21.5" LCD TV
Service
Service
Service
Description

Table of Contents............................................................1

Important Safety Notice...................................................2
Revision List.........................................................3
1. General Specification..................................................4
2. Operating Instructions............................................5
2.1 The Use of Remote Control...................................5
2.2 To Use the Menus................................................6
2.3 How to Connect................................................18
2.4 Front Panel Control Knobs..................................20
3. Input/Output Specification.......................................23
4. Mechanical Instructions.........................................24
5. Repair Flow Chart ..............................................27
6. PCB Layout ....................................................34
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
TABLE OF CONTENTS
SAFETY NOTICE
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
Page
Description
6.1 Main Board....................................................34
6.2 Power Board..................................................37
6.3 Key Board....................................................39
6.4 IR Board.......................................................39
7. Adjustment..............................................................40
8. Block Diagram........................................................41
9. Schematic Diagram..........................................42
9.1 Main Board....................................................42
9.2 Power Board..................................................54
9.3 Key Board.....................................................56
9.4 IR Board........................................................57
10. Exploded View..............................................58
11. BOM List......................................................60
1
AOC LE22A3520/61
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE22A3520/61 and is the answer not in the manual?

Questions and answers

Summary of Contents for AOC LE22A3520/61

  • Page 1 21.5″ LCD TV AOC LE22A3520/61 Service Service Service TABLE OF CONTENTS Description Page Description Page Table of Contents..……........…..1 6.1 Main Board…………..……………...…….……..34 Important Safety Notice........……..2 6.2 Power Board……...…………..….…….………..37 Revision List…………………………………………………3 6.3 Key Board…...…………………………………..39 1. General Specification......……...…..4 6.4 IR Board…...……………………………………..39 2. Operating Instructions………………...…….………..5 7.
  • Page 2: Important Safety Notice

    Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended.
  • Page 3: Revision List

    Revision List Version Release Date Revision Instructions Customer Model TPV Model Jun.13,2012 Initial release LE22A3520/61 E22B1KNCBQA1NN...
  • Page 4: General Specification

    1. General Specification Notas: • Designs and specifications are subject to change without notice. • This model may not be compatible with features and/or specifications that may be added in the future.
  • Page 5: Operating Instructions

    2. Operating Instructions 2.1 The Use of Remote Control...
  • Page 6: To Use The Menus

    2.2 To Use the Menus Picture Setting...
  • Page 7 Sound Setting Settings Menu...
  • Page 8 Channel Search...
  • Page 9 Manual search description 1. Select Channel Search menu. 2. Select Manual Search and press OK key or ► arrow key to get Manual search sub-menu...
  • Page 10 Channel Edit Menu In these case the shortcut key like Red key,Green key,Yellow key,Blue key action as below. Red key:To set the channel as user’s favoriate channel. Green key:To skip the channel and you will not find this channel by press ch+/- key to change channel. Yellow key:To lock the channel and user will get the channel only by entering the password.
  • Page 11 Other Adjustments...
  • Page 12 * Passwors Setting, TV Lock, Blue Screen functions are available only in TV mode. * Noise Reduction, DCR, DCC will be enable only when the Picture mode is Personal. * Press Red key on remote control to reset Blue screen, Sleep time, Zoom, Noise Reduction, DCR,DCC,HDMI/DVI Switch, Color System functions to the default settings.
  • Page 13 Sound and OSD...
  • Page 14 PC setting Note: * If the PC is connected to the TV and no signal has been input from the PC for more than 30 seconds, the TV enters the standby mode automatically. * This setting is only available in VGA source...
  • Page 15 Media Functions(USB) Viewing Photos...
  • Page 16 USB menu settings for Photo Slide show Press OK key to get following Menu setup shown above. 1. [Transition Effect] : Select the slide transition as None, Top To Bottom, Bottom To Top, Left To Right, Right To Left, Random. 2.
  • Page 17 Reading Text files Remarks: 1. USB interface of digital multimedia player is not all-purpose. So when some USB devices could not be recognized, the problem is usually not the performance failure but due to device driver. 2. Because USB devices and memory capability are different, the time needs for multimedia player to read information are also different.
  • Page 18: How To Connect

    2.3 How to Connect You can enjoy standard-definition and high-definition digital programming (if available in your area), along with standard-definition analog programming. It is strongly recommended that you connect the antenna/cable input using a 75-ohm coaxial cable to receive optimum picture quality. A 300- ohm twin lead cable can be easily affected by radio frequency interference, resulting in signal degradation.
  • Page 19: Connecting Earphone

