Page 1 TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column When driving Driving, stopping and safe-driving information Air conditioning and audio systems, as well as other in- Interior features terior features for a comfortable driving experience Maintenance and...
Page 2: Table Of Contents
TABLE OF CONTENTS Index 1-5. Opening and closing the Before driving windows and moon roof Power windows ....128 Moon roof with Solar 1-1. Hybrid system Panel........ 132 Hybrid system features ..40 Hybrid system precautions ... 45 1-6. Refueling Energy monitor/consumption Opening the fuel tank screen.........
Page 3 2-4. Using other driving When driving systems Cruise control ..... 290 Dynamic radar cruise 2-1. Driving procedures control ......295 Driving the vehicle ....196 Driving assist systems..313 Power (ignition) switch..208 Hill-start assist control ..318 EV drive mode ....215 PCS (Pre-Crash Safety Hybrid transmission ....
Page 4 TABLE OF CONTENTS Index 3-4. Using the storage features Interior features List of storage features..372 • Glove boxes ..... 374 • Console box ..... 375 3-1. Using the air conditioning • Cup holders...... 376 system and defogger • Bottle holders ....378 Air conditioning system..
Page 5 Maintenance and care When trouble arises 4-1. Maintenance and care 5-1. Essential information Cleaning and protecting Emergency flashers ... 490 the vehicle exterior ... 398 If your vehicle needs to Cleaning and protecting be towed ......491 the vehicle interior .... 403 If you think something is wrong......
Page 6 TABLE OF CONTENTS Index Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.).... 590 Fuel information ....601 6-2. Customization Customizable features ..603 6-3. Initialization Item to initialize ....611 Index Abbreviation list....614 Alphabetical index .....615 What to do if......626 PRIUS_OM_OM47A19E_(EE)
Page 7 PRIUS_OM_OM47A19E_(EE)
Page 8 Pictorial index Exterior  Windshield wipers P. 274, 280 Moon roof with Solar Panel P. 132 Hood P. 414 Outside rear view mirrors P. 126 Side turn signal lights P. 227 Front fog lights P. 272 Front turn signal lights P.
Page 9 Rear fog light (right-hand drive vehicles) P. 272 Back door P. 103 Rear window defoggers P. 360 Rear turn signal lights P. 227 Rear window wiper P. 286 Fuel filler door P. 137 License plate lights Side doors P. 100 P.
Page 10 Pictorial index Interior (Left-hand drive vehicles) Head restraints P. 114 Airbag manual on-off switch P. 172 Seat belts P. 117 SRS front passenger airbag P. 158 Cup holders P. 376 Armrest Glove boxes P. 388 P. 374 Rear seats P. 111 SRS side airbags P.
Page 11 Sun visors P. 381 Front interior/personal lights P. 369 Microphone Assist grips P. 389 Rear interior light P. 370 SRS curtain shield airbags P. 158 Vanity mirrors P. 382  Auxiliary box P. 379  Moon roof switch P. 132 Anti-glare inside rear view mirror P.
Page 12 Pictorial index Interior (Left-hand drive vehicles) Window lock switch P. 128 Door lock switch P. 100 Inside lock button P. 100 Power window switches P. 128 PRIUS_OM_OM47A19E_(EE)
Page 13 AUX port/USB port Console box P. 375 Power outlet P. 384 Cup holders P. 376 : Refer to ““touch screen” Owner’s manual” or “Navigation System Owner’s Manual”. PRIUS_OM_OM47A19E_(EE)
Page 14 Pictorial index Interior (Left-hand drive vehicles)  Seat heater switches P. 386 Power outlet P. 384 Auxiliary box P. 379 PRIUS_OM_OM47A19E_(EE)
Page 15: Instrument Panel
Pictorial index Instrument panel (Left-hand drive vehicles) Windshield wipers and washer switch P. 274, 280 SRS driver airbag P. 158 Rear window wiper and Horn P. 229 washer switch P. 286 Headlight switch Gauges and meters P. 230 P. 267 Multi-information display P.
Page 16 Pictorial index Instrument panel (Left-hand drive vehicles) Outside rear view mirror switches P. 126  Headlight leveling dial P. 269  Headlight cleaner switch P. 289  Ventilation switch P. 353 Hood lock release lever P. 414 PRIUS_OM_OM47A19E_(EE)
Page 17 “TRIP” button P. 241, 245 Climate remote control switches P. 351 Audio remote “DISP” button P. 241 control switches  Talk switch Cruise control switch P. 290 Dynamic radar cruise control  Telephone switches switch P. 295  Vehicle-to-vehicle distance button P.
Page 18 Pictorial index Instrument panel (Left-hand drive vehicles) Clock adjustment buttons P. 247 Instrument cluster light control switch P. 233 Head-up display switches P. 260 IPA pre-support switch Power (ignition) switch P. 208 PRIUS_OM_OM47A19E_(EE)
Page 19 Air conditioning system P. 340 Rear window and outside rear view mirror defoggers switch P. 360 Emergency flasher switch P. 490 EV drive mode switch P. 215 Eco drive mode switch P. 220 Power mode switch P. 220 Shift lever P.
