  • Page 1 PCM-4335 All-in-one 486DX-66 with Flat Panel/CRT PC/104 Module...

  • Page 2: Fcc Statement

    FCC STATEMENT THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERA- TION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFER- ENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

  • Page 3: Copyright Notice

    Copyright Notice This document is copyrighted, 1997, 1998, by AAEON Technology Inc. All rights are reserved. AAEON Technology Inc. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of AAEON Technology Inc.

  • Page 4: Packing List

    456E, please read it thoroughly before you install and use the board. The product that you have purchased comes with two-year limited warranty, but AAEON cannot be responsible for misuse of the product. Therefore, we strongly urge you first read the manual before using the product.

  • Page 5: Table Of Contents

    Contents General Information ......1 Introduction ................2 Specifications ................. 3 Installation ........... 5 Jumpers and connectors ............6 Locating jumpers and connector ........7 Setting jumpers ..............8 Safety precautions ..............9 Fan power connector ............10 Floppy drive connector (CN2) .......... 10 Serial ports connector (CN3/COM1, CN8/COM2) ..
  • Page 6 AMIBIOS Setup ........31 General information ............32 Starting AMIBIOS setup ............32 AMIBIOS main menu ............. 32 Using a mouse with AMIBIOS setup ........33 Using the keyboard with AMIBIOS setup ......33 Standard CMOS setup ............34 Advanced CMOS setup ............. 36 Advanced chipset setup .............
  • Page 7 Watchdog Timer ......73 Watchdog Timer ..............73 Example ................75 SetWatchDog_timer ENDP..........76 Installing PC/104 Modules ....79 Installing PC/104 modules ..........80...

  • Page 9: General Information

    This chapter provides background information for the PCM-4335. Sections include: • Card specifications Chapter 1 General Information...
  • Page 10 With its industrial grade reliability, the PCM- 4335 can operate continuously at temperatures up to 140º F (60º C). The PCM-4335 is specially designed as a compact all-in-one CPU card which incorporates a PC/104 connector into its design, making without backplane SBC applications possible.
  • Page 11 CPU: STPC Client BIOS: AMI 128KB FLASH BIOS Chipset: STPC Client Super I/O Chipset: Winbond W83977F RAM memory: 4MB to 64MB. One 144-pin SODIMM socket on board. Enhanced IDE hard disk drive interface: Support up to two hard disk drives. BIOS auto-detect. Supports PIO mode 4 and Bus Master. 22 x 2 header, pitch 2.00mm.
  • Page 12 One 32-pin DIP socket supports M-systems DiskOnChip 2000 series, memory capacity from 2MB to 144MB. Power supply voltage: +5V (4.75V to 5.25V) Max. power requirements: +5V @ 2A Operating temperature: 32 to 140ºF (0 to 60ºC) Board Size: 96mm x 90mm Weight: 0.2 Kg PCM-4335 User's Manual...

  • Page 13: Installation

    Installation This chapter explains set up procedures for the PCM-4335 hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installa- tion procedure. Chapter 2 Installation...

  • Page 14: Jumpers And Connectors

    COM2 (RS-232/422/485) External KB/PS2 mouse connector CN10 Power connector -5V/-12V Voltage input connector DOC address select RS-232/422/485 select (COM2) Clear CMOS Keyboard lock LCD panel voltage select Hardware reset LCD SHF/ASHF clock select External speaker connector 6 PCM-4335 User's Manual...

  • Page 15: Locating Jumpers And Connector

    Locating jumpers and connector JP1 JP2 14 13 CLIENT 13 26 CN10 Chapter 2 Installation...

  • Page 16: Setting Jumpers

    If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales represen- tative before you make any changes. Generally, you simply need a standard cable to make most connections. 8 PCM-4335 User's Manual...

  • Page 17: Safety Precautions

    Safety precautions Warning! Always completely disconnect the power cord from your chassis whenever you are working on it. Do not make connections while the power is on because sensitive electronic components can be damaged by the sudden rush of power. Only experienced electronics personnel should open the PC chassis.