    PC Connection Use the TV as a monitor for your PC shown below with the HD15 to HD15 connection. This TV can also be connected to a PC with DVI or HDMI output. • Connect the PC IN jack to the PC using the HD15- HD15 cable with ferrite core (analog RGB) and audio cable. •...
  • Page 20: Front Panel Control Knobs

    2.4 Front Panel Control Knobs...
  • Page 21 Description Item AV(Audio/Video Connect audio (L/R)/video output from an external device to these jacks ) Input For connecting the Composite Video signal of the TV to other display devices as their source Video Output signal. Connect a HDMI signal to HDMI port. The HDMI (High definition Multimedia Input) connector provides Non- compressed and fully digital audio/video data transmission between TV set and any HDMI audio/video devices, including the set top box, DVD player, Blue-ray player, A/V receiver HDMI Input...
  • Page 22 3. Input / Output Specification 3.1 RGB Signal Input 15 - Pin Color Display Signal Cable Pin No. Description Pin No. Description Red Video Green Video Sync Ground Blue Video Not Used Not Used Serial Data for DDC Ground H-Sync. Red Ground V-Sync.
  • Page 23 3.3 Compatible Mode Table Analog RGB Input Signal Timing VESA MODES Horizontal Vertical Nominal Sync Nominal Sync Nominal Frequency Polarity Freq. Polarity Pixel Mode Resolution (KHz) (Hz) Clock (MHz) 640x480@60Hz 31.469 59.940 25.175 800x600@56Hz 35.156 56.25 36.000 SVGA 800x600@60Hz 37.879 60.317 40.000 1024x768@60Hz...
  • Page 24: Mechanical Instructions

    4. Mechanical Instructions 1. Remove the screws to remove BASE. 2. Remove the screws to remove REAR COVER.
  • Page 25 3. Remove the screws to remove SPEAKERS, MAIN BOARD and POWER BOARD. 4. Remove the screws to remove BKT.
  • Page 26 Remove the screw to remove IR BOARD.
  • Page 27: Repair Flow Chart

    5. Repair Flow Chart 1. No power No power (LED “Off”) Check the AC input and Power “On” the power is “ON”? Power board Replace the power board output=5.2V? Check the IR board and LED Replace the IR board Replace the main board...
  • Page 28 2. Can’t start Can’t start (LED red) Replace the power board Power board output=12/16V? Replace the key board Check the power key is under control? Replace the IR board Check the IR receiver is normal? Replace the main board Replace the Power board...
  • Page 29 3. Abnormal display Abnormal Display Reset the source Check the source Enter factory mode to do “EEPROM initial”&“Reset” Replace the main board Check the main board Check the LVDS cable Replace the LVDS cable Check the panel Replace the panel...
  • Page 30 4. No display No display (No LED) Check TV is under control and power Replace the main board on/off by remote control and power key? Check the backlight is “On”? Check the LVDS cable Check the B/L signal is available? Reinsert or replace the LVDS cable Replace main board...
  • Page 31 5. Sound problem No sound or sound abnormal Check the audio source connection and the TV system are correct? Reinsert the audio cable or change the TV system Check the TV is muted, adjust the volume or enter the menu to reset? Enter factory mode to do “Reset”...
  • Page 32 6. Remote control malfunction Remote Control malfunction Check the remote control battery is Replace the battery not properly placed or no power? Use the other remote controls Replace the remote control Whether the IR board is Replace the IR board abnormal? Replace the main board...
  • Page 33 7. OSD is unstable or can’t work normally OSD is unstable or can’t work normally Key board connected properly? Reconnect the key board Replace the button function Buttons are OK? Replace the key board Key board is OK? Enter factory mode to do “Reset” Replace the main board...
  • Page 34: Pcb Layout

    6. PCB Layout 6.1 Main Board 715G4629M01000004K...
  • Page 37: Power Board

    6.2 Power Board 715G5309P0A001002S...
  • Page 39: Key Board

    6.3 Key Board 715G5569K01000004S 6.4 IR Board 715G5061R01000004M...
  • Page 40: Adjustment

    7. Adjustment (Take other model for example) ADC Adjustment 1. Factory Mode Turn on the TV. Press menu key and then press number key 1+9 +9+9+back. It will achieve the factory mode. 2. ADC Adjustment (It’s no need to adjust ADC.) (1) Enter into the factory mode :(same as the above-mentioned) (2) Select item “Source”: Ypbpr a.
  • Page 41: Block Diagram

