Summary of Contents for Monitor Audio platinum series II
- Page 1 S p e a k e r M a n u a l...
-
Page 3: Table Of Contents
Contents Introduction from the Technical Director 2 AV Positioning 7 Company History 2 FX Speakers 8 Premium Materials for Unmatched Aesthetics 3 Connecting Speaker Cables 9 Natural Leather Characteristics 3 Bare Wire Connection 9 Real Wood Veneers 3 Banana Plugs 9 Technologies 4... -
Page 4: Introduction From The Technical Director
By consistently refining and applying the technology, Monitor Audio has become the world’s foremost proponent of metal dome drivers. Monitor Audio designs everything in house at their world headquarters in England, so that it can optimise the incomparable blend of virtues that makes Monitor Audio loudspeakers unique: clean, dynamic sound, superior build quality and innovative design. -
Page 5: Premium Materials For Unmatched Aesthetics
Each cabinet is a unique and natural work of art! Because of this, Monitor Audio Ltd. is to unable guarantee that the veneer on different pairs of speakers will be identical in colour or grain definition. We can only assure you that the very best raw materials have been selected and applied. -
Page 6: Technologies
This combination is able to reduce distortion by over 8dB above 300Hz, which equates to a 60% reduction in the energy of harmonic components, making RDT II the lowest distortion cone technology in Monitor Audio’s history. HiVe®II(HighVelocity,LowNoiseReflexPort) A new type of port technology which uses a straight rifled design to accelerate air flow and reduce turbulence. -
Page 7: Anti-Resonance Composite (Arc)
ARC is used for mid-range housings and baffle components. ARC is a unique material, developed specifically by Monitor Audio engineers for the Platinum II series. Its properties ensure energy is damped out and not emitted as high-Q resonance. -
Page 8: Unpacking
If it’s slightly off-level, unscrew the foot at the lowest point and check again. Continue this process until the cabinet is fully level. Use the locking nuts on each foot to fix the feet in place and to stop any unwanted vibrations. Platinum Series II... -
Page 9: Setting Up
Setting Up 2-Channel Positioning When arranging a 2-channel system, the listening position and the loudspeakers should form an equilateral triangle. The speakers should be positioned approximately 6 - 10 feet (1.8 - 3m) apart. The ideal distance from the rear wall varies depending on the speaker (see guide below), however, the speakers need to be a minimum of 3 feet (91cm) from the side walls. -
Page 10: Fx Speakers
FX Speakers If you wish to use FX speakers in an AV system with Platinum Series II we would recommend the Gold FX, which not only will be a good timbre and tonal match with your Platinum II speakers but is also available in the same selection of high quality finishes. -
Page 11: Connecting Speaker Cables
Connecting Speaker Cables Bare Wire Connection Unscrew the binding posts and pass the bare wire through the hole in the binding post. Tighten the binding post to clamp the wire in place. Banana Plugs Remove the red and black plastic plugs from the terminals and insert the banana plugs into the standard 4mm holes that are revealed. -
Page 12: Bi-Wiring
Platinum Series II... -
Page 13: Port Bungs
In terms of the audible benefit, bi-wiring/ bi-amping, provides more clarity and detail to the midrange and high frequencies. Often the bass will become faster and tighter. Focus and staging will improve as well. In all, this is a very effective and desirable improvement and is highly recommended by Monitor Audio. Port bungs WARNING: Care must be taken not to insert the port bungs too far into the port, as this may result in the foam bung being lost inside the cabinet. -
Page 14: Running-In Your Platinum Ii Speakers
(red to red and black to black), and the other speaker out of phase: positive to negative and negative to positive inputs on the speaker. For information on Monitor Audio’s System De-Tox disk please refer to our website: www.monitoraudio.com Care and Maintenance... -
Page 15: Upkeep Of Cabinets
Platinum II speakers. Stands New dedicated Platinum Series II stands are available, to perfectly compliment both aesthetically and acoustically with the PL100 II stand mount speakers. They feature sturdy ‘no ring’ construction to add safe support and isolate the speakers from resonant frequencies. -
Page 16: Specifications
23.98Kg (52lb 12oz) 43.02Kg (94lb 10oz) kg (Ibs) Santos Rosewood veneer with piano lacquer. Finishes Available Ebony veneer with clear piano lacquer or Piano Black lacquer. Upholstered front baffle in Black Ingleston premium grade leather By Andrew Muirhead. Platinum Series II... - Page 17 Monitor Audio Ltd. 24 Brook Road Rayleigh, Essex SS6 7XJ England Tel: +44 (0)1268 740580 Fax: +44 (0)1268 740589 Email: info@monitoraudio.co.uk Web: www.monitoraudio.com Designed & Engineered in the United kingdom Made in China Version 1. 2015...
