Connecting Battery Cables

WARNING:
• Never allow any of your tools and/or battery cable(s) to contact both battery terminal(s)/ post(s) at the
same time. An electrical short may occur and serious personal injury or damage may occur.
•
The use of rubber gloves and chemical goggles is recommended when working with batteries.
CAUTION:
When connecting the battery cables to the battery (s), the battery cable(s) MUST be connected to the battery
terminal(s)/post(s) depending on battery type. Always check the battery top for POSITIVE (+) and NEGATIVE
(-) marking symbols before connecting the battery cables.
1. Connect battery cable(s) to battery (s) terminal(s)/post(s) as follows.
•
Negative (-) BLACK battery cable to NEGATIVE (-) battery terminal/post.
•
Positive (+) RED battery cable to POSITIVE (+) battery terminal/post.
2. Secure the battery cable(s)/ring terminal(s) to the battery terminal(s)/post(s), BLACK to NEGATIVE (-) and
RED to POSITIVE (+), with the provided M6 hex screw, hex locknut and washer. Securely tighten.
3. Verify all battery cable(s)/ring terminal(s) are correctly installed and securely tightened.
4. Slide terminal cap(s) onto battery clamps / terminals.
Reassemble the battery box and install into the wheelchair.
5.
NOTE:
New battery(s) must be fully charged before using; otherwise the life of the battery (s) will be reduced.
6. If necessary, charge the battery (s). Refer to section 8.5 'Batteries and Charging'.