  • Page 18: Fan Power Connector

    Fan power connector (CN1) PCM-4335 offer +5V to drive a fan for CPU. 2 (-) 1 (+) 14 13 (CN1) CLIENT 13 26 10 PCM-4335 User's Manual...

  • Page 19: Floppy Drive Connector (Cn2)

    Floppy drive connector (CN2) You can attach up to two floppy disks to the PCM-4335's on- board controller. You can use any combination of 5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB, and 2.88 MB) drives.

  • Page 20: Serial Ports Connector (Cn3/Com1, Cn8/Com2)

    Serial port connectors (CN3/COM1, CN8/COM2) The PCM-4335 offers two serial ports. One RS-232 and one RS-232/422/485. These ports allow you to connect them to serial devices (a mouse, printers, etc.), or a communication network. You also can select or disable the address for each port with the BIOS peripheral setup program.
  • Page 21 RS-232 connector (CN3/COM1) The following table shows the pin assignments for the card's RS- 232 port: RS-232 connector (CN3/COM1) Signal RS-232/422/485 connector (CN8/COM2) RS-232/422/485 connector (CN8/COM2) Signal B485TXD+ B485TXD- B422RXD+ B422RXD- Chapter 2 Installation...

  • Page 22: Ide Hard Drive Connector (Cn4)

    If you install two drives, you will need to set one as the master and one as the slave by using jumpers on the drives. If you install just one drive, set it as the master. 14 PCM-4335 User's Manual...
  • Page 23 Pin assignments The following table lists the pin numbers and their respective signals: IDE hard drive connector (CN4) (CN4) IDE hard drive connector Signal Signal IDE RESET DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12...

  • Page 24: Parallel Port Connector (Cn5)

    Parallel port connector (CN5) Normally, the parallel port is used to connect the card to a printer. The PCM-4335 includes an onboard parallel port, accessed through CN5, a 26-pin flat-cable connector. You need an adapter cable if you use a traditional DB-25 connector.

  • Page 25: Vga Display Connector (Cn6)

    BLUE CHASSIS GND CHASSIS GND When the PCM-4335's power is applied, the control signal is low until just after the relevant flat panel signals are present. Configuration of the VGA interface is done completely via the software utility. You don't have to set any jumpers.
  • Page 26 14 13 CLIENT 13 26 49 50 (CN7) 18 PCM-4335 User's Manual...

  • Page 27: Lcd Panel Connector (Cn7)

    LCD panel connector (CN7) LCD panel connector (CN7) Signal Signal +12 V +12 V +5 V +5 V ENAVEE SHF CLK FLM (V SYS) LP (H SYS) ENABKL Chapter 2 Installation...
  • Page 28 "Present" or "Absent" selection. This allows no- keyboard operation in embedded system applications without the system halting under POST (power-on-self-test). 14 13 CLIENT 13 26 (CN9) (CN9) Keyboard and PS/2 mouse connector Signal KB_Data MS_Data KB_CLK MS_CLK 20 PCM-4335 User's Manual...

  • Page 29: Power Supply Connector (Cn10)

    Power supply connector (CN10) In single board computer without backplane applications, you will need to connect power directly to the PCM-4335 board using CN10. This connector is fully compatible with the standard PC power supply connectors(mini 4-pin). See the following table for...

  • Page 30: Exter Power Supply Connector (J1)

    Exter power supply connector (J1) The PCM-4335 cna offer -5V & -12V voltages by input from the (J1) connector for expansion PC/104 application cards. 14 13 CLIENT 13 26 (J1) External power supply connector (J1) Function -12V 22 PCM-4335 User's Manual...

  • Page 31: Doc Address Select (Jp1)

    DOC address select (JP1) The DiskOnChip 2000 occupies a 8 KB window in the upper memory address range of CC00 to DC00. You should ensure this does not conflict with any other device's memory address. JP1 controls the memory address of the Flash disk. 2 4 6 14 13 1 3 5...

