4-7. Long Card Guide

To reach into the inside front of the chassis, you may want to remove the

long card guide first. Press the plastic clips with a screwdriver as shown.

The standard system speaker mounts in the chassis as shown here. To re-

move the speaker, press the metal clip (or pry from the front of the chassis)

with a screwdriver and lift the speaker upward.

IV. Hardware Setup

AP200 Hardware Reference Guide

Press the clips with a

screwdriver to release.

Press the clip (or pry from

the front) with a screwdriver

to release.
