1st' second. Use your thumb to gently push the load levers down to the lever locks. Push down and lock the Gently close level labeled 'Close 1st'.

  • Page 30: Installing A Passive Cpu Heatsink

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket under- neath.

  • Page 31: Removing The Heatsink

    Chapter 2: Installation Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instruc- tions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket.

  • Page 32: Installing And Removing The Memory Modules

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Installing and Removing the Memory Modules Note: Check Supermicro's Website for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing & Removing DIMMs 1. Insert the desired number of DIMMs into the memory slots, starting with P1- DIMM #A1.
  • Page 33 Chapter 2: Installation Memory Support for the X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard The X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F motherboard supports up to 512 GB of Registered (RDIMM)/Load Reduced (LRDIMM) ECC or Unbuffered (UDIMM) ECC/Non-ECC DDR3 800/1066/1333/1600 MHz of 240-pin 4-channel memory in 16 DIMM modules. For the latest memory updates, please refer to our Website a at http://www.supermicro.com/products/motherboard.
  • Page 34 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Populating UDIMM (ECC/Non-ECC) Memory Modules Intel E5-2600 Series Processor UDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage Validated by Slot per Channel DIMM & Per DIMM (SPC) and DIMM Per Channel (DPC) Data Width...
  • Page 35 Chapter 2: Installation Populating LRDIMM (ECC) Memory Modules Intel E5-2600 Series Processor LRDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage Validated DIMM & Data Per DIMM by Slot per Channel (SPC) and Width DIMM Per Channel (DPC) 1 Slot Per 2 Slots Per (See the Note...

  • Page 36: Motherboard Installation

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Motherboard Installation All motherboards have standard mounting holes to fit different types of chassis. Make sure that the locations of all the mounting holes for both motherboard and chassis match. Although a chassis may have both plastic and metal mounting fas- teners, metal ones are highly recommended because they ground the motherboard to the chassis.

  • Page 37: Installing The Motherboard

    Chapter 2: Installation Installing the Motherboard 1. Install the I/O shield into the chassis. 2. Locate the mounting holes on the motherboard. 3. Locate the matching mounting holes on the chassis. Align the mounting holes on the motherboard against the mounting holes on the chassis. 4.

  • Page 38: Control Panel Connectors And I/O Ports

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Control Panel Connectors and I/O Ports The I/O ports are color coded in conformance with the PC 99 specification. See the picture below for the colors and locations of the various I/O ports. Back Panel Connectors and I/O Ports X9DR7/E-LN4F Rev.

  • Page 39: Serial Ports

    Chapter 2: Installation Serial Ports Serial (COM) Ports Pin Definitions Two COM connections (COM1 & Pin # Definition Pin # Definition COM2) are located on the mother- board. COM1 is located on the Back- plane I/O panel. COM2, located close to PCI-E Slot1, provides front access support.

  • Page 40: Universal Serial Bus (Usb)

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Universal Serial Bus (USB) FP USB (4/5, USB 9) Backplane Pin Definitions USB (0/1, 2/3) Four Universal Serial Bus ports (USB Pin Definitions USB 4, 6 USB 5 0/1, USB 2/3) are located on the I/O Pin # Definition...

  • Page 41: Ethernet Ports

    Chapter 2: Installation Ethernet Ports LAN Ports Pin Definition Four Gigabit Ethernet ports (LAN1/ Pin# Definition LAN3, LAN2/LAN4) are located on the P2V5SB SGND I/O backplane on the motherboard. In TD0+ Act LED addition, an IPMI_Dedicated LAN is TD0- P3V3SB located above USB 0/1 ports on the TD1+ Link 100 LED (Yel- backplane to provide KVM support...

  • Page 42: Front Control Panel

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Front Control Panel JF1 contains header pins for various buttons and indicators that are normally lo- cated on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro's server chassis. See the figure below for the descriptions of the various control panel buttons and LED indicators.

  • Page 43: Front Control Panel Pin Definitions

    Chapter 2: Installation Front Control Panel Pin Definitions NMI Button NMI Button Pin Definitions (JF1) The non-maskable interrupt button Pin# Definition header is located on pins 19 and 20 Control of JF1. Refer to the table on the right Ground for pin definitions. Power LED Power LED Pin Definitions (JF1) The Power LED connection is located Pin#...