Page 20 Pictorial index Interior (Right-hand drive vehicles) Airbag manual on-off switch P. 172 Head restraints P. 114 Seat belts P. 117 SRS front passenger airbag P. 158 Cup holders P. 376 Glove boxes P. 374 Armrest P. 388 Rear seats P. 111 SRS side airbags P.
Page 21 Sun visors P. 381 Front interior/personal lights P. 369 Microphone Intrusion sensor cancel switch P. 150 Rear interior light P. 370 Assist grips P. 389 SRS curtain shield airbags P. 158 Vanity mirrors P. 382  Moon roof switch P. 132 ...
Page 22 Pictorial index Interior (Right-hand drive vehicles) Window lock switch P. 128 Door lock switch P. 100 Inside lock button P. 100 Power window switches P. 128 PRIUS_OM_OM47A19E_(EE)
Page 23 Console box P. 375 Power outlet P. 384 AUX port/USB port Cup holders P. 376 : Refer to ““touch screen” Owner’s manual” or “Navigation System Owner’s Manual”. PRIUS_OM_OM47A19E_(EE)
Page 24 Pictorial index Interior (Right-hand drive vehicles)  Seat heater switches P. 386 Power outlet P. 384 Auxiliary box P. 379 PRIUS_OM_OM47A19E_(EE)
Page 25 Pictorial index Instrument panel (Right-hand drive vehicles) Windshield wipers and washer SRS driver airbag P. 158 switch P. 274, 280 Horn P. 229 Rear window wiper and washer switch P. 286 Headlight switch P. 267 Gauges and meters P. 230 Turn signal lever Multi-information display P.
Page 26 Pictorial index Instrument panel (Right-hand drive vehicles) Air conditioning system P. 340 Rear window defogger switch P. 360 P position switch P. 221 Shift lever P. 218 EV drive mode switch P. 215 Eco drive mode switch P. 220 Power mode switch P.
Page 27 Clock adjustment buttons P. 247 Instrument cluster light control  switch P. 233  MPH or km/h button P. 232 Head-up display switches P. 260 IPA pre-support switch Power (ignition) switch P. 208  : If equipped : Refer to “Navigation System Owner’s Manual”. PRIUS_OM_OM47A19E_(EE)
Page 28 Pictorial index Instrument panel (Right-hand drive vehicles) “TRIP” button P. 241, 245 Climate remote control switches P. 351 Audio remote “DISP” button P. 241 control switches  Talk switch Cruise control switch P. 290 Dynamic radar cruise control  Telephone switches switch P.
Page 29  Headlight leveling dial P. 269  Headlight cleaner switch P. 289 Outside rear view mirror switches P. 126  Ventilation switch P. 353 Card holder P. 380 Hood lock release lever P. 414  : If equipped : Refer to ““touch screen” Owner’s manual” or “Navigation System Owner’s Manual”.
Page 30 Pictorial index Luggage compartment Luggage compartment light P. 104 Luggage cover P. 394 Auxiliary box P. 393 Cargo hooks P. 392 PRIUS_OM_OM47A19E_(EE)
Page 31 PRIUS_OM_OM47A19E_(EE)
Page 32: For Your Information
Accessories, spare parts and modification of your Toyota Both genuine Toyota and a wide variety of other spare parts and accessories for Toyota vehicles are currently available on the market. Should it be...
Page 33  SRS airbag system  Seat belt pretensioner system Be sure to check with any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system.
Page 34 CAUTION  General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 35 In the event that your vehicle must be disposed of, the hybrid battery (traction battery) must be disposed of by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or a qualified service shop. If the hybrid battery (trac- tion battery) is not disposed of properly, it may cause electric shock that can result in death or serious injury.
Page 36 Your vehicle contains batteries and/or accumulators. Do not discard them into the environment but cooperate with separate collection (Directive 2006/66/EC). PRIUS_OM_OM47A19E_(EE)
Page 37 This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 38 PRIUS_OM_OM47A19E_(EE)
Page 39: Before Driving
Before driving 1-1. Hybrid system 1-5. Opening and closing the windows and moon roof Hybrid system features ..40 Power windows....128 Hybrid system precautions ....... 45 Moon roof with Solar Panel ......132 Energy monitor/consumption screen....... 52 1-6. Refueling Hybrid vehicle driving tips ........
Page 40: Hybrid System Hybrid System Features
1-1. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
Page 41 1-1. Hybrid system  When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 42 1-1. Hybrid system  Regenerative braking In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery).  The accelerator pedal is released while driving with the shift position in D or B.
Page 43 The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.
Page 44 The operation sound of the air conditioning system (air conditioning com- pressor, blower motor).  Maintenance, repair, recycling, and disposal Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself. PRIUS_OM_OM47A19E_(EE)
Page 45: Hybrid System Precautions
1-1. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it contains a high voltage system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle. Air conditioning compressor Service plug High voltage cables (orange)
Page 46 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. PRIUS_OM_OM47A19E_(EE)
Page 47 1-1. Hybrid system Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted. If a warning message is shown on the multi-information display, read the message and follow the instructions.
Page 48 The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 49 1-1. Hybrid system CAUTION  High voltage precautions The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ...
