3" Composite Air Cut-off Tool
Item 68832
Visit our website at: http://www.harborfreight.com
Email our technical support at: tech@harborfreight.com
Read this manual before using this product.
Failure to do so can result in serious injury.
SAVE ThIS mAnuAl.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1‑800‑444‑3353 as soon as possible.
©
®
Copyright
2011 by Harbor Freight Tools
. All rights reserved. No portion of this document
or any artwork contained herein may be reproduced in any shape or form without the express
written consent of Harbor Freight Tools. Diagrams within this document may not be drawn
proportionally. Due to continuing improvements, actual product may differ slightly from the
product described herein. Tools required for assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 68832 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CentralPneumatic 68832

  • Page 1 3” Composite Air Cut-off Tool Item 68832 Visit our website at: http://www.harborfreight.com Email our technical support at: tech@harborfreight.com Read this manual before using this product. Failure to do so can result in serious injury. SAVE ThIS mAnuAl. When unpacking, make sure that the product is intact and undamaged.
  • Page 2: Important Safety Instructions

    Distractions are able to result in the loss of control of the tool. nOTICE is used to address practices not related to personal injury. Page 2 For technical questions, please call 1-800-444-3353. SKU 68832...
  • Page 3: Personal Safety

    Prolonged exposure to or turn the switch to its off position before leaving the work area. SKU 68832 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4: Air Source

    Pounds per square inch of pressure use only the lubricants supplied with the tool or specified ft-lb Foot‑pounds of torque by the manufacturer. Chart continued in next column. Page 4 For technical questions, please call 1-800-444-3353. SKU 68832...
  • Page 5: Specific Safety Instructions

    [to the State parts can grab the surface and of California] to cause cancer, birth pull the tool out of your control. defects or other reproductive harm. SKU 68832 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6: Vibration Precautions

    (while still keeping safe control of it). Let the tool do the work. To reduce vibration, maintain tool as explained in this manual. If abnormal vibration occurs, stop immediately. SAVE ThESE InSTRuCTIOnS. Page 6 For technical questions, please call 1-800-444-3353. SKU 68832...
  • Page 7: Specifications

    *Maximum speed at stated maximum air pressure. Excess air pressure is hazardous and may cause the tool to exceed stated maximum speed. Components and Controls Throttle Safety lock Air Inlet Adjustable Air Regulator Adjustable Exhaust Ring Adjustable Swivel Guard SKU 68832 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8: Air Supply

    Tool Oil to the airline connection before pressure, and release the throttle operation. Add a few more drops to prevent accidental operation. after each hour of continual use. Page 8 For technical questions, please call 1-800-444-3353. SKU 68832...
  • Page 9 Residual air pressure should not be present after the tool is disconnected from the air supply. However, it is a good safety measure to attempt to discharge the tool in a safe fashion after disconnecting to ensure that the tool is disconnected and unpowered. SKU 68832 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10 Page 10 For technical questions, please call 1-800-444-3353. SKU 68832...
  • Page 11: Tool Set Up

    Designate a work area that is clean Socket Head Screw and Flange and well‑lit. The work area must with the Hex Key Wrench not allow access by children or pets to prevent distraction and injury. SKU 68832 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12 Throttle to vary the speed of the tool. Use only enough speed as needed to cut the workpiece. Slowly and carefully place the edge of the cutting wheel onto the surface of the workpiece. Page 12 For technical questions, please call 1-800-444-3353. SKU 68832...
  • Page 13: Cleaning, Maintenance, And Lubrication

    AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 68832 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14: Troubleshooting

    Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect air supply before service. Available Accessories Description Function Aluminum Oxide Cut‑off Wheels for metal cutting Silicon Carbide Cut‑off Wheels for masonry cutting Page 14 For technical questions, please call 1-800-444-3353. SKU 68832...
  • Page 15 O‑Ring, Φ13x9x2 Washer Muffle Guard O‑Ring, Φ8x4.8x1.6 C‑Ring O‑Ring, Φ10.3x6.7x1.8 Flange Valve Socket Head Screw, M6x10 Valve Spring Hex Key Wrench O‑Ring, Φ16x11x2.5 Spanner Valve Plug Gasket Cutting Disc sold separately SKU 68832 For technical questions, please call 1-800-444-3353. Page 15...
  • Page 16 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