  • Page 32: Rs-232/422/485 Select (Jp2)

    RS-232/422/485 select (JP2) The PCM-4335 offers two serial ports. One RS-232 and one RS- 232/422/485. The follwing charts show the available options: 2 4 6 14 13 1 3 5 CLIENT (JP2) 13 26 RS-232/422/485 select (JP2) *RS-232 RS-422 RS-485...

  • Page 33: Clear Cmos (Jp3)

    Clear CMOS (JP3) You can connect an external switch to clear CMOS. This switch closes CLEAR CMOS and turns on the power, at which time the CMOS setup can be cleared. 14 13 CLIENT 13 26 1 2 3 (JP3) Clear CMOS (JP3) Protect* Clear CMOS...

  • Page 34: Keyboard Lock Function(Jp4)

    Simply connect the switch between Pins 1 and 2. The pin assignments appear in the following table: 14 13 CLIENT 13 26 (JP4) Keyboard lock function (JP4) Function Keyboard lock Ground 26 PCM-4335 User's Manual...

  • Page 35: Lcd Driving Voltage Select (Jp5)

    LCD driving voltage select (JP5) You can select the LCD connector (CN7) driving voltage by setting JP5. The configuration as follows 14 13 CLIENT 13 26 1 2 3 (JP5) LCD driving voltage select (JP5) 3.3V Chapter 2 Installation...

  • Page 36: Reset Switch (Jp6)

    This switch restarts your computer as if you had turned off the power then turned it back on. The following table shows the pin assignments for the JP6. 14 13 CLIENT 13 26 (JP6) Reset switch (JP6) Function Reset 28 PCM-4335 User's Manual...

  • Page 37: Lcd Signal Select (Jp7)

    LCD signal select (JP7) You can select the LCD control signal by setting (JP7). The following charts show the available option: 14 13 CLIENT 13 26 3 2 1 (JP7) LCD signal select (JP7) ASHF CLK SHF CLK Chapter 2 Installation...

  • Page 38: External Speaker Connector (Sp1)

    External speaker connector (SP1) You can connector an external speaker to SP1. 1 (+) 14 13 (SP1) CLIENT 13 26 30 PCM-4335 User's Manual...
  • Page 39 This chapter describes how to set the BIOS configuration data.
  • Page 40 Auto Configuration with Optimal Settings Auto Configuration with Fail Safe Settings Save Settings and Exit Exit Without Saving Standard CMOS setup for changing time, date, hard disk type, etc. ESC: Exit :Sel F2/F3: Color F10: Save & Exit ¯- 32 PCM-4335 User Manual...

  • Page 41: Amibios Setup

    AMIBIOS Setup can be accessed via keyboard, mouse. The mouse click functions are: • single click to change or select both global and current fields • double click to perform an operation in the selected field AMIBIOS Setup has a built-in keyboard driver that uses simple keystroke combinations: Keystroke Function...

  • Page 42: Standard Cmos Setup

    Sec Mode Mode Mode Mode Pri Master AUTO AUTO Off Pri Slave : AUTO AUTO Off Boot Sector Virus Protection Disabled Month: Jan - Dec Esc: Exit :Sel ¯- Day: 01-31 PgUp/PgDn: Modify Year: 1901 -2099 F2/F3: Color 34 PCM-4335 User Manual...
  • Page 43 Select the Date and Time icon in the Standard CMOS setup. The current values for each category are displayed. Enter new values through the keyboard or hit the "+" or "-" key to change values. Select the appropriate specifications to configure the type of floppy drive that is attached to the system: 360 KB 5¼", 1.2 MB 5¼", 720 KB 3½", and/or 1.44 MB 3½".
  • Page 44 Auto Configuration with Optimal Settings Auto Configuration with Fail Safe Settings Save Settings and Exit Exit Without Saving Standard CMOS setup for changing time, date, hard disk type, etc. ESC: Exit :Sel F2/F3: Color F10: Save & Exit ¯- 36 PCM-4335 User Manual...

