Summary of Contents for Lamona LAM3301
-
Page 1: Electric Oven
Built in Fan Assisted LAM3301 Electric Oven User & Installation Guide... - Page 2 LAMONA Appliances Dear Customer, Congratulations on your choice of oven which has been designed to give you excellent service. The user manual will help you use your product quickly and safely. Please read this user manual before installing and using the oven.
-
Page 3: Table Of Contents
User manual LAM3301 Index 01 - Before using the oven 07 - Cooking and baking advice 02 - Safety 08 - Cooking tables Important instructions Oven cooking table General Grill cooking table Safety for children Safety when working with electricity... - Page 4 User manual LAM3301 Index _ 04...
-
Page 5: Safety
User manual LAM3301 Important instructions and warnings for safety and environment This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capa-bilities or lack of experience and knowledge if they have been given supervision or instruction concern-ing use of the appliance in a safe way and understand the hazards involved. -
Page 6: Before Using The Oven
LAMONA Appliances Before using the Oven Make sure that you have removed all packaging, wrappings, stickers and from the oven’s surface. It is recommended that you clean and wash the oven’s surface before using for the time. Never use the product when your judgment or... -
Page 7: Safety For Children
User manual LAM3301 and components inside the oven which maybe Product must be installed by a person hot. Always allow time for the oven in accordance with the regulations in force. to cool. Otherwise, the guarantee may become void. Do not allow the oven to cool with the door Safety for children open. -
Page 8: General Information
LAMONA Appliances 03 - General Information Oven layout Control panel Grill heating element Handle Light Oven Door Oven shelf positions Control panel layout oven/ grill function knob oven / grill temperature indicator Main oven temperature indicator Accessories Oven tray / grill pan... -
Page 9: Preparation
User manual LAM3301 04 - Preparation First cleaning of the appliance Tips for saving energy Remove all packaging materials. The following information will help you to use your appliance in an ecological way, and to save energy: Wipe the surfaces of the appliance with a... -
Page 10: Operating Modes
LAMONA Appliances 05 - Operating modes Operating modes All functions for the oven and grill are listed in this section. The order of operating modes shown here might deviate from the arrangement on your appliance. Fan Assisted cooking Grill -Full... -
Page 11: How To Use The Grill
User manual LAM3301 06 - How to operate the oven and grill Select temperature The grill heats up to the adjusted temperature & Operating mode and maintains it. During heating, the temperature indicator light will remain on until the desired temperature is reached. -
Page 12: Cooking And Baking Advice
LAMONA Appliances 07 - Cooking and baking advice Tips for baking cake Risk of scalding by hot steam! Take care when If the cake is too dry, increase the temperature opening the oven door as steam may escape. by 10°C and decrease the cooking time. -
Page 13: Cooking Tables
User manual LAM3301 08 - Cooking Tables The values indicated in the tables below are Baking and roasting indicative. They may vary according to the type of Level 1 is the bottom level in the oven. food as well as your preferences of cooking. -
Page 14: Grill Cooking Table
LAMONA Appliances Grill cooking table GRILL COOKING TABLE Food Cooking level Oven Function Cooking Time (min) Fish 4 - 5 Level 20 - 25 Sliced chicken 4 - 5 Level 25 - 30 Lamb chops 4 - 5 Level 20 - 25... -
Page 15: Care And Maintenance
User manual LAM3301 09 - Care and maintenance General information Cleaning the control panel Service life of the product will extend and the Clean the control panel and control knobs with a possibility of problems will decrease if the product is damp cloth and wipe them dry. -
Page 16: Removing The Inner Door Glass
LAMONA Appliances Removing the inner door glass The inner glass panel of the oven door can be The inner glass can then be lifted from its removed for cleaning. retaining slots. When cleaning, avoid the use any harsh abrasive chemicals or sharp metal scrapers for as this could scratch the surface and damage the glass. -
Page 17: Removal Of The Oven Door
User manual LAM3301 Removal of the oven door Replacing the oven lamp Open the door. Hot surfaces may cause burns! Unlock the clips at the hinge housing on Make sure that the appliance is switched off the right and left hand sides of the door by... -
Page 18: Installation
LAMONA Appliances 10 - Installation Before installation The appliance is intended for installation in Howdens kitchen cabinets. The product should only be installed by suitably Surfaces, synthetic laminates and adhesives persons. used must be heat resistant. The product must be installed in accordance Kitchen cabinets must be set level and with all local regulations. -
Page 19: Installation And Connection
User manual LAM3301 Installation and connection This appliance must only be installed by a electrician, e.g. a local electricity company or a NICEIC registered contractor, Material damage! to a suitable double-pole control unit with The door and/or handle must not be used for lifting a minimum contact clearance of 3 mm in or moving the appliance. -
Page 20: Cooling Fan
LAMONA Appliances Cooling fan Installation Slide the oven through the cabinet aperture, align and secure. Fix your oven with the 2 screws and washers as indicated in the illustration. Final check Control panel Connect the appliance to the mains supply, Door switch on the mains supply and check the oven’s... - Page 21 User manual LAM3301 TECHNICAL INFORMATION General Voltage /Frequency 220-240 V ~ 50 Hz Total power consumption 2.4kW min. 13 A Fuse Cable type / section H05VV-FG 1.5mm², 3 core or equivalent Cable length max. 2m Oven/Grill External dimensions (height / width / depth)
-
Page 22: Troubleshooting
LAMONA Appliances 12 - Troubleshooting TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Oven emits steam when it Food is being cooked with a high It is normal that steam escapes from food during cooking. is in use. water content This is not a fault. -
Page 23: Your Guarantee
User manual LAM3301 13 - Your guarantee Product Guarantee Details (UK only) breakdown repairs. (Details of which are shown on your Proof of Purchase Document). Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE) The product must be correctly installed and operated in accordance with the manufacturer’s... - Page 24 ISSUE 080514 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
