Typical fully pumped system with F.M.Z.V in each
service
TP9 (Switch 1 to PUMPED)
Terminals
Mains
N
Supply
L
Other Danfoss Randall products suitable for use with the above
circuit:-
AT Cylinder Thermostat.
N L 1 2 3 4 5 6
3 amp
fuse
F.M.Z.V
in HW
C
W C W
ON
ON
OFF OFF
Cyl.
Stat
Boiler &
Pump
N
N
Remote
Sensor
N
Looping
Terminals
F.M.Z.V
in CH
N
GB