  • Page 44: Hdd Led

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual HDD LED HDD LED Pin Definitions (JF1) The HDD LED connection is located Pin# Definition on pins 13 and 14 of JF1. Attach a 3.3V Standby cable here to indicate HDD activ- HD Active ity. See the table on the right for pin definitions.

  • Page 45: Overheat (Oh)/Fan Fail Led

    Chapter 2: Installation Overheat (OH)/Fan Fail LED OH/Fan Fail LED Pin Definitions (JF1) Connect an LED cable to pins 7 and Pin# Definition 8 of Front Control Panel to use the Overheat/Fan Fail LED connections. OH/Fan Fail LED The LED on pin 8 provides warnings of overheat or fan failure.

  • Page 46: Reset Button

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Reset Button Reset Button Pin Definitions (JF1) The Reset Button connection is located Pin# Definition on pins 3 and 4 of JF1. Attach it to a Reset hardware reset switch on the computer Ground case. Refer to the table on the right for pin definitions.

  • Page 47: Connecting Cables

    Chapter 2: Installation Connecting Cables ATX Power 24-pin Connector Pin Definitions Pin# Definition Pin # Definition Power Connectors +3.3V +3.3V -12V +3.3V A 24-pin main power supply connector(J22) and two 8-pin CPU PWR connectors PS_ON (JPWR1/2,) are located on the mother- board.

  • Page 48: Fan Headers

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Fan Headers Fan Header Pin Definitions This motherboard has eight system/CPU Pin# Definition fan headers (Fan 1-Fan 6, Fan A, Fan B) Ground on the motherboard. All these 4-pin fans +12V headers are backward compatible with Tachometer the traditional 3-pin fans.

  • Page 49: Internal Speaker

    Chapter 2: Installation Internal Speaker Internal Buzzer (SP1) Pin Definition The Internal Speaker, located at SP1, Pin# Definitions can be used to provide audible indica- Pin 1 Pos. (+) Beep In tions for various beep codes. See the Pin 2 Neg. (-) Alarm table on the right for pin definitions.

  • Page 50: Overheat Led/Fan Fail

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual TPM Header/Port 80 TPM/Port 80 Header Pin Definitions A Trusted Platform Module/Port 80 Pin # Definition Pin # Definition header is located at JTPM1 to provide LCLK TPM support and Port 80 connection. LFRAME# <(KEY)> Use this header to enhance system...

  • Page 51: Power Smb

    Chapter 2: Installation Power SMB (I C) Connector PWR SMB Pin Definitions Power System Management Bus (I Pin# Definition Connector (JPI C1) monitors power Clock supply, fan and system temperatures. Data See the table on the right for pin PWR Fail definitions.

  • Page 52: T-Sgpio 1/2 And Scu-Sgpio 1 Headers

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual T-SGPIO 1/2 and SCU-SGPIO 1 T-SGPIO/SCU-SGPIO Headers Pin Definitions Pin# Definition Definition Two SGPIO (Serial-Link General Pur- pose Input/Output) headers, located at T-SGPIO 1/2, support I-SATA 0-5. Ground Data Additionally, SCU-SGPIO 1 provides Load Ground support to S-SATA 0-3 from Intel Clock SCU chip.

  • Page 53: Standby Power Connector

    Chapter 2: Installation Standby Power Connector Standby PWR Pin Definitions A header for the standby power con- Pin# Definition nector is located at JSTBY1. Connect an appropriate cable here to provide Ground power support for your PCI-Exp. Ground devices. LAN3/LAN4 LED Connection LAN3/LAN4 LED Pin Definitions A 4-pin header (JF2), located next to...

  • Page 54: Jumper Settings

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Jumper Settings Explanation of Jumpers Connector Pins To modify the operation of the mother- board, jumpers can be used to choose between optional settings. Jumpers create Jumper shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.

  • Page 55: Cmos Clear

    Chapter 2: Installation CMOS Clear JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such as a small screwdriver to touch both pads at the same time to short the connection. Always remove the AC power cord from the system before clearing CMOS.