Page 50 1-1. Hybrid system CAUTION  Road accident cautions If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury:  Stop the vehicle in a safe place to prevent subsequent accidents. While depressing the brake pedal, apply the parking brake, shift the shift position to P and turn the hybrid system off.
Page 51 Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 52: Energy Monitor/Consumption Screen
1-1. Hybrid system Energy monitor/consumption screen You can view the status of your hybrid system on the “touch screen” screen, the navigation system screen or the multi-information dis- play. “touch screen” screen or navigation system screen Multi-information display Energy monitor Displays the flow of energy as it changes in accordance with driving conditions.
Page 53 1-1. Hybrid system Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine PRIUS_OM_OM47A19E_(EE)
Page 54 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS_OM_OM47A19E_(EE)
Page 55 1-1. Hybrid system Navigation system Press “INFO”. If the “Consumption” screen is displayed, touch “Energy”. Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine...
Page 56 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS_OM_OM47A19E_(EE)
Page 57 1-1. Hybrid system Multi-information display Press the “DISP” button to dis- play the energy monitor.  Names and meaning of each icons Gasoline engine Hybrid battery (traction bat- tery) Electric motor (traction motor) Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by...
Page 58 1-1. Hybrid system Condition Display When the vehicle is powered by the gasoline engine When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions. PRIUS_OM_OM47A19E_(EE)
Page 59 1-1. Hybrid system Trip information screen “touch screen” Press “CAR”. If the “Energy monitor” screen is displayed, touch “Consumption”. Fuel consumption in the past 30 minutes Cruising range (P. 66) Regenerated energy in the past 30 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown.
Page 60 1-1. Hybrid system Navigation system Press “INFO”. If the “Energy monitor” screen is displayed, touch “Fuel consumption”. Fuel consumption in the past 30 minutes Regenerated energy in the past 30 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown. Cruising range (P.
Page 61 1-1. Hybrid system Multi-information display Press the “DISP” button to dis- play the 5-minute or 1-minute fuel consumption display. Press and hold the “DISP” button to switch the display between 5- minute and 1-minute fuel con- sumption. The display will alternate with each press of the button.
Page 62 1-1. Hybrid system EV indicator Eco Driving Indicator Light Average speed Average fuel consumption/eco savings Use the displayed average fuel consumption as a reference. : P. 242 : The current amount since the trip meter was reset will be dis- played.
Page 63 1-1. Hybrid system Monthly fuel consumption record/Eco savings record (multi- information display only) Press the “DISP” button to dis- play the monthly fuel consump- tion record savings record. Press and hold the “DISP” button to switch the display between monthly fuel consumption record and eco savings record.
Page 64 1-1. Hybrid system Eco savings record display By setting the fuel consumption for comparison and the gasoline price beforehand (P. 248), when the actual fuel consumption is less than the fuel consumption for comparison, the difference is calculated and the amount of money saved or spent is displayed : The displayed amount is intended only as a guide and may differ from the actual amount.
Page 65 1-1. Hybrid system  Remaining hybrid battery (traction battery) charge display The charge amount of the hybrid battery (traction battery) is automatically controlled by the hybrid system. For this reason, even if electricity is recov- ered via the regenerative braking, or electricity is generated via the gasoline engine, the displayed hybrid battery (traction battery) charge amount may not reach the highest level (level 8).
Page 66 1-1. Hybrid system  Resetting the monthly fuel consumption/eco savings record Press and hold the “TRIP” button while the monthly fuel consumption/eco savings record is displayed. A confirmation message will be displayed. Press and hold the “TRIP” button to reset the data. Press the “DISP”...
Page 67: Hybrid Vehicle Driving Tips
1-1. Hybrid system Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points:  Using Eco drive mode When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 68 1-1. Hybrid system  Highway driving Control your speed and keep at a constant speed. Also, before stopping at a toll booth or similar, allow plenty of time to release the accelerator and gently apply the brakes. A greater amount of electrical energy can be retained when slowing down.
Page 69 1-1. Hybrid system  Luggage Carrying heavy luggage can lead to poor fuel consumption. Avoid carrying unnecessary luggage. Installing a large roof rack can also cause poor fuel consumption.  Warming up before driving Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary.
Page 70: 1-2. Key Information
1-2. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart entry & start system (P. 73) • Operating wireless remote control function (P. 98) • Operating the Remote Air Conditioning System (P. 356) Mechanical keys Key number plate : If equipped...
Page 71 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional using the key number plate. (P. 568) ...
Page 72 In case of a smart entry & start system malfunction or other key-related problems Take your vehicle with all the electronic keys provided with your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
Page 73: Smart Entry & Start System
1-3.Opening, closing and locking the doors Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Unlocks and locks the side doors (P. 74) Unlocks and locks the back door (P.
Page 74 1-3. Opening, closing and locking the doors Unlocking and locking the doors Front door handles (including front passenger door handle if equipped with entry function) Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
Page 75 1-3. Opening, closing and locking the doors Back door (vehicles with entry function of front and back doors) Press the unlock button to unlock all the doors. The doors cannot be unlocked for 3 seconds after the doors are locked. Press the lock button to lock all the doors.