    8. Block Diagram...
  • Page 42: Schematic Diagram

    9. Schematic Diagram 9.1 Main Board 715G4629M01000004K NC/CONN CN700 USB_5V Power +18V_AMP BL_ON1 BL_ON1 R1215 52.3K Vo = 0.8 * (1+ R739/R740) BL_PWM D12V FB700 BL_PWM R1214 V1 = 0.8 * (1+ 52.3/10) =4.984V D12V FB702 C770 1uF 25V C700 120R/6000mA V1 = 0.8 * (1+ 53.4/10) =5.072V 5V_USB...
  • Page 43 From DDR2 From HDMI From TUNER From LVDS TUN_IF+ S_DQ_IN[0:15] TUN_IF+ HDMI0_D2+ TUN_IF- HDMI0_D2+ TUN_IF- S_DQ_IN0 HDMI0_D2- TEDP HDMI0_D2- TEDP S_DQ_IN1 HDMI0_D1+ I2C_SCL TEDN S_DQ_IN2 HDMI0_D1+ HDMI0_D1- I2C_SCL I2C_SDA TEDN TECLKP HDMI0_D1- I2C_SDA TECLKP S_DQ_IN3 HDMI0_D0+ TECLKN HDMI0_D0+ TECLKN S_DQ_IN4 HDMI0_D0- TECP HDMI0_D0-...
  • Page 44 RP4000 22oHM 1/16W S_DQ_IN14 S_DQ14 S_DM1_IN S_DM1 From RTD268x S_DQ_IN9 S_DQ9 U4002 S_DQ_IN11 S_DQ11 S_DQ0 S_DA0 S_DQ_IN[0:15] [7] RP4001 S_DQ1 S_DA1 22oHM 1/16W S_DQ_IN0 S_DQ_IN12 S_DQ12 S_DQ2 S_DA2 S_DQ_IN1 S_DQ_IN6 S_DQ6 S_DQ3 S_DA3 S_DQ_IN2 S_DM0_IN S_DM0 S_DQ4 S_DA4 S_DQ_IN3 S_DQ_IN1 S_DQ1 S_DQ5 S_DA5...
  • Page 45 TO RTD268x CN101 AV1_CVBS+ R101 0R05 1/10W AV1_CVBS+ R102 AV1_CVBS+ VIN_A0- ZD101 C101 VIN_A0- AV1_IN_L MLVG0402 AV1_IN_L AV1_IN_R AV1_IN_R SH100 VIN_A0- RCA JACK AGND AGND AV2_CVBS+ AV1_IN_L R103 AV2_CVBS+ VIN_A1- 12KOHM +-5% 1/16W VIN_A1- C102 R104 AV2_IN_L 8.2K 1/10W AV2_IN_L AV2_IN_R 470pF 50V AV2_IN_R...
  • Page 46 YPbPr1 Video in R113 R114 TO RTD268x 0R05 1/10W 100R 1/10W 5% ZD102 Y 1+ MLVG0402 R115 C107 PB1+ PB1+ PR1+ 5PF 50V PR1+ VIN_Y0- VIN_Y0- SH102 Y PBPR1_IN_L VIN_Y0- R116 R117 YPBPR1_IN_L Y PBPR1_IN_R 0R05 1/10W 100R 1/10W 5% YPBPR1_IN_R AGND R118...
  • Page 47 D100 D5V_STB TO RTD268x BAT54C VGA_CON5V VGA_B+ VGA_B+ VGA_B- D5V_STB VGA_B- A3V3 VGA_G+ VGA_G+ VGA_G- VGA_G- VGA_R+ VGA_R+ VGA_R- VGA_5V VGA_R- R205 VGA_HS VGA_HS VGA_VS R100 R151 4K7 1/16W 5% VGA_VS 4K7 1/16W 5% Q301 VGA_TX0 4K7 1/16W 5% 2N7002 VGA_DDC_SCL D5V_STB VGA_DDC_SDA...
  • Page 48 DGND CN500 CN501 DGND CN502 SHLD5 SHLD5 SHLD0 HDMI2_D2+ SHLD4 SHLD4 TMDSD2+ SHLD3 SHLD3 DSHLD0 SHLD2 HDMI2_D2- SHLD2 SHLD2 TMDSD2- HDMI2_D1+ SHLD1 SHLD1 TMDSD1+ SHLD_GND2 SHLD_GND2 DSHLD1 HDMI2_D1- SHLD_GND1 SHLD_GND1 TMDSD1- HDMI2_D0+ TMDSD0+ DDC_GND DDC_GND DSHLD2 HDMI2_D0- CSHLD0 CSHLD0 TMDSD0- HDMI2_CLK+ DSHLD2 DSHLD2...