  • Page 56: Vga Enable

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual VGA Enable VGA Enable Jumper Settings Jumper JPG1 allows the user to enable Jumper Setting Definition the onboard VGA connector. The default Enabled (Default) setting is 1-2 to enable the connection. Disabled See the table on the right for jumper settings.

  • Page 57: I 2 C Bus To Pci-Exp. Slots

    Chapter 2: Installation C Bus to PCI-Exp. Slots C to PCI-E slots Jumper Settings Use Jumpers JI C1 and JI C2 to connect Jumper Setting Definition the System Management Bus (I C) to Pins 1-2 Enabled (Default) PCI-Express slots to improve PCI slot Pins 2-3 Disabled performance.

  • Page 58: Onboard Led Indicators

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Onboard LED Indicators GLAN LEDs Link Speed LED Activity LED There are four GLAN ports on the moth- erboard. Each Ethernet LAN port has Rear View (when facing the two LEDs. The Yellow LED on the right rear side of the chassis) indicates connection and activity.

  • Page 59: Onboard Power Led

    Chapter 2: Installation Onboard Power LED Onboard PWR LED Indicator (LE1) LED Settings An Onboard Power LED is located at LE1 Color/State Definition on the motherboard. When this LED is on, System Off (PWR cable not the system is on. Be sure to turn off the connected) system and unplug the power cord before Green...

  • Page 60: Serial Ata Connections

    SAS Ports (X9DR7-LN4F Only) Eight SAS Ports (SCU 0-3, 4-7) are located on the X9DR7-LN4F to provide Serial _Attached SCSI connections. These ports are supported by the LSI 2308 SAS controller. See the table on the right for pin definitions.

  • Page 61: Chapter 3 Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.

  • Page 62: No Video

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual No Video 1. If the power is on, but you have no video, remove all the add-on cards and cables. 2. Use the speaker to determine if any beep codes exist. Refer to Appendix A for details on beep codes.

  • Page 63: Memory Errors

    Chapter 3: Troubleshooting Memory Errors When a No-Memory Beep Code is issued by the system, check the following: 1. Make sure that the memory modules are compatible with the system and that the DIMM modules are properly and fully installed. (For memory compatibility, refer to the Memory Compatibility Chart posted on our Website @ http://www.
  • Page 64 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual 4. System cooling: Check system cooling to make sure that all heatsink fans, and CPU/system fans, etc., work properly. Check Hardware Monitoring set- tings in the BIOS to make sure that the CPU and System temperatures are within the normal range.

  • Page 65: Technical Support Procedures

    Chapter 3: Troubleshooting Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, please note that as a motherboard manufacturer, Supermicro also sells motherboards through its channels, so it is best to first check with your distributor or reseller for troubleshooting services.

  • Page 66: Battery Removal And Installation

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Battery Removal and Installation Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock out- wards to unlock it.

  • Page 67: Frequently Asked Questions

    Chapter 3: Troubleshooting Frequently Asked Questions Question: What are the various types of memory that my motherboard can support? Answer: The motherboard supports Registered/Load Reduced ECC or Unbuffered ECC/Non-ECC DDR3 DIMM modules. To enhance memory performance, do not mix memory modules of different speeds and sizes. Please follow all memory installation instructions given on Section 2-3 in Chapter 2.

  • Page 68: Returning Merchandise For Service

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required before any warranty service will be rendered. You can obtain service by calling your ven- dor for a Returned Merchandise Authorization (RMA) number. When returning the...

  • Page 69: Chapter 4 Bios

    BIOS Introduction This chapter describes the AMI BIOS Setup utility for the X9DR7-LN4F/X9DR7- JLN4F/X9DRE-LN4F. It also provides the instructions on how to navigate the AMI BIOS Setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated.

  • Page 70: Main Setup

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual How To Change the Configuration Data The configuration data that determines the system parameters may be changed by entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing <Delete> at the appropriate time during system boot. Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Re- covery User Guide posted @http://www.supermicro.com/support/manuals/.
  • Page 71 Chapter 4: AMI BIOS The AMI BIOS Main menu displays the following information: System Date/System Time Use this option to change the system time and date. Highlight System Time or System Date using the arrow keys. Enter new values through the keyboard and press <Enter>.