Page 76 1-3. Opening, closing and locking the doors Antenna location and effective range  Antenna location Vehicles with entry function of driver’s door Antennas outside cabin Antennas inside cabin Vehicles with entry function of front and back doors Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment...
Page 77 1-3. Opening, closing and locking the doors  Effective range (areas within which the electronic key is detected) Vehicles with entry function of driver’s door When locking or unlocking the door The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of driver’s door handle.
Page 78 1-3. Opening, closing and locking the doors Vehicles with entry function of front and back doors When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of either of the outside front door handle and back door opener switch.
Page 79 1-3. Opening, closing and locking the doors  Operation signals The emergency flashers flash to indicate that the doors have been locked/ unlocked. (Locked: Once; Unlocked: Twice)  When the door cannot be locked by the lock sensor on the upper part of the door handle If the door will not lock even when the topside sensor area is touched, try touch-...
Page 80 1-3. Opening, closing and locking the doors  Alarms and warning lights A combination of exterior and interior alarms as well as warning lights are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate measures in response to any warning message shown on the multi-information display.
Page 81 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure The “POWER” switch was turned to ACCESSORY mode while the driver’s Interior alarm Turn the “POWER” door was open (or the pings continu- switch off and close driver’s door was opened ously the driver’s door while the “POWER”...
Page 82 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure The electronic key has a Replace the electronic low battery key battery An attempt was made to Interior alarm start the hybrid system Start the hybrid sys- pings once without the electronic key tem with the elec- being present, or the elec-...
Page 83 1-3. Opening, closing and locking the doors  Security feature If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.  Battery-saving function The battery-saving function will be activated in order to prevent the elec- tronic key battery and the 12-volt battery from being discharged while the vehicle is not in operation for a long time.
Page 84 1-3. Opening, closing and locking the doors  Conditions affecting operation The smart entry & start system, wireless remote control and immobilizer sys- tem use weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart entry &...
Page 85 1-3. Opening, closing and locking the doors  Note for the entry function  Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 86 1-3. Opening, closing and locking the doors  Note for locking the doors  Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again.  If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly.
Page 87 1-3. Opening, closing and locking the doors  Note for the unlocking function  A sudden approach to the effective range or door handle may prevent the doors from being unlocked. In this case, return the door handle to the original position and check that the doors unlock before pulling the door handle again.
Page 88 1-3. Opening, closing and locking the doors  If the smart entry & start system does not operate properly  Locking and unlocking the doors: Use the mechanical key. (P. 569) Starting the hybrid system: P. 570   Electronic key battery depletion ...
Page 89 1-3. Opening, closing and locking the doors  Certification for the smart entry & start system PRIUS_OM_OM47A19E_(EE)
Page 90 1-3. Opening, closing and locking the doors PRIUS_OM_OM47A19E_(EE)
Page 91 1-3. Opening, closing and locking the doors PRIUS_OM_OM47A19E_(EE)
Page 92 1-3. Opening, closing and locking the doors PRIUS_OM_OM47A19E_(EE)
Page 93 1-3. Opening, closing and locking the doors PRIUS_OM_OM47A19E_(EE)
Page 94 1-3. Opening, closing and locking the doors PRIUS_OM_OM47A19E_(EE)
Page 95 1-3. Opening, closing and locking the doors PRIUS_OM_OM47A19E_(EE)
Page 96 1-3. Opening, closing and locking the doors PRIUS_OM_OM47A19E_(EE)
Page 97 (P. 76) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 98: Wireless Remote Control
1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Check to see that all the side doors and back door are securely locked.
Page 99 1-3. Opening, closing and locking the doors  Security feature P. 83  Alarm (if equipped) Using the wireless remote control to lock the doors will set the alarm system.  Conditions affecting operation P. 84  If the wireless remote control does not operate properly Locking and unlocking the doors: Use the mechanical key.
Page 100: Side Doors
1-3. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch.  Entry function P. 73  Wireless remote control P. 98  Door lock switch Locks all the doors Unlocks all the doors ...
Page 101 1-3. Opening, closing and locking the doors Locking the front doors from the outside without a key STEP Move the inside lock button to the lock position. STEP Close the door while pulling the door handle. The door cannot be locked if the “POWER” switch is in ACCESSORY or ON mode, or the electronic key is left inside the vehicle.
Page 102 1-3. Opening, closing and locking the doors  Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (P. 569)  If a wrong key is used The key cylinder rotates freely to isolate inside mechanism. ...
Page 103: Back Door
1-3. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures.  Locking and unlocking the back door Entry function P. 73 Wireless remote control P. 98 Door lock switch P.
Page 104 1-3. Opening, closing and locking the doors  Luggage compartment light The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on.  If the back door opener is inoperative The back door can be unlocked from the inside. STEP Open the center deck board.
Page 105 1-3. Opening, closing and locking the doors CAUTION  Caution while driving  Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 106 1-3. Opening, closing and locking the doors CAUTION  Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury.  Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 107 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. PRIUS_OM_OM47A19E_(EE)
Page 108 Do not touch the damper stay rod with gloves or other fabric items.  Damper stays Do not attach any accessories other than genuine Toyota parts to the back door.  Do not place your hand on the damper stay or apply lateral forces to it.
