CanyCom S25A Operator's Manual page 62

3670M-0505-030E
HST Fluid Filler Caps
3670M-0505-040E
3670M-0505-050E
3670M-0505-060E
Maintenance
Fluid Level Window
Drain Plug
Line Filter
3. Visually inspect oil level window.
4. If the level is low, open filler cap and fill fluid.
Put filler cap back in place.
5. Start and run engine for a while to circulate
the fluid. Then, stop engine.
6. Visually inspect fluid level to be within the
fluid level window.
7. Close engine hood.
Changing
1. Park machine on the level ground.
2. Have an appropriate oil drain pan.
3. Remove drain plug to drain fluid.
4. Install drain plug.
NOTE
• Replace both line filter cartridge and
suction filter element when hydraulic fluid
is changed.
6. Open engine hood.
7. Remove line filter cartridge with the oil filter
wrench.
8. Have a new line filter cartridge ready. Apply
clean hydraulic fluid (oil) on the cartridge oil
seal evenly.
-53-
5