  • Page 49 RTD268x<--> +18V_AMP RF_AGC RF_AGC TUN_IF+ TUN_IF+ TUN_IF- R177 FB102 FB103 TUN_IF- I2C_SCL IF_12V 300R NC/120R/6000mA I2C_SCL I2C_SDA NC/120R/6000mA I2C_SDA R178 300R U104 NC/BA17809FP-E2 R179 R180 C147 C130 C131 6.8kOHM +-5% 1/10W L101 680OHM +-5% 1/10W IF_12V 1uF 25V 10nF 50V 0.82uH C129 10uF16V...
  • Page 50 D3V3 D3V3 R4044 LEDR R139 4.7K Q4002 4K7 1/16W 5% R140 4.7K PMBS3906 R141 R142 LED_R R4046 KEY _SDA D3V3 200OHM1/16W KEY _SCL 100R 1/16W 5% D3V3 100R 1/16W 5% CN4003 R4083 4.7K ZD4000 LIGHT_SENSOR ADC1 LSADC0 C4110 Q4003 R4047 LEDG 100N 16V ZD4001...
  • Page 51 To RTD268x DM3V3 AOUT_L AOUT_L AOUT_R AOUT_R U600 AMP_STBY AMP_STBY Thermal Pad PVDD PVCCL AMP_STBY R622 Q603 C612 C623 PMBS3904 0.1uF 50V 1nF 50V C605 100UF 35V 10K 1/10W FAULTZ PVCCL LOUT+ LINP BSPL DM3V3 C624 L604 220NF 25V 22uH C625 C628 R614...
  • Page 52 D_5V From RTD268x FB101 CVBS_OUT CVBS_OUT 220R/2000mA C144 C149 SPDIF_OUT 100N 16V 220uF 16V SPDIF_OUT R204 R209 75K 1/16W 330OHM 1/10W AGND AGND Q103 PMBS3906 R111 0R05 1/10W Q102 CVBS_OUT C145 PMBS3904 C150 10uF 16V R210 R207 CN107 C146 NC 82pF 50V R206 75R 1% 68KOHM 1/16W +/-5%...
  • Page 53 TEAN RP4010 TEAN_1 8-bit LVDS TEAP TEAP_1 FromRTD268x TEBN TEBN_1 TEBP TEBP_1 22oHM 1/16W PANEL_VCC TEDP TECN TECN_1 TEDP TEDN TECP TECP_1 TEDN TECLKP TECLKN TECLKN_1 TECLKP TECLKN TECLKP TECLKP_1 TECLKN TECP RP4011 22oHM 1/16W TECP DGND D5V_STB TECN TECN TEBP TEDN TEDN_1...
  • Page 54 9.2 Power Board 715G5309P0A001002S FB9908 BD9101 FB9906 BEAD GBL408-C BBY(NC) BEAD CN9101 D9101 ON/OFF T9101 MBRF1560CT L9101 C9102A C9101 POWER X'FMR 3.5uH +5.2V C9120 47UF 450V C9102 C9101A 13*40 13*45 C9125 FB9902 47UF 450V 13*45 2.2nF 630V BEAD 13*40 FB9907 C9111 +12_16V BEAD...
  • Page 55 FB9905 FB9904 L8102 BEAD D8101 VLED+ 47UH SR510-22 JUMPER +12_16V C8101 C8102 C8113 470UF 25V C8105 C8106 47UF 100V 47UF 100V 100N 50V 10*12 10*12 10*12 R8116 Q8101 AO4482L C8115 100PF R8115 51K 1/4W C8107 1NF 500V R8104 R8117 C8111 33 OHM 3.6K 1% 1/8W IC8501...
  • Page 56 9.3 Key Board 715G5569K01000004S SW01 VOL+ 2.48V~2.72V TACT SW FWRD H1.5MM 7K5 1/8W +/-1% SW02 VOL- 2.04V~2.22V TACT SW FWRD H1.5MM 2K7 +-1% 1/8W SW03 1.58V~1.79V TACT SW FWRD H1.5MM 1K8 +/-1% 1/8W CN01 SW04 PWR-SW 1.24~1.45V FUNC_KEY TACT SW FWRD H1.5MM CONN 1K 1/8W 1% SW05...
  • Page 57: Ir Board