Page 109: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever Lumbar support adjustment switch : For driver’s side Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward and upward to help reduce...
Page 110 1-4. Adjustable components (seats, mirrors, steering wheel)  Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may make the inner struc- ture of the head restraint appear. This does not indicate a problem. During rear-end collision...
Page 111: Rear Seats
1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats The seatbacks can be folded down. Before folding down the seatbacks STEP Park the vehicle in a safe place. Apply the parking brake firmly and shift the shift position to P. (P.
Page 112 1-4. Adjustable components (seats, mirrors, steering wheel) Folding down the seatbacks Fold the seatback down while pushing the lock release button. To return the rear seatbacks to their original positions, lift them up until they lock.  Remove the seat belt from the guide If the seat belt interferes with luggage on the folded seats, remove the seat belt from the guide.
Page 113 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION  When folding the seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury.  Do not fold the seatbacks down while driving.  Stop the vehicle on level ground, set the parking brake and shift the shift position to P.
Page 114: Head Restraints
1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push and hold the lock release button when lowering the head Lock restraint. release button Rear seats Down Pull up or push down the head restraint while pressing the...
Page 115 1-4. Adjustable components (seats, mirrors, steering wheel)  Removing the head restraints Pull the head restraint up while pressing the lock release button. Lock release button  Installing the head restraints Align the head restraint with the installa- tion holes and push it down to the lock position.
Page 116 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION  Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury.  Use the head restraints designed for each respective seat. ...
Page 117: Seat Belts
1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle.  Correct use of the seat belts  Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 118 1-4. Adjustable components (seats, mirrors, steering wheel)  Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 119  Seat belt regulations If seat belt regulations exist in the country where you reside, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for seat belt replacement or installation. PRIUS_OM_OM47A19E_(EE)
Page 120 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children.  Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ...
Page 121 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION  Pregnant women Obtain medical advice and wear the seat belt in the proper way. (P. 117) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants.
Page 122 If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.
Page 123: Steering Wheel
1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP push the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 124: Inside Rear View Mirror
1-4. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirmation of the rear view in accordance with the driver’s seating posture. Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down.
Page 125 1-4. Adjustable components (seats, mirrors, steering wheel) Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF When the automatic anti-glare function is in ON mode, the indi- cator illuminates.
Page 126: Outside Rear View Mirrors
1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. To select a mirror to adjust, STEP press the switch. Left Right To adjust the mirror, press the STEP switch. Right Down Left Folding the mirrors...
Page 127 1-4. Adjustable components (seats, mirrors, steering wheel)  Mirror angle can be adjusted when The “POWER” switch is in ACCESSORY or ON mode.  When the mirrors are fogged up The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defoggers.
Page 128: Opening And Closing The Windows And Moon Roof Power Windows
1-5. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: One-touch closing Closing One-touch opening Opening : To stop the window partway, operate the switch in the oppo- site direction.
Page 129 1-5. Opening and closing the windows and moon roof  The power windows can be operated when The “POWER” switch is in ON mode.  Operating the power windows after turning the hybrid system off The power windows can be operated for approximately 45 seconds even after the “POWER”...
Page 130 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 131 1-5. Opening and closing the windows and moon roof  Customization The one-touch closing operation can be disabled, except for the driver’s seat. (Customizable features P. 603) CAUTION  Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ...
Page 132: Moon Roof With Solar Panel
1-5. Opening and closing the windows and moon roof  Moon roof with Solar Panel Use the overhead switches to open, close, and tilt the moon roof up and down.  Tilt up/down Tilt up Push and hold “OPEN” and then release.
Page 133 1-5. Opening and closing the windows and moon roof  Open/close Open Push and hold “OPEN” at the tilt position then release. Lightly push on either side of the switch stops the moon roof partway. The moon roof stops slightly before the fully open position to reduce the wind noise.
Page 134 “OPEN” switch until the moon roof opens fully and then closes slightly. If the functions do not activate, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 135 1-5. Opening and closing the windows and moon roof CAUTION  Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury.  Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 136 1-5. Opening and closing the windows and moon roof NOTICE  To prevent damage to the moon roof  Before opening, make sure that there are no foreign objects such as stones or ice around the opening.  Do not hit the face or edge of the moon roof with hard objects. ...
Page 137: 1-6. Refueling
1-6. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap:  Before refueling the vehicle  Turn the “POWER” switch off and close all the doors and win- dows.  Confirm the type of fuel. (P. 139) ...
Page 138 1-6. Refueling Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction.
Page 139  Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 140 1-6. Refueling CAUTION  When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury.  After exiting the vehicle and before opening the fuel filler door, touch an unpainted metal surface to discharge any static electricity.
Page 141 Do not top off the fuel tank  When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 142: Theft Deterrent System Immobilizer System
1-7. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.
