Buderus Logano G334 X Instructions Manual

High altitude conversion gas-fired boiler
Hide thumbs Also See for Logano G334 X:
Table of Contents

Advertisement

Quick Links

See also: User Manual
6304 2382 – 2 012/11 US/CA
Instructions for High Altitude
Conversion
Logano G334 X gas-fired boiler
This conversion kit and the accompanying instructions are for conversion of
G334 X gas-fired boilers for operation at altitudes above 8500 feet.
Required Sealevel Input Rates of 0-8500 feet
G334 X-73
G334 X-92
301 MBtu/hr
387 MBtu/hr
WARNING!
This conversion kit is intended for use by a
qualified service company only as
specified by the manufacturer's
instructions and the current applicable
rules and regulations of the local
authorities and the regulations of NFPA54,
CAN/CGA B149.1 and 2, Installation
Code, must also be observed. If these
instructions are not followed exactly, a fire,
explosion or release of carbon monoxide
may occur with serious property damage
or loss of life and serious injury. The
heating contractor is liable for correct
conversion of the heating system with this
conversion kit.
WARNING!
Please use the enclosed instructions for
conversion from natural gas to propane.
Note: Please keep these instructions for future reference.
Please read carefully before conversion
G334 X-116
G334 X-132
476 MBtu/hr
541 MBtu/hr
For heating engineers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Logano G334 X and is the answer not in the manual?

Questions and answers

Related Manuals for Buderus Logano G334 X

Summary of Contents for Buderus Logano G334 X

  • Page 1 For heating engineers Instructions for High Altitude Conversion Logano G334 X gas-fired boiler This conversion kit and the accompanying instructions are for conversion of G334 X gas-fired boilers for operation at altitudes above 8500 feet. Required Sealevel Input Rates of 0-8500 feet...

  • Page 2: Table Of Contents

    Contents Safety ........... . . 3 1.1 Correct use .

  • Page 3: Safety

    Safety Safety Observe these instructions for your safety. Please observe these notes RISK TO LIFE Correct use from explosion of flammable gases. The conversion kit is for conversion of the G334 X gas- z Never work on gas lines unless you are WARNING! fired boiler for operation at altitudes above 8500 feet.

  • Page 4: Conversion Of The Boiler At Altitudes Over 8500 Feet

    Conversion of the boiler at altitudes over 8500 feet Conversion of the boiler at altitudes over 8500 feet Read the instructions before conversion for your safety. RISK TO LIFE due to not observing the attached conversion instructions. WARNING! z If you wish to convert the boiler for operation with propane, the conversion from natural gas to propane must be carried out first as specified by the...
  • Page 5 Conversion of the boiler at altitudes over 8500 feet 4. Turn gas valve ON/OFF button clockwise to OFF position. Do not use force. RISK TO LIFE from explosion of flammable gases. z Wait five (5) minutes until all gas WARNING! residues have dissipated.
  • Page 6 Conversion of the boiler at altitudes over 8500 feet 11. Unscrew retaining nuts on burner plate and pull gas burner straight out. 12. When removing the burner make sure that the spacers remain on the studs. 13. Install the new main gas orifices and copper gasket. Check with Î...
  • Page 7 Conversion of the boiler at altitudes over 8500 feet Carrying out leak test USER NOTE The boiler has two gas valves. Make all measurements and adjustments on both gas valves. 22. Open gas valve in the gas line. SYSTEM DAMAGE due to short-circuit.

  • Page 8: Start-Up Instructions

    Start-up instructions Start-up instructions Read the instructions before start-up for your safety. RISK TO LIFE due to not observing the start-up instructions and resulting incorrect WARNING! operation. z If these instructions are not followed exactly, a fire or explosion may be caused with serious property damage or loss of life or serious injury.

  • Page 9: Making Boiler Ready For Operation

    Start-up instructions Making boiler ready for operation STOP! First read the safety instructions on Î page 8 of this manual. 1. Carry out leak test (Î page 7). Wait five (5) minutes until all gas residues have dissipated. Finally check whether there is any smell of gas, including at floor level.

  • Page 10: Then Carry Out Start-Up Procedures

    Start-up instructions 4.1.2 Placing heating system with Logamatic 2107 (accessory) in operation The boiler is fully functional with the factory-installed aquastat. The Logamatic 2107 control can also be installed in addition to the factory-installed aquastat. Switch on the heating system with the ON/OFF switch on the control.
  • Page 11 Start-up instructions 8. Turn gas valve ON/OFF switch counterclockwise to ON position. 9. The automatic igniter must generate sparks towards the pilot burner. The pilot flame must appear and then ignite the main burner. If the main burner does not ignite, close the gas valve. Disconnect heating system from the power supply and inform your customer service technician or gas company.
  • Page 12 Start-up instructions 15. Observe pilot flame through the sight glass (Î Fig. 8, page 10) in the burner housing. 16. The flame must envelope the flame guard 1/2 to 1 1/2 inches. If this is the case continue with step 20. 17.
  • Page 13 Start-up instructions 25. Turn gas valve ON/OFF button clockwise to OFF position. 26. Close main gas valve. 27. Disconnect heating system from the power supply and set the thermostat to the lowest setting. 28. Remove pressure measuring nipple and pressure gauge for measuring gas supply pressure and manifold pressure from the gas valve and close the openings with the screw plugs.
  • Page 14 Notes We reserve the right to make any changes due to technical modifications. Conversion instructions for G334 X gas-fired boiler conversion kit - High altitudes • Issue 2 012/11...
  • Page 15 Notes We reserve the right to make any changes due to technical modifications. Conversion instructions for G334 X gas-fired boiler conversion kit - High altitudes • Issue 2 012/11...
