Description of symbols
Refers to a section within a chapter that contains important information and safety notes
observed.
Indicates that the section is continued on the next page.
Indicates the end of a section.
Indicates situations in which the vehicle must be stopped as quickly as possible.
The symbol indicates a registered trademark. However, the absence of this symbol does not constitute a waiver of the
®
rights concerning any term.
 →
 
Symbols like these refer you to warnings within the same section or on a given page. They draw your attention to
 →
 
possible risks of accident or injury and explain how they can be avoided.
 →
 
 →
 
Cross reference to potential risks of damage to property in the same section or on the page specified.
DANGER
Texts with this symbol indicate dangerous situations which will lead to fatal or severe injuries if you do not observe the warning.
WARNING
Texts with this symbol indicate dangerous situations which could lead to fatal or severe injuries if you do not observe the warning.
CAUTION
Texts with this symbol indicate dangerous situations which could lead to slight or severe injuries if you do not observe the warning.
NOTICE
Texts with this symbol indicate situations which could cause vehicle damage if you do not observe the warning.
  Texts with this symbol contain additional information on the protection of the environment.
Texts with this symbol contain additional information.