Page 143 1-7. Theft deterrent system  Certifications for the immobilizer system PRIUS_OM_OM47A19E_(EE)
Page 144 1-7. Theft deterrent system PRIUS_OM_OM47A19E_(EE)
Page 145 1-7. Theft deterrent system PRIUS_OM_OM47A19E_(EE)
Page 146 1-7. Theft deterrent system NOTICE  To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guar- anteed. PRIUS_OM_OM47A19E_(EE)
Page 147: Double Locking System
1-7. Theft deterrent system  Double locking system Unauthorized access to the vehicle is prevented by disabling the door unlocking function from both the interior and exterior of the vehicle. Vehicles employing this sys- tem have labels on the win- dow glass of both front doors.
Page 148 1-7. Theft deterrent system Canceling the double locking system Using the entry function: Hold the outside door handle on the driver side or front passenger side (if equipped with the sensor). Using the wireless remote control: Press CAUTION  Double locking system precaution Never activate the double locking system when there are people in the vehi- cle because all the doors cannot be opened from inside the vehicle.
Page 149: Alarm
1-7. Theft deterrent system  Alarm The system sounds the alarm and flashes lights when forced entry is detected.  Triggering of the alarm The alarm is triggered in the following situations when the alarm is set.  A locked door or back door is unlocked or opened in any way other than using the entry function or wireless remote control.
Page 150 1-7. Theft deterrent system  Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm:  Unlock the doors using the entry function or wireless remote control.  Start the hybrid system. (The alarm will be deactivated or stopped after a few seconds.) Intrusion sensor (if equipped) The intrusion sensor detects intruders or movement in the vehicle.
Page 151 1-7. Theft deterrent system  System maintenance The vehicle has a maintenance-free type alarm system.  Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following:  Nobody is in the vehicle. ...
Page 152 1-7. Theft deterrent system  Alarm-operated door lock When the alarm is operating, the doors are locked automatically to prevent intruders.  Canceling and automatic re-enabling of the intrusion sensor  The alarm will still be set even when the intrusion sensor is canceled. ...
Page 153 1-7. Theft deterrent system  Ice or snow is removed from the vehi- cle, causing the vehicle to receive repeated impacts or vibrations.  The wind or something similar causes externally mounted reflectively coated windshield cover to move.  Unstable items, such as dangling accessories or clothes hanging on the coat hooks, are in the vehicle.
Page 154 1-7. Theft deterrent system PRIUS_OM_OM47A19E_(EE)
Page 155 1-7. Theft deterrent system NOTICE  To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guar- anteed. PRIUS_OM_OM47A19E_(EE)
Page 156: Safety Information Correct Driving Posture
1-8. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (P. 109) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 157 1-8. Safety information CAUTION  While driving  Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle.  Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 158: Srs Airbags
1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 159 1-8. Safety information SRS side and curtain shield airbags SRS side airbags Can help protect the torso of the front seat occupants SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats PRIUS_OM_OM47A19E_(EE)
Page 160 1-8. Safety information SRS airbag system components Front passenger airbag Driver airbag “PASSENGER AIR BAG” Side impact sensors (front) indicator Seat belt pretensioners and Side airbags force limiters Curtain shield airbags Driver’s knee airbag Side impact sensors (rear) Front impact sensors SRS warning light Airbag sensor assembly Airbag manual on-off switch...
Page 161 1-8. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
Page 162 1-8. Safety information  SRS airbag deployment conditions (SRS front airbags)  The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 20 - 30 km/h [12 - 18 mph] frontal collision with a fixed wall that does not move or deform).
Page 163 1-8. Safety information  Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ...
Page 164 1-8. Safety information  Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 165 When to contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional In the following cases, the vehicle will require inspection and/or repair. Con- tact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. ...
Page 166 1-8. Safety information  The surface of the seats with the side airbag is scratched, cracked, or other- wise damaged.  The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or other- wise damaged.
Page 167 1-8. Safety information CAUTION  SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury.  The driver and all passengers in the vehicle must wear their seat belts properly.
Page 168 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 169 1-8. Safety information CAUTION  SRS airbag precautions  Do not lean against the door, the roof side rail or the front, side and rear pil- lars.  Do not allow anyone to kneel on the passenger seat toward the door or put their head or hands outside the vehicle.
Page 170 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 171 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 172: Airbag Manual On-Off System
1-8. Safety information Airbag manual on-off system This system deactivates the front passenger airbag and front pas- senger side airbag. Only deactivate the airbags when using a child restraint system on the front passenger seat. “PASSENGER AIR BAG” indicator This indicator turns on when the airbag system is “ON”.
Page 173 “PASSENGER AIR BAG” indicator information If any of the following problems occur, it is possible that there is a malfunc- tion in the system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 174: Child Restraint Systems
Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installation.  Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44. PRIUS_OM_OM47A19E_(EE)
Page 175 1-8. Safety information Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation “ECE No.44”. Group 0: Up to 10 kg (22 lb.) (0 - 9 months) Group 0 : Up to 13 kg (28 lb.) (0 - 2 years) Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II: 15 to 25 kg (34 to 55 lb.) (4 years - 7 years)
Page 176 1-8. Safety information Baby seat Equal to Group 0 and 0 of “ECE No.44” Child seat Equal to Group 0 and I of “ECE No.44” Junior seat Equal to Group II and III of “ECE No.44” PRIUS_OM_OM47A19E_(EE)
Page 177 1-8. Safety information Child restraint system suitability for various seating positions Provided information in the table shows your child restraint system suitability for various seating positions. Front passenger seat Seating position Rear seat Airbag manual on-off switch Mass groups Outside Center Up to 10 kg (22 lb.)