  • Page 45: Chapter 3 Amibios Setup

    Press enter, the Advanced CMOS Setup screen appears: AMIBIOS SETUP — ADVANCED CMOS SETUP (C) 1995 American Megatrends, Inc. All Rights Reserved Available Options: Quick Boot : Enabled Disabled 1st Boot Device : IDE-0 Enabled 2nd Boot Device : Floppy 3rd Boot Device : Reserved Try Other Boot Devices...
  • Page 46 The settings are Enabled or Disabled. The default setting is Disabled. When this option is set to Enabled, AMIBIOS supports a PS/2- type mouse. The settings are Enabled or Disabled. The default setting is Enabled. 38 PCM-4335 User Manual...
  • Page 47 This option specifies that a keyboard is attached to the computer. The settings are Present or Absent. The default setting is Present. This option specifies the type of display monitor and adapter in the computer. The settings are Mono, CGA40x25, CGA80x25, VGA/EGA, or Absent.
  • Page 48 L2 cache memory. The contents of the F0000h memory segment are always copied from the BIOS ROM to system RAM for faster execution. The settings are Enabled or Disabled. The default setting is Disabled. 40 PCM-4335 User Manual...
  • Page 49 C000, 16K Shadow C400, 16K Shadow C800, 16K Shadow CC00, 16K Shadow D000, 16K Shadow D400, 16K Shadow D800, 16K Shadow DC00, 16K Shadow These options control the location of the contents of the 16KB of ROM beginning at the specified memory location. If no adapter ROM is using the named ROM area, this area is made available to the local bus.

  • Page 50: Advanced Chipset Setup

    DRAM Bank 0 :EDO 60us DRAM Bank 1 :EDO 60us Memory Hole :Disabled PCI to Host Read Prefetch :Disabled ESC: Exit :Sel ¯- PCI to Host write posting :Disabled PgUp/PgDn: Modify Watchdog Timer Support :Enablled F2/F3: Color 42 PCM-4335 User Manual...

