Summary of Contents for Monitor Audio Loudspeaker Platinum Series

  • Page 2 “In developing Platinum we’ve created the definitive Monitor Audio loudspeaker. There is no finer expression of the dedication to sound quality, design and engineering that has driven our adventure and innovation for over three decades. We’ve proved once again that there is no preconception that cannot be challenged, no rule beyond question.
  • Page 3 T e c h n i c a l E x p e r t i s e I n n o v a t i o n S u p e r i o r D e s i g n P e r f o r m a n c e P r i d e O w n e r s h i p...
  • Page 4 S P r E z z a T u r a Famous for his ‘Il Libro Del Cortegiano’ (The Book of the Courtier, 1528), Renaissance humanist Baldesar Castiglione coined the word ‘sprezzatura’ to describe the ideal for courtly behaviour. He insisted that in order to be worthy, exceptional virtuosity should be conveyed with an unaffected, effortless dignity.
  • Page 6 D I T I O n Introducing genuinely esoteric affordable performance and quality, Monitor Audio’s Platinum loudspeakers are engineered to achieve the most natural sound possible. In our quest for true fidelity, we’ve harnessed new materials, developed innovative new technologies, tested, refined and optimised every last design detail, and verified the science with plenty of good old-fashioned listening.
  • Page 8 Q u a l i t y Each pair of Platinum loudspeakers is an original work of art. Monitor Audio’s cabinet makers hand select uniquely matching sets of exotic natural wood veneer in Santos Rosewood or Ebony for every pair.
  • Page 10 T e c h n o l o g i e s Ceramic-Coated Aluminium/Magnesium (C-CAM ® Since 1972, Monitor Audio’s near fanatical commitment to excellence and innovation has received global recognition and acclaim. When we launched our R352MD loudspeaker - the first model to incorporate a metal dome tweeter - it caused quite a stir.
  • Page 12 Platinum C-CAM high frequency ribbon transducer. A pure ribbon tweeter is highly regarded in the world of high-end audio as being the best way to reproduce ultra-high frequencies and provide the most lifelike transient response. While this belief is well supported by fundamental physics, one listen will tell you that this driver is very special indeed.
  • Page 14 To optimise the performance of the RDT cone, Monitor Audio has developed motor systems in which a focused magnetic gap and copper eddy rings work together to produce a higher level of linearity and lower distortion than was previously possible.
  • Page 16 ARC material, a thermo-set polymer loaded with minerals to provide very inert, optimally-damped components. Refined for Platinum by Monitor Audio’s engineers, this type of material is used for leading-edge automotive design and is ideal for acoustic applications where a high degree of structural rigidity and vibration damping is required.
  • Page 17 HiVe II (High Velocity reflex port) TLE (Tapered Line Enclosure) ARC (Anti-Resonance Composite) ARC (Anti-Resonance Composite)
  • Page 18 Internally, the sides are non-regular, preventing the formation of standing waves, which undermine the accuracy of the system. Monitor Audio has developed a unique ‘pin-hole’ bracing structure for the Platinum series, positioned to provide rigidity and integrity. Cabinet bracing is further enhanced by steel bolts that tie front and back panels to the ‘pin-hole’...
  • Page 20 P L 1 0 0 A compact two-way loudspeaker featuring one 6.5” (165mm) RDT bass-mid driver and C-CAM ribbon transducer. The PL100 has the superior bass definition and detailed mid-range response of the most accurate studio monitors; and its ability to generate the deepest bass frequencies will redefine expectations of a small speaker.
  • Page 22 With a range from 28Hz to 100kHz, the PL300 is a true wide bandwidth speaker system which is unrivalled in its class. Between 550Hz and 4kHz, the PL300’s ultra-light and rigid RDT...
  • Page 24 P L C 3 5 0 PLC350 is a substantial three–way, four driver centre channel speaker with the same driver complement as the PL300. Armed with the drivers and technologies of the Platinum series, the PLC350 is able to illuminate frequencies from 32Hz to 100 kHz - arguably the widest bandwidth of any centre speaker available.
  • Page 26 P L W - 1 5 Underpinning the drama and scintillating musical vitality of a Platinum multichannel speaker system is the PLW-15, a range- matching sub-bass engine endowed with all the quality, virtuosity and excellence that defines the marque. Capable of releasing the...
  • Page 28 Frequency Response Sensitivity (1W@1m). dB Nominal Impedance. ohms Maximum S.P.L dBA (per pair) Power Handling (RMS) watts Recommended Amplifier Requirements (RMS) watts Bass Alignment Mid/ H.F Crossover Frequency Bass Low Pass Crossover Frequency Drive Unit Complement External Dimensions - Excluding Stand Weight (each) Stand External Dimensions Finishes Available GENUINE LEATHER 42Hz - 100kHz 112.6 120 50-120 Ported. HiVe II technology ® 2800Hz N/A 1 x 6.5” RDT Bass/mid-range driver ® 1 x C-CAM high frequency ribbon transducer ®...
  • Page 29 Frequency Response Sensitivity (1W@1m). dB Nominal Impedance. ohms Maximum S.P.L dBA (per pair) Power Handling (RMS) watts Recommended Amplifier Requirements (RMS) watts Bass Alignment Mid/ H.F Crossover Frequency Bass Low Pass Crossover Frequency Drive Unit Complement External Dimensions – Including Fixed Plinth & Feet Weight (each) Including Plinth Finishes Available GENUINE LEATHER 28Hz - 100kHz 118.6 300 100-300 Twin Ported HiVe ® Sealed Mid-range TLE 4000Hz 550Hz 2 x 8” long-throw RDT 1 x 4”...
  • Page 30 MODEL Frequency Response Sensitivity (1W@1m). dB Nominal Impedance. ohms Maximum S.P.L dBA (per pair) Power Handling (RMS) watts Recommended Amplifier Requirements (RMS) watts Bass Alignment Mid/ H.F Crossover Frequency Bass Low Pass Crossover Frequency Drive Unit Complement External Dimensions - Excluding Stand Weight Stand External Dimensions – Including Plinth & Feet Finishes Available GENUINE LEATHER PLC350 32Hz- 100kHz 117.8 100-250 Twin Ported HiVe II technology ® Sealed Mid-range TLE ®...
  • Page 31 The PLW-15 subwoofer is scheduled to be introduced in 2008. All information and specifications will be available on its release. External Dimensions - Excluding Plinth. Weight (each) Including Plinth Mains input Voltage Trigger Input Finishes Available Width: 485mm Height: 455mm Depth: 475mm 50 Kg 100 - 240 Vac (50 / 60 Factory Set) 3.5mm Jack input, +12Vdc = On State...
  • Page 34 Monitor Audio Ltd 24 Brook Road, Rayleigh Essex, SS6 7XL England Tel: + 44 (0)1268 740580 Fax: + 44 (0)1268 740589 Email: info@monitoraudio.co.uk monitoraudio.co.uk Designed in the United Kingdom...
