5. Adjust valve knob to desired cooking temperature.
Using the Lighting Stick to Light the Burners
1. Insert a match into
2. Once lit, place the flame through the hole on left side of grill body to reach
the burner ports. (see diagram on the right).
3. Push and turn control knob to "HIGH" setting. After lighting observe the burner flame,
Make sure all burner ports are lighted--a blue/yellow flame of one to two inches
from the burner ports should appear.
If ignition still does not take place, turn the burner control knob to the "OFF" position.
Wait five minutes with lid open for the gas to clear and repeat the lighting procedure.
4. Adjust valve knob to desired cooking temperature.
Confirm that the burner is properly lit by agreeing with description below. If the flame pattern appears abnormal, consult the
troubleshooting guide on page 12 for corrective action.
FIG. A
Normal: Soft blue flames with yellow tips
between I inch - 2 inches high.
Flare-ups:
"Flare-ups" sometimes occur when food drippings fall onto the hot heat plate or burner and ignite. Some flaring is normal and
desirable as it helps impart the unique flavors associated with grilled foods. Controlling the intensity of the flare-ups is
necessary, however, in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental fire.
WARNING: Always monitor the grill closely when cooking and turn the flame level down (LOW) or OFF if flare-
ups intensify.
Shutting off the burner:
Always turn the valve knob clockwise all the way to the "LOCK OFF'' position.
Promptly disconnect the propane cylinder.

Excess flow safety valve reset procedure

A sudden shut off of the gas flow typically occurs if you open the LP tank valve rapidly.
This procedure is effective with all LP tank sizes.
To ensure the procedure is performed safely and successfully, please carefully follow the instructions below.
1. Turn the regulator valve to the "LOCK OFF" position.
2. Disconnect the LP tank from the regulator valve.
3. Open the lid of the grill.
4. Turn regulator valve to HIGH.
5. Wait at least one minute.
6. Turn the regulator valve to the "LOCK OFF" position.
GPT1813G
Instruction Manual
Guide d'utilisation
the end of the lighting stick and light it.
2 in.
Observe flame height when lit:
1 in.
Flame should be a blue/yellow colour between 1 to 2 inches high.
0 in.
Out of adjustment: Noisy hard blue
flames – too much air.
FIG. B
11
FIG. C
Poor combustion: Wavy, yellow
flames- too little air.
