Removing the Front & Top Panels
Before removing the front panel, the top panel must be unscrewed and re-
moved. Lean the front panel over the edge of a table or book. Reach your
fingers up into the front panel and pull the front panel away from the chassis.
Removing the Front Panel

Device Bay Covers

With the front panel removed, the device bay covers can be removed or installed.
Device Bay Removal Procedure:
1. With your thumb, push the tab outward against the side of the front panel.
2. With your other hand, push the device cage cover inward from the front side.
Front Panel Backside
18
IV. Hardware Setup
AP200 Hardware Reference Guide
Four of your fingers should fit
behind the front panel.
Device Bay Cover Tab