  • Page 72: 4-3 Advanced Setup Configurations

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual 4-3 Advanced Setup Configurations Select the Advanced tab to access the following submenu items. Boot Features Quiet Boot This feature allows the user to select bootup screen display between POST mes- sages and the OEM logo. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages.
  • Page 73 Chapter 4: AMI BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 74 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual • CPU Stepping • Maximum CPU Speed • Minimum CPU Speed • Processor Cores • Intel HT (Hyper-Threading) Technology • Intel VT-x Technology • Intel SMX Technology • L1 Data Cache • L1 Code Cache •...
  • Page 75 Chapter 4: AMI BIOS Active Processor Cores Set to Enabled to use a processor's second core and above. (Please refer to Intel's website for more information.) The options are All, 1, 2, 4 and 6. Limit CPUID Maximum This feature allows the user to set the maximum CPU ID value. Enable this function to boot the legacy operating systems that cannot support processors with extended CPUID functions.
  • Page 76 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent parti- tions, creating multiple "virtual" systems in one physical computer. The options are Enabled and Disabled.
  • Page 77 Chapter 4: AMI BIOS CPU C6 Report (Available when Power Technology is set to Custom) Select Enabled to allow the BIOS to report the CPU C6 State (ACPI C3) to the operating system. During the CPU C6 State, the power to all cache is turned off.

  • Page 78: North Bridge

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Short Duration Power Limit During Turbo Mode, the system may exceed the processors default power setting and exceed the Short Duration Power limit. By increasing this value, the proces- sor can provide better performance for short duration. This item displays the time period during which short duration power is maintained.
  • Page 79 Chapter 4: AMI BIOS CPU1 Slot 1 PCI-E 3.0 x8 OPROM This feature allows the user to set the PCI-Exp bus speed for the slot specified above. The options are Gen1 (Generation 1), Gen2 and Gen3. CPU1 Slot 2 PCI-E 3.0 x8 OPROM This feature allows the user to set the PCI-Exp bus speed for the slot specified above.
  • Page 80 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual QPI Link Frequency Select Use this feature to select the desired QPI frequency. The options are Auto, 6.4 GT/s, 7.2 GT/s, and 8.0 GT/s. DIMM Configuration This section displays the following DIMM information. Current Memory Mode This item displays the current memory mode.
  • Page 81 Chapter 4: AMI BIOS DDR Speed Use this feature to force a DDR3 memory module to run at a frequency other than what is specified in the specification. The options are Auto, Force DDR3- 800, Force DDR3-1066, Force DDR3-1333, Force DDR3-1600 and Force SPD. Channel Interleaving This feature selects from the different channel interleaving methods.
  • Page 82 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual South Bridge Configuration This feature allows the user to configure the settings for the Intel PCH chip. PCH Information This feature displays the following PCH information. Name: This item displays the name of the PCH chip. Stepping: This item displays the status of the PCH stepping.
  • Page 83 Chapter 4: AMI BIOS SATA Mode Use this feature to configure SATA mode for a selected SATA port. The options are Disabled, IDE Mode, AHCI Mode and RAID Mode. The following are displayed depending on your selection: IDE Mode The following items are displayed when IDE Mode is selected: Serial-ATA (SATA) Controller 0-1 Use this feature to activate or deactivate the SATA controller, and set the compatibility mode.
  • Page 84 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual PCIe/PCI/PnP Configuration PCI ROM Priority Use this feature to select the Option ROM to boot the system when there are mul- tiple Option ROMs available in the system. The options are EFI Compatible ROM and Legacy ROM.
  • Page 85 Chapter 4: AMI BIOS CPU1 Slot 1 PCI-E 3.0 x8 OPROM, CPU1 Slot 2 PCI-E 3.0 x8 OPROM, CPU2 Slot 3 PCI-E 3.0 x16 OPROM, CPU1 Slot 4 PCI-E 3.0 x8 OPROM, CPU2 Slot 5 PCI-E 3.0 x16 OPROM, CPU2 Slot 6 PCI-E 3.0 x 8 OPROM Select Enabled to enable Option ROM support to boot the computer using a network interface from the slots specified above.

