- Page 1 LCD TV with LED backlight User Manual LE46D7840 LE50D7840 HIGH-DEFINITION MULTIMEDIA INTERFACE www.aoc.com 2013 AOC. All Rights Reserved.
- Page 3 This manual provides as an operational guide to user. All statements, technical information, and recommendations in this manual and in any guides or related documents are believed reliable, but the accuracy and completeness thereof are not guaranteed or warranted, and they are not intended to be, nor should they be understood to be, representations or warranties concerning the products described.
-
Page 4: Table Of Contents
COMPUTER FORMATS - HDMI REFERENCE CHART ....................16 COMPUTER FORMATS - VGA REFERENCE CHART ....................16 VIDEO FORMATS REFERENCE CHART ........................16 VIDEO SYSTEMS SUPPORTED BY THE TV,VIDEO MODES ..................16 USING AOC TV ................................. 17 FIRST ADJUSTMENTS ............................................17 Switching Input Source ............................................17 SETUP....................................18 TV SETTINGS ..............................................18... - Page 5 Set-up ..................................................23 Connect the TV to the Internet ..........................................23 Ready to start ..............................................23 Access Smart TV apps ............................................23 Download new apps ............................................23 Visit websites ..............................................23 Smart TV options ..............................................23 Erase Smart TV memory ..........................................23 SOURCE MENU ................................24 From the broadcaster ............................................24 Access broadcaster TV guide ..........................................24 Customize the TV guide ............................................24 RECORDINGS ..................................
-
Page 6: Important Information
Use the Wall-Mount bracket or TV stand which was recommended by the TV immediately and have it checked by qualified service AOC, and please consult your dealer for detailed information. personnel before operating it further. Use with other Wall-Mount Bracket or TV stand may cause instability 15 ) Avoid operating the TV at temperatures below 32°F (0°C). -
Page 7: Usage Instructions
If the AC power cord is damaged, it may result in a fire or Outdoor Use an electric shock. Stop using it and ask your dealer or AOC service center to exchange it. Do not install this TV outdoors. If the TV is exposed to rain, it may result in a fire or an electric shock. -
Page 8: Lcd/Led Screen
LCD/LED Screen Electric Shock Do not touch the AC power cord or the TV with a wet hand. If you Although the LCD/LED screen is made with high-precision plug/unplug the AC power cord from the TV with a wet hand, it may technology and has effective pixels of 99.99% or more, black dots cause electric shock. -
Page 9: Optional Equipment
Optional Equipment Batteries Do not install optional equipment too close to the TV set. Keep Do not dispose of batteries in a fire. optional equipment at least 11.875 inches (30 cm) away from the TV Do not short circuit, disassemble or overheat the batteries. set. -
Page 10: Sound
Sound Install on the wall If a snapping or popping sound from the TV is continuous or frequent 11 7/8 inches 30 cm while the TV is operating, unplug the TV and consult your dealer or service technician. It is normal for some TV’s to make occasional snapping or popping sounds, particu larly when being turned on or off. -
Page 11: Volume Adjustment
Ask a qualified service technician to dispose of the Thank you for purchasing this AOC high-definition television. The quality of the image you see on your AOC TV is only as good as the quality of the signal it receives. To experience the stunning detail of your new AOC TV, you need access to HD programming. -
Page 12: Contents In The Box
Contents in the Box After unpack the TV box, please check the TV and all accessories are well presented and undamaged. AOC TV Stand Base LIST EXIT Smart TV Remote Control AAA Battery x 2 Power cable User Warranty Card... -
Page 13: Controls & Connections
Controls & Connections VOL + Press to increase the sound volume level. VOL - Press to decrease the sound volume level. CH ▲ Press to select the next higher program number. CH ▼ Press to select the next lower program number. INPUT Press to select the input source. - Page 14 Item Description Connects to your headphones. If your headphones do not match the jack, use a suitable plug adapter (not Headphone supplied). Insert USB storage device to the USB 2.0 port to view photos, videos, and listen to music. / For future software USB/Service upgrades.