    9.4 IR Board 715G5061R01000004M 33G8032 4F HR R002 LED1 Top View NC 220 OHM 1/10W NC 264-10SURC/S530-A3 CN01 U001 16 mm VOUT R001 15K 1/10W Dip LED C001 IRM-3640CF45 CONN 0.1uF 50V 37mm T P V ( Top Victory Electronics Co .
  • Page 58: Exploded View

    10. Exploded View...
  • Page 59 Item Description BEZEL PANEL BKT_CONNECTOR SGCC POWER BOARD MAIN BOARD Item Part No. Description BKT_IO 0Q1G1030 6120 HX SCREW (FOR IR BOARD) BKT_MID 0M1G1730 8120 RA SCREW(FOR POWER BOARD) BASE 0M1G1730 8120 RA SCREW(FOR MAIN BOARD) STAND 0Q1G 930 8 47 HX SCREW (FOR BKT_MID) REAR_COVER 0Q1G 930 8 47 HX...
  • Page 60: Bom List

    705TQ949001 COMSUPTIVE ASS'Y-A4 708GCA120CPQ01 AOC 40(1680 AP) 050G 600 2 HANDLE1 050G 600 3 HANDLE2 Q52G 1185 98 MIDDLE CARTON TAPE FOR AOC 72MM E750 750GBV215DAT16N000 LCD TPM215HW01-DAT01 C1A WH TPV 756TXBCB0KC025000Q MAIN BOARD-CBPFCK1DX7Q SMTF-U4003 100TARVI005C2X MCU ASSY-056G2233 50 P11G002310100000PJ...
  • Page 61 X44GCA1261501A ARTWORK CARTON --AOC LE22A3520 092GB1JX1A3EGC BATTERY 1.5V LR03 AAA£¨LR03£© alkali Q45G2010M0101A pe bag for manual X41G22MV61506A MANUAL 040G 58162435A PN LABEL FOR Manual PE Bag Q40G 581689 4B SN LABEL(58x35mm) Q40G0001954 1A S/N LABEL X40G0001624 2A Label for screw pe bag...
  • Page 62 U4000 056G 562F32 SCALER RTD2684S-GR LQFP-256 U700 056G 563 93 IC G9084T43U TO-252 U700 056G 563 93 C LDO G9084PT43U 5A ADJ TO-252 U705 056G 563323 DC/DC AOZ1242AI 3A SO-8 U702 056G 563344 DC/DC AT1529F11U 3.2A SOP-8 U704 056G 563344 DC/DC AT1529F11U 3.2A SOP-8 U103 056G 563519...
  • Page 63 RP4006 061G 1265108JY RST CHIP NET 51R 5% 1/16W 8P4R RP4009 061G 1265108JY RST CHIP NET 51R 5% 1/16W 8P4R RP4008 061G 1265108JY RST CHIP NET 51R 5% 1/16W 8P4R RP4007 061G 1265108JY RST CHIP NET 51R 5% 1/16W 8P4R R4052 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN...
  • Page 64 R4060 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA R181 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN R518 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN R514 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN R4024 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN R4027...
  • Page 65 R121 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R4017 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R162 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R157 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R123 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R4007 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA...
  • Page 66 R519 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO R502 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO R711 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA R4066 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA R509 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA R4075 061G0603103 JF...
  • Page 67 R4082 061G0603472 JI RST 0603 4.7K 5% 1/10W TA-I R4083 061G0603472 JI RST 0603 4.7K 5% 1/10W TA-I R4062 061G0603472 JT RST CHIP 4K7 1/10W 5% TZAI YUAN R4076 061G0603472 JT RST CHIP 4K7 1/10W 5% TZAI YUAN R718 061G0603472 JT RST CHIP 4K7 1/10W 5% TZAI YUAN R4064 061G0603472 JT...
