Adjustment of Screen

Function Definition
Audio
Color
Language
Settings
Input Source Analog
(Optiona ) l
Direct
Primary
Secondary
Directory
Directory
Brightness
Contrast
Clock
Phase
H. Position
V. Position
Sharpness
Volume
Mute
9300K
7500K
6500K
User/Red
User/Green
User/Blue
English
Français
Italiano
Deutsch
Español
日本語
简体中文
繁體中文
OSD Timeout Adjust OSD display time setting.
OSD Position Move OSD display position to any one of the following 5
Auto Setting
Recall
Digital
You can skip the Menu pages and display an adjustment scale directly by using the
following button operations:
Brightness: Press the Brightness Button when the Menu is not displayed.
Contrast: Press the Contrast Button when the Menu is not displayed.
Auto Setting: Press the Auto Button when the Menu is not displayed.
Turbo: Press the Input Button when the Menu is not displayed.
Pct: Picture Mode (High brightness)
Text: Text Mode (Normal)
Eco Economy (Brightness of back-light is reduced)
Changing to a lower brightness mode can lessen eye fatigue.
Change from Picture Mode to Text Mode when working with text.
Change from Text Mode to Economy Modes when viewing the screen for long
periods.
Description
Adjust the brightness of the screen.
Adjust the contrast of the image.
Adjust the clock pulse of the image.
Adjust the focus of the image.
Move the image left and right on the screen.
Move the image up and down on the screen.
Adjust the picture sharpness of lower resolutions.
Adjust the volume of the audio.
Set up the audio to be mute on or off.
Set up the color temp. to be 9300K white color.
Set up the color temp. to be 7500K white color.
Set up the color temp. to be 6500K white color.
Adjust red/green/blue gain.
Select the language you want.
positions within the overall screen.
1
4
Set up to adjust clock, phase and positions automatically.
Restore to factory settings
Select Analog input source:
Select Digital input source:
7
2
3
5
