Related Manuals for Wine Corner CI140CF
Summary of Contents for Wine Corner CI140CF
- Page 1 USER MANUAL CI140CF - CI140IX - CI141CF - CI141IX D E F Y I N G C O N V E N T I O N...
- Page 2 BUILT-IN AIR-CONDITIONED CELLARS Thank you for choosing our product! We welcome you into the ever increasing circle of people who are happy to own an IP product. We hope you will get the maximum satisfaction from this air-conditioned cellar, which has been specifically designed to preserve and serve wine.
-
Page 3: Table Of Contents
CONTENTS 1. Unit Performances and Features Page 1 2. Checking the Unit on Delivery Page 1 3. Cleaning and Positioning Accessories Page 1 4. Connection and Installation Page 2-3 5. Power Consumption Page 3 6. Temperature Settlng Page 4 7. Storage Page 5 8. -
Page 4: Unit Performances And Features
BUILT-IN SINGLE-TEMPERATURE AIR-CONDITIONED CELLARS GENERAL INSTRUCTIONS FOR USE UNIT PERFORMANCES AND FEATURES This unit has been designed to recreate the ideal conditions of a good natural cellar. In order to recreate such a peculiar atmosphere, IP uses a double automatic "warm/cold" circuit ensuring that the specified temperature is maintained inside the cellar. -
Page 5: Connection And Installation
CONNECTION AND INSTALLATION The cabinet must be placed on a level surface: this will ensure that the cabinet door seals and closes properly and the motor can run efficiently and quietly. If the floor is uneven then the cabinet legs can be adjusted (front and rear) to help level the unit. - Page 6 Make sure that the mains electric is compatible with the voltage ratings on the plate which is located at the back of the unit. A +/- of 6% tolerance is allowed. It is necessary to check the voltage value during the running of the unit, as you should take into account that a lower voltage than the tolerance allowed may also cause damage to the compressor motor.
-
Page 7: Power Consumption
POWER CONSUMPTION In order to keep the power consumption as low as possible the cabinet should NOT be placed in direct sunlight, next to a direct heat source (radiators, cookers, fires etc) or placed in an environment with excessive humidity TEMPERATURE SETTING SYMBOLS 1) ON/OFF SWITCH... -
Page 8: Storage
Your cellar is provided with an automatic defrosting system. If for any reason manual defrosting is required, press and hold down button 10 for a few seconds and the refrigeration will be interrupted for ten minutes: the pilot light (9) will flash. Once the 10 minute interval has passed, the cellar will resume its normal operation at the previously programmed temperatures. - Page 10 CI 140 IX Model with stainless steel door and C 141 Model with glass door To change which way the door is hinged, follow these instruction: - Gently lay the cellar on its back; - Remove the lower hinge by unscrewing the 2 screws; - Lift the door to remove it from the upper hinge pin;...
-
Page 11: Support
SUPPORT Please Note: Any problems that may arise are due to simple basic faults or a fault with the electrical supply, therefore these faults are usually very easy to rectify on site by an electrician or even by the customer. If the cellar is not working: - If the display (6) is not lit even after pressing the ON/OFF push-button, check that: - the plug is properly inserted in the... -
Page 12: Maintenance And Cleaning
MAINTENANCE AND CLEANING The maintenance for the wine cellar is very basic, the parts do not need periodic maintenance and should only be replaced by an engineer if faulty, however the cellar must be cleaned on a regular basis. Inside: Defrost the cellar manually, if necessary. Clean using warm water and a mild detergent (unperfumed) Do not use any type of corrosive product: when cleaning the shelves do not use abrasive or cutting materials as this may remove or damage the protective film... - Page 13 © Wine Corner Limited 2012. We reserve the right to change product specifications and prices without prior notice. Wine Corner Limited does not accept any responsibility for any loss, which may arise as a consequence of reliance on information contained in this document.