  • Page 86: Serial Port Console Redirection

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Device Settings This item displays the settings of Serial Port 1. Change Settings Use this feature to set the optimal Platform Environment Control Interface (PECI) setting for a serial port specified. The default setting is Auto, which will allow the AMI BIOS to automatically select the best PECI setting.

  • Page 87: Console Redirection Settings

    Chapter 4: AMI BIOS Console Redirection Select Enabled to use a COM Port selected by the user for Console Redirection. The options are Enabled and Disabled. The default setting for COM1 is Disabled, and for COM2 is Enabled. Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user.
  • Page 88 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Flow Control This feature allows the user to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop send- ing data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty.

  • Page 89: Acpi Settings

    Chapter 4: AMI BIOS Out-of-Band Management Port The feature selects a serial port used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote server. The options are COM1 and COM2. Terminal Type This feature allows the user to select the target terminal emulation type for Con- sole Redirection.
  • Page 90 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual NUMA (NON-Uniform Memory Access) This feature enables the Non-Uniform Memory Access ACPI support. The options are Enabled and Disabled. High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does...
  • Page 91 Chapter 4: AMI BIOS TPM Owner Status This item displays the status of TPM Ownership. Intel TXT (LT-SX) Configuration Intel TXT (LT-SX) Hardware Support This feature indicates if the following hardware components support the Intel Trusted Execution Technology. CPU: TXT (Trusted Execution Technology) Feature Chipset: TXT (Trusted Execution Technology) Feature Intel TXT (LT-SX) Configuration This feature displays the following TXT configuration setting.
  • Page 92 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual • Add an Attempt • Delete Attempts • Commit/Discard Changes and Exit • Change Attempt Order • Commit/Discard Changes and Exit Intel® Ethernet Controller 10 Gigabit: These items display the following information on the Intel 10 Gigabit X connections.

  • Page 93: Event Logs

    Chapter 4: AMI BIOS Event Logs Select the Event Logs tab to access the following submenu items. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 94 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes, Next reset, and Yes, Every reset.

  • Page 95: Ipmi

    Chapter 4: AMI BIOS IPMI Select the IPMI (Intelligent Platform Management Interface) tab to access the fol- lowing submenu items. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system. System Event Log ...
  • Page 96 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately.

  • Page 97: Boot

    Chapter 4: AMI BIOS Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). Boot This submenu allows the user to configure the following boot settings for the system.

  • Page 98: Security

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Security This menu allows the user to configure the following security settings for the system. Password Check Use this feature to determine when a password entry is required. Select Setup to require the password only when entering setup. Select Always to require the pass- word when entering setup and on each boot.

  • Page 99: Save & Exit

    Chapter 4: AMI BIOS Save & Exit This submenu allows the user to configure the Save and Exit settings for the system. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit, and press <Enter>.
  • Page 100 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previ- ous values, select Yes to load the values previous saved, or select No to keep the changes you've made so far.

  • Page 101: Appendix A Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 102 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Notes...

  • Page 103: Appendix B Software Installation Instructions

    Appendix B: Software Installation Instructions Appendix B Software Installation Instructions B-1 Installing Software Programs After you've installed the operating system, a screen as shown below will appear. You are ready to install software programs and drivers that have not yet been in- stalled.

  • Page 104: Configuring Superdoctor Iii

    X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual B-2 Configuring SuperDoctor III The SuperDoctor III program is a Web-based management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called the SD III Client. The SuperDoctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 105 Appendix B: Software Installation Instructions SuperDoctor III Interface Display Screen-II (Remote Control) Note: The SD III utility and user guide can be downloaded from our website at: http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we will still recommend that you use Supero Doctor II.
  • Page 106 X9DR7-LN4F/X9DR7-JLN4F/X9DRE-LN4F Motherboard User’s Manual Notes...
  • Page 107 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

This manual is also suitable for:

X9dre-ln4fX9dr7-jln4f

Table of Contents
