- Page 1 MPS-500 USB e-drum set assembly instructions...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 17.07.2015, ID: 277656 (V2)
- Page 3 Table of contents Table of contents Safety instructions.......................................... 4 Contents of package........................................5 Assembly.............................................. 6 Protecting the environment....................................11 MPS-500 USB...
- Page 4 Safety instructions Safety instructions DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices.
- Page 5 Contents of package Contents of package Before you assemble your kit, make sure the contents of package is complete according to the following list. Millenium MPS-500 e-drum set Millenium MPS-500 e-drum module Pads: 1 × 8" snare / stereo 3 × 8" tom / mono 1 ×...
- Page 6 Assembly Assembly Overview Loosen the wing nuts on the holder clamps before inserting the tubes. Mount the various elements in the specified sequence. The positions of the pads, cymbals, etc. are shown in the illustration below. Setting up the rack CAUTION! Danger of cuts on hands and fingers When plugging the connections, take care for sharp edges on the metal pipes, screws etc.
- Page 7 Insert the crash pad, ride pad and hi-hat pad supports into the respective holder clamps on the rack. Secure the supports at the desired vertical position using the retaining screws. Loosen the retaining screws at the support joints and orient the supports so as to match your preferred playing position. Then re-tighten the retaining screws. MPS-500 USB...
- Page 8 Assembly Mounting pads on the rack Attach the supplied L-pieces to the pads. First, tighten the wing nuts on the pads hand-tight. Then slide the plastic ends of the L-pieces up to the stop into the designated terminals on the rack. Align the pads on the rack to meet your needs, then tighten the wing nuts of the pad brackets and the bolts of the pad terminals on the rack evenly.
- Page 9 Snap the two metal rods into the holes provided on the frame of the pedal. Place the beater into the hole provided on the rotary head of the kick drum pedal and tighten the clamp with the drum key firmly. MPS-500 USB...
- Page 10 Assembly Bass drum and hi-hat Position the bass drum pad centred under the rack. Position the bass drum pedal centred in front of the pad. Place the hi-hat pedal to the left of the bass drum pedal. Set-up and cabling Set up the rack, the pads and the cymbals according to your needs.
- Page 11 Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. MPS-500 USB...
- Page 12 Notes e-drum set...
- Page 13 Notes MPS-500 USB...
- Page 14 Notes e-drum set...