Page 178 1-8. Safety information Key of letters inserted in the above table: Suitable for “universal” category child restraint system approved for the use in this mass group. UF: Suitable for forward-facing “universal” category child restraint system approved for the use in this mass group. Not suitable seat position for children in this mass group.
Page 179 1-8. Safety information Child restraint system suitability for various seating positions (with ISOFIX rigid anchor) Provided information in the table shows your child restraint system suitability for various seating positions. Vehicle ISOFIX positions Mass groups Size class Fixture Rear outside ISO/L1 Carrycot ISO/L2...
Page 180 1-8. Safety information For the child restraint system which do not carry the ISO/XX size class identification (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position. Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraint systems of universal category approved for use in this mass group.
Page 181  Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 182 1-8. Safety information CAUTION  Child restraint precautions  Never install a rear-facing child restraint system on the front passenger seat when the airbag manual on-off switch is ON. (P. 172) In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
Page 183 1-8. Safety information CAUTION  When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 184: Installing Child Restraints
1-8. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts belt requires a locking clip.) ISOFIX rigid anchors (ISOFIX child restraint system)
Page 185 1-8. Safety information Installing child restraints using a seat belt Rear-facing  Baby seat/child seat  Place the child restraint system STEP on the rear seat facing the rear of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle.
Page 186 1-8. Safety information If your child restraint system is not equipped with a lock-off (a seat belt locking feature), secure the child restraint system using a locking clip. (P. 190) After installing the child restraint system, rock it back and forth to ensure that it is installed securely.
Page 187 1-8. Safety information Run the seat belt through the STEP child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Keep the lap portion of the belt tight. Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place.
Page 188 1-8. Safety information  Junior seat Place the child restraint system STEP on the seat facing the front of the vehicle. Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle.
Page 189 1-8. Safety information Removing a child restraint system installed with a seat belt Push the buckle release button and fully retract the seat belt. Installation with ISOFIX rigid anchor (ISOFIX child restraint sys- tem) STEP Adjust the head restraint to the upmost position. STEP Widen the gap between the seat cushion and seatback slightly.
Page 190 If your child restraint system does not provide a locking clip, you can purchase the fol- lowing item from any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 191 1-8. Safety information CAUTION  When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.
Page 192 1-8. Safety information CAUTION  When installing a child restraint system  Never install a rear-facing child restraint system on the front passenger seat when the airbag manual on-off switch is on. (P. 172) The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
Page 193 When installing a child restraint system  If child restraint system regulations exist in the country where you reside, please contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for the child restraint system installa- tion.
Page 194 1-8. Safety information PRIUS_OM_OM47A19E_(EE)
Page 195: When Driving
When driving 2-1. Driving procedures 2-3. Operating the lights and windshield wipers Driving the vehicle .... 196 Headlight switch....267 Power (ignition) switch..208 Fog light switch ....272 EV drive mode ....215 Windshield wipers and Hybrid transmission ..218 washer (type A) ....
Page 196: 2-1. Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing:  Starting the hybrid system P. 208  Driving STEP With the brake pedal depressed, shift the shift position to D. (P. 218) Check that the shift position indicator shows D.
Page 197  Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is rec- ommended: ...
Page 198 2-1. Driving procedures  Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (P. 592)  For efficient use  Shift the shift position to D when driving. In the N position, the gasoline engine operates but electricity cannot be generated.
Page 199 2-1. Driving procedures CAUTION  When starting the vehicle Always keep your foot on the brake pedal while stopped with the hybrid sys- tem operating. This prevents the vehicle from creeping.  When driving the vehicle  Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
Page 200 2-1. Driving procedures CAUTION  If the smell of exhaust is noticed inside the vehicle, open the windows and check that the back door is closed. Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard.
Page 201 2-1. Driving procedures CAUTION  Do not adjust the positions of the steering wheel, the seat, or the inside or outside rear view mirrors while driving. Doing so may result in a loss of vehicle control that can cause accidents, resulting in death or serious injury.
Page 202 CAUTION  If you hear a squealing or scraping noise (brake pad wear indicators) Have any authorized Toyota dealer or repairer, or another duly qualified and equipped professional check and replace the brake pads as soon as possi- ble. Rotor damage may result if the pads are not replaced when needed.
Page 203 2-1. Driving procedures CAUTION  When the vehicle is parked  Make sure to firmly apply the parking brake and shift the shift position to P. Failure to do so may cause the vehicle to move, or the vehicle to acceler- ate suddenly if the accelerator pedal is accidentally depressed.
Page 204 2-1. Driving procedures CAUTION  Do not leave a door or window open if the curved glass is coated with a metallized film such as a silver-colored one. Reflected sunlight may cause the glass to act as a lens, causing a fire. ...