  • Page 68 C4087 065G040210412K CAP CHIP 0402 100nF K 16V X7R C4068 065G040210412K CAP CHIP 0402 100nF K 16V X7R C4118 065G040210412K CAP CHIP 0402 100nF K 16V X7R C4079 065G040210412K CAP CHIP 0402 100nF K 16V X7R C4095 065G040210412K CAP CHIP 0402 100nF K 16V X7R C4063 065G040210412K CAP CHIP 0402 100nF K 16V X7R...
  • Page 69 C127 065G040247131J CAP CHIP 0402 470PF J 50V NPO C110 065G040247131J CAP CHIP 0402 470PF J 50V NPO C105 065G040247131J CAP CHIP 0402 470PF J 50V NPO C104 065G040247131J CAP CHIP 0402 470PF J 50V NPO C103 065G040247131J CAP CHIP 0402 470PF J 50V NPO C111 065G040247131J CAP CHIP 0402 470PF J 50V NPO...
  • Page 70 C760 065G060310432K CAP 0603 100NF 10% 50V X7R C125 065G060310432K CAP 0603 100NF 10% 50V X7R C138 065G060310432K CAP 0603 100NF 10% 50V X7R C703 065G060310432K CAP 0603 100NF 10% 50V X7R C128 065G060310432K CAP 0603 100NF 10% 50V X7R C713 065G060310432K CAP CHIP 0603 0.1UF K 50V X7R...
  • Page 71 C4039 065G060347332K CAP CHIP 0603 47N 50V X7R +/-10% C4034 065G060347332K CAP CHIP 0603 47N 50V X7R +/-10% C4027 065G060347332K CAP CHIP 0603 47N 50V X7R +/-10% C4035 065G060347332K CAP CHIP 0603 47N 50V X7R +/-10% C4120 065G060347332K CAP CHIP 0603 47N 50V X7R +/-10% C4025 065G060347332K CAP CHIP 0603 47N 50V X7R +/-10%...
  • Page 72 FB4019 071G 56G301 EA CHIP BEAD 0805 300R 25% 4000mA FB4015 071G 56G301 EA CHIP BEAD 0805 300R 25% 4000mA FB4020 071G 56G301 EA CHIP BEAD 0805 300R 25% 4000mA FB4029 071G 56G301 EA CHIP BEAD 0805 300R 25% 4000mA FB4001 071G 56G301 EA CHIP BEAD 0805 300R 25% 4000mA...
  • Page 73 FB4003 071G 59G301 TA CHIP BEAD 300OHM 200mA FCM1608KF-301T02 FB4007 071G 59G301 TA CHIP BEAD 300OHM 200mA FCM1608KF-301T02 L100 073G 63229 TA CHIP INDUCROR 2.2uH 10% FCI1608F-2R2K L102 073G 6333810T CHIP INDUCTOR 0.33uH 10% L103 073G 12610010M CHIP INDUCTOR 1206 10UH 10% 25mA 1.0R L704 073G253S 31 H SMD CHOKE 15.0uH...
  • Page 74 X85T8006101 SHIELD Q36G 600 18111 ZA NON-WOVEN FABRIC Cloth 0.25 0.3 PLTVCE514XXG1Q ADAPTER BOARD 040G 45762412B CBPC LABEL 009G6005 1 GND TERMINAL IC9102 056G 139 3A PC123Y22FZOF SHARP RV9901 061G 46561 WB VARISTOR 560V 10% 14 NR9901 061G 58159LAW 5A NTCR 1.5R 15% 2.4W SCK101R55LMY502 NR9902 061G 58159LAW 5A...
  • Page 75 R9111 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA R8106 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA R9114 061G0805104 JT RST CHIPR 100KOHM +- 5% 1/8W TZAI YUAN R8121 061G08051309FI RST 0805 13R 1% 1/8W R8122 061G08051309FI RST 0805 13R 1% 1/8W R8123 061G08051309FI...
  • Page 76 C8110 065G080510231J CAP 0805 1NF 5% 50V NPO C8114 065G080510332K CAP CHIP 0805 10N 50V X7R +/-10% C8108 065G080510332K CAP CHIP 0805 10N 50V X7R +/-10% C9104 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C9110 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C9112 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10%...
  • Page 77 J915 095G 90 23 JUMP WIRE - - D9106 093G 6451652T 1N4148 IC9103 056G 158 10 T DC/DC AS431AZTR-E1 150MA 40V TO-92 FB9907 071G 55 26 H BEAD 3.5*6.0*0.8 127R 25% BF-I35060R-796 J925 095G 90 23 JUMP WIRE - - J914 095G 90 23 JUMP WIRE - -...
  • Page 78 C9103 363G213K2224TA CAP DMPE 2.2nF 10% 630V RSBPC1220SH00K C8102 067G 5154709HT EC 47UF 20% 100V 10*12 X85T8026101 SHIELD_IC M00109 0Q1G1030 6120 HX SCREW 3x8 ECN4003 395G801414WY44 HARNESS 14P-5P+4P 370/450mm IRPFBXB7Q IR BOARD LED1 081G 2 4 EL LED Red 264-10SURC/S530-A3 U001 356G0927911 IR RECEIVER KSM-603TM2M.