-
Page 15: Tv Installation
TV, especially to determine the strength of the wall for withstanding the TV’s weight. For product protection and safety reasons, AOC strongly recommends that you use the Wall-Mount Bracket model designed for your TV and the Wall-Mounting of your TV should be performed by AOC dealer or licensed contractor. -
Page 16: Connecting Tv
Connecting TV Cable System or VHF/UHF Antenna System You can enjoy standard-definition analog programming in with your new TV using both cable and external VHF/UHF antenna. It is strongly recommended that you connect the antenna/cable input using a 75-ohm coaxial cable to receive optimum picture quality. A 300-ohm twin lead cable can be easily affected by radio frequency interference, resulting in signal degradation. -
Page 17: Composite Signal Connection
Composite Signal Connection AV IN PC Connection Use the TV as a monitor for your PC shown below with the HD15 to HD15 connection. This TV can also be connected to a PC with DVI or HDMI output. (Refer to the separate Quick Setup Guide.) VGA IN D-SUB ... -
Page 18: Computer Formats - Hdmi Reference Chart
Computer formats - HDMI Reference Chart Resolution Vertical Frequency(Hz) 640 x 480 800 x 600 1024 x 768 1280 x 1024 1360 x 768 1920 x 1080 *Recommended resolution Computer formats - VGA Reference Chart Resolution Vertical Frequency(Hz) 640 x 480 800 x 600 1024 x 768 1280 x 1024... -
Page 19: Using Aoc Tv
USING AOC TV FIRST ADJUSTMENTS INITIAL SETUP This screen allows the user to start the channel installation before accessing other TV functions. You can also exit by pressing the EXIT key to quit the installation. Select your language English Español Portugués... -
Page 20: Setup
HOME Setup Smart TV Source TV guide Recordings SETUP Setup There are few options that offer user convenient&quick access to certain settings. Quick picture and sound settings Quick&simple setup of picture and sound settings. Search for channels Select either Update channels or Re-install channels. Follow the onscreen instructions for quick channel installation. -
Page 21: 3D Menu
Sharpness Adjust the image sharpness. The sharpness adjustment range is from 0 ~ 10. Filter and reduce noise in the video. Select your preferred reduction level from one of the Noise reduction following options: Off, Minimum, Medium, Maximum. MPEG artifact reduction Smoothen transitions and blurriness in the digital image. -
Page 22: Sound Menu
SOUND MENU Press HOME on TV remote control, then select Setup > TV settings > Sound. Press the middle button OK to access the sub-menus. To cycle through these sub-menus, use the navigation ring on TV remote control. Picture Picture Sound style Sound style Bass... -
Page 23: General Settings
GENERAL SETTINGS Press HOME on TV remote control, then select Setup > TV settings > General settings. Press the middle button OK to access the sub-menus. To cycle through these sub-menus, use the navigation ring on TV remote control. Picture Menu language Clock Sleep timer... -
Page 24: Channel Settings
CHANNEL SETTINGS To access the TV settings, press the HOME key on TV remote control, select Setup > Channel settings. Antenna connection Select the signal source from either Antenna or Cable. Digital: Reception test Search digital channel manually. Channel installation Copy the channel list to one of following options: Copy to USB, Copy to TV, Current Channel list copy version. -
Page 25: Set-Up
setting of the TV. To check which TV programs are available, look up the TV guide inside the app. Smart TV can only display one page at a time in full screen view. Some web pages may not display completely; features that require plug-ins may be unusable. Set-up Connect the TV to your home network, then configure Smart TV. -
Page 26: Source Menu
SOURCE MENU Source In Source menu, it is possible to view pictures, music, video from connected devices. This turns the TV into an MP3 player, picture viewer or video player, without the need for peripherals such as cameras, DVD players, etc. Press Source on the remote control to access the Source center, then select your preferred, connected device with the navigation ring on TV remote control. -
Page 27: Recordings
RECORDINGS Recordings User can record TV programs onto a USB hard drive when this TV receives program guides. User can record both current broadcasting programs and future programs. What you need USB hard drive with minimum capacity of 32GB and minimum trasfer speed of 30 Basic requirements megabits per sec USB 2.0 compatible hard drive... -
Page 28: Troubleshooting
Troubleshooting Condition Explanation / Solution No picture No picture Check the Power Saving settings. Make sure the power cord is connected securely. Turn on the power of the TV. Cannot receive any channels Check antenna/cable connections. Make sure the Cable setting is correct for your TV signal source. TV is locked to one channel Perform Auto Program to add receivable channels that are not present in the TV’s memory. -
Page 29: Dimensions & Specifications
Wireless network is not found devices. Make sure that the firewalls in your network allow access to the TV wireless connection. Dimensions & Specifications Model LE46D7840 LE50D7840 Panel size 1168.4 mm diagonal (46” viewable) 1270 mm diagonal (50” viewable) Resolution...