  • Page 51: Power Management Setup

    The Power management setup offers options to help reduce power consumption. To see the options in this group, choose the Power management setup icon from the AMIBIOS setup main menu. AMIBIOS SETUP — BIOS SETUP UTILITIES (C) 1995 American Megatrends, Inc. All Rights Reserved Standard CMOS Setup Advanced CMOS Setup Advanced Chipset Setup...
  • Page 52 10 seconds to 2 hours and can be set manual- ly when power management is in SMI. The default setting is Disabled. When the system goes into power saving mode, power management will skip to the next mode in the sequence if this is disabled. 44 PCM-4335 User Manual...
  • Page 53 This sets the period of system inactivity after which the system goes into Standby mode, the intermediate power saving state. The settings range from 10 seconds to 2 hours and can be set manually when power management is in SMI. The default setting is Disabled.
  • Page 54 (such as DOS, OS/2, Windows 3.x) does not use PnP. You must set this option correctly or PnP-aware adapter cards installed in your computer will not be configured properly. The settings are Yes or No default settings is no. 46 PCM-4335 User Manual...
  • Page 55 AMIBIOS SETUP — ADVANCED CHIPSET SETUP (C) 1995 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S : No :Enabled Available Options: PCI Latency Timer (PCI Clocks) : 64 PCI VGA Palette Snoop : Display PCI IDE Bos Master : Display Off Board PCI IDE Card : Auto...
  • Page 56 ISA/EISA setting. Onboard I/O is configurable by AMIBIOS. The IRQs used by onboard I/O are configurable by AMIBIOS. The IRQs used by onboard I/O are configured as PCI/PnP. The settings are PCI/PnP or ISA/EISA. The default settings are PCI/PnP. 48 PCM-4335 User Manual...
  • Page 57 Peripheral Setup options are displayed by choosing the Peripheral Setup icon from the AMIBIOS Setup main menu. All Peripheral Setup options are described in this section: AMIBIOS SETUP — BIOS SETUP UTILITIES (C) 1995 American Megatrends, Inc. All Rights Reserved Standard CMOS Setup Advanced CMOS Setup Advanced Chipset Setup...
  • Page 58 IRQ7 is used for the Parallel Port (LPT 1). The IRQ can be changed to IRQ5. This option enables serial port 1 on the motherboard and specifies the base I/O port address for serial port 1~4. The settings are Disabled, 3F8h, 3E8h, 2E8h, and 2F8h. 50 PCM-4335 User Manual...
  • Page 59 1) Select this option from the main menu 2) Enter the Password and Press <Enter> 3) Retype the Password and Press <Enter> If you forget the password, please contact your distributor for another password which you can use to enter the AMIBIOS setup and change your own password.
  • Page 60 Auto Configuration with Optimal Settings Auto Configuration with Fail Safe Settings Save Settings and Exit Exit Without Saving Standard CMOS setup for changing time, date, hard disk type, etc. ESC: Exit :Sel F2/F3: Color F10: Save & Exit ¯- 52 PCM-4335 User Manual...
  • Page 61 You can load the Fail Safe settings for the AMIBOIS setup options by selecting it from the main menu. The Fail Safe settings provide the most stable settings, though they may not provide optimal performance. Use this option as a diagnostic aid if the system is behaving erratically.
  • Page 62 Auto Configuration with Optimal Settings Auto Configuration with Fail Safe Settings Save Settings and Exit Exit Without Saving Standard CMOS setup for changing time, date, hard disk type, etc. ESC: Exit :Sel F2/F3: Color F10: Save & Exit ¯- 54 PCM-4335 User Manual...
  • Page 63 Selecting this option and pressing <Enter> lets you exit the Setup program, without recording any new values or changing old ones. AMIBIOS SETUP — BIOS SETUP UTILITIES (C) 1995 American Megatrends, Inc. All Rights Reserved Standard CMOS Setup Advanced CMOS Setup Advanced Chipset Setup Power Management Setup PCI/Plug and Play Setup...
  • Page 64 56 PCM-4335 User Manual...
  • Page 65 This chapter provides information about: • Driver types and installation...

  • Page 66: Software Drivers

    This chapter describes the operation and installation of the display drivers supplied on the Supporting CD-ROM that are shipped with your product. The onboard VGA adapter is based on the CHIPS VGA Flat Panel/CRT controller and is fully IBM VGA compatible. This controller offers a large set of extended functions and higher resolutions.
  • Page 67 The instructions in this manual assume that you understand elementa- ry concepts of MS-DOS and the IBM Personal Computer. Before you attempt to install any driver from the Supporting CD-ROM, you should: • Know how to copy files from a CD-ROM to a directory on the hard disk •...
  • Page 68 Ò Ò These drivers are designed to work with Microsoft Windows . You Ò just install these drivers through the Windows operating system. Ò 1. Install Windows 95 as you normally would for a VGA display. Click the Start button, go to Settings and click on Control Panel.
  • Page 69 Click the setting buttom, then click the Advanced Properties icon into the Advanced Display properties windows, show as figure2: figure 2...
  • Page 70 click on Change Display Type. In the Change Display Type window, click on the Change button under Adapter Type into the select Device window show as figure(3):This will bring up the Select Device window. figure 3...
  • Page 71 2. Place the Supporting CD-ROM in your CD-ROM drive. figure 4 In the Select Device window, click on Have Disk, Select Browse, and find the Win95 driver "chips95.inf" in the Supporting CD- ROM: cd-rom: \CD ROM\mode name\driver\vga driver \win95\chips95.inf and then click OK. "cd-rom"...
  • Page 72 The name of the Chips And Techn "69000 PCI " driver will appear highlighted in the Models list boxfhow as figure. Click OK to start the driver installation show as figure 5: figure 5...
  • Page 73 Once the installation is complete, the Advanced display Properties window will reappear. Show as figure 6: figure 6...
  • Page 74 Click on close to close the window. Then the Display Properties window will reappear. Show as figure 7: figure 7...
  • Page 75 Click on Apply. Restart the system for the new settings to take effect, show as figure 8: figure 8...
  • Page 76 These drivers are designed to work with Microsoft Windows Version 3.1. You should install these drivers through Windows. 1. Install Windows as you normally would for a VGA display. Run Windows to make sure that it is working correctly. 2. Place the Supporting CD-ROM into your CD-ROM drive. In Windows Program Manager, choose File from the Options Menu.
  • Page 77 These drivers are designed to function with the OS/2 Version 4.0, 3.0 and 2.11 operating systems. To install this driver, do the following steps: 1. Open an OS/2 full screen or windowed session. 2. Place the Supporting CD-ROM into your CD-ROM drive. 3.
  • Page 78 6. When the installation is complete, you will need to shut down and then restart the system for the changes to take effect. Make sure to remove the installation diskette before restarting the system.
  • Page 79 Ò Ò These drivers are designed to work with Microsoft Windows Ò 1. Install Windows NT 3.51 as you normally would for a VGA Ò display. Run Windows N T Control Panel from the Main Group. Choose the Display option. In the Display Settings dialog box, click on Change Display Type.

  • Page 80: Driver Installation

    Ò 1. Install Windows NT 4.0 as you normally would for a VGA display. First click the Start button, go to Settings and click on Control Panel. Choose the Display icon and click on the icon. In the Display Properties window, click on the Settings tab. Then click on Change Display Type.
  • Page 82 1. Enter configuration mode. 2. Select Logical Device. 3. Select register number. 4. write/read data to/from register. 5. exit configuration mode. watch-dog function program procedure is : 1. Active Watching-Dog Timer output Function. 2. Write Watching Dog Timer Time-out value. PCM-4335 User's Manual...

  • Page 83: A Watchdog Timer

    Following is an Example of programming 16 seconds period for watchdog timer in assembly language. When timer times out, it will generate system reset. .model small .code CONFIG_PORT dw 3f0h DATA_PORT 3f1H SetWatchDog_Time PROC push bx push cx push dx bl,7 ;;...
  • Page 84 ;; Delay EnterConfig endp ;; Exit to I/O Chip Program Configuration Register Mode ExitConfig proc push ax push dx al,0aah ;; Specific Value to Exit Config Mode dx,cs:CONFIG_PORT ;; dx,al ;; Write to Config Port ExitConfig endp PCM-4335 User's Manual...
  • Page 85 ;; Select The I/O Chip Program Configuration Register Logical Device ;; Input : bl = logical device number SelectDevice proc push ax push dx al,07h ;; Select Control Register 7 (CR07) dx,cs:CONFIG_PORT ;; dx,al ;; Write to Config Port al,bl ;;...
  • Page 86 ;; Select Logical Device dx,cs:CONFIG_PORT ;; Write value(al) to Config Port dx,al ;; to select register number al,ah dx,cs:DATA_PORT ;; Write data(ah) to Data Port dx,al ;; to setting register value call ExitConfig ;; Exit Config Mode W977Write ENDP PCM-4335 User's Manual...
  • Page 87 This appendix gives instructions for installing PC/104 modules.
  • Page 88 The PCM-4335's PC/104 connectors give you the flexibility to attach PC/104 expansion modules. These modules perform the functions of traditional plug-in expansion cards, but save space and valuable slots. Modules include: • PCM-3110B PCMCIA Module (one-slot) • PCM-3115B PCMCIA Module (two-slot) •...

  • Page 89: B Installing Pc/104 Modules

    Installing these modules on the PCM-4335 is a quick and simple operation. The following steps show how to mount the PC/104 modules: Step1 Remove the PCM-4335 from your system, paying particular attention to the safety instructions already mentioned above. Step2 Make any jumper or link changes required to the CPU card now.
  • Page 90 0.300 3.250 3.775 3.575 3.575 0.200 0.200 3.350 0.200 3.550 PCM-4335 User's Manual...