Page 205 2-1. Driving procedures CAUTION  When taking a nap in the vehicle Always turn the hybrid system off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to hybrid system overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
Page 206 2-1. Driving procedures NOTICE  When driving the vehicle  Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque.  Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 207 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional check the following: ...
Page 208: Power (Ignition) Switch
2-1. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes.  Starting the hybrid system STEP Check that the parking brake is set. STEP Firmly depress the brake pedal.
Page 209 2-1. Driving procedures STEP Check that the “READY” indicator is on. If the “READY” indicator changes from a flashing light to a solid light and the buzzer sounds, the hybrid system is starting nor- mally. The vehicle will not move when the “READY” indicator is off. The vehicle can move when the “READY”...
Page 210 2-1. Driving procedures  Changing “POWER” switch modes Modes can be changed by pressing the “POWER” switch with the brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 211 Notes for the entry function P. 85  If the hybrid system does not start The immobilizer system may not have been deactivated. (P. 142) Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 212  When the “POWER” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.  If the “READY” indicator does not come on If the “READY”...
Page 213 The “POWER” switch will not be able to be turned off. In such a case, the switch can be turned off after applying the parking brake. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately.
Page 214 If the “POWER” switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Con- tact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. PRIUS_OM_OM47A19E_(EE)
Page 215: Ev Drive Mode
2-1. Driving procedures EV drive mode In EV drive mode, the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. This mode allows you to drive in residential areas late at night, or in indoor parking lots etc.
Page 216 2-1. Driving procedures  Situations in which EV drive mode cannot be turned on It may not be possible to turn EV drive mode on in the following situations. If it cannot be turned on, a buzzer will sound and a message will be shown on the multi-information display.
Page 217  Fuel economy PRIUS is designed to achieve the best possible fuel economy during normal driving (using the gasoline engine and electric motor [traction motor]). Driv- ing in EV drive mode more than necessary may lower fuel economy.
Page 218: Hybrid Transmission
2-1. Driving procedures Hybrid transmission Select a shift position appropriate for the driving conditions.  Shifting the shift lever Shift lever Operate the shift lever gently and ensure correct shifting operation. Release the shift lever after each shifting operation to allow it to return to the position.
Page 219 2-1. Driving procedures Shift position indicator The position of the frame on the shift position indicator changes in accordance with the current shift position. When any shift position other than D or B is selected, the arrow toward B and B position indicator disappear from the shift position indicator. When selecting the shift position, make sure that the shift position has been changed to the desired position by checking the shift position indica- tor provided on the instrument cluster.
Page 220 2-1. Driving procedures  Selecting a driving mode The following modes can be selected to suit driving conditions: Eco drive mode Suitable for improving the fuel economy, because the torque cor- responding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions and the operation of the air conditioning system (heating/cooling) will be minimized.
Page 221 2-1. Driving procedures P position switch  When shifting the shift position to P Fully stop the vehicle and set the parking brake, and then press the P position switch. When shift position changed to P, the indicator comes Check that the P position is illumi- nated on the shift position indica- tor.
Page 222 2-1. Driving procedures  Operation of the air conditioning system in Eco drive mode Eco drive mode controls the heating/cooling operations and fan speed of the air conditioning system to enhance fuel efficiency. (P. 220) To improve air conditioning performance, adjust the fan speed and temperature or turn off Eco drive mode.
Page 223 2-1. Driving procedures  Situations where the shift position will automatically change to N: • When the P position switch is pressed while the vehicle is running. • When an attempt is made to select the R position by moving the shift lever when the vehicle is moving forward.
Page 224 2-1. Driving procedures  About engine braking When shift position B is selected, releasing the accelerator pedal will apply engine braking.  When the vehicle is driven at high speeds, compared to ordinary gaso- line-fueled vehicles, the engine braking deceleration is felt less than that of other vehicles.
Page 225  For the shift lever Do not remove the shift lever knob or use anything but a genuine Toyota shift lever knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift lever from returning to position, causing unexpected accidents to occur when the vehicle is in motion.
Page 226 If any of the following situations occurs, shift control system malfunctions are possible. Immediately stop the vehicle in a safe place on level ground, apply the park- ing brake, and then contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
Page 227: Turn Signal Lever
2-1. Driving procedures Turn signal lever The turn signal lever can be used to show the following intention of the driver: Right turn Left turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 228: Parking Brake
2-1. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. (Depressing the pedal again releases the parking brake.)  Parking brake engaged warning buzzer P.
Page 229: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark.  After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
Page 230: 2-2. Instrument Cluster
2-2. Instrument cluster Gauges and meters The units used on the display may differ depending on the target region. The following gauges and meters and display illuminate when the “POWER” switch is in ON mode: Fuel gauge Displays the quantity of fuel remaining in the tank. Speedometer Displays the vehicle speed.
Page 231 2-2. Instrument cluster Touch tracer display (if equipped) When the audio control switches, climate control switches, “DISP” button or “TRIP” button of the steering wheel are touched, the touch tracer display will appear in front of the gauges, with the touched button highlighted to allow the driver to identify the button that is being operated.
Page 232 2-2. Instrument cluster MPH or km/h button (if equipped) The speed units can be selected MPH or km/h. Press the button to switch the display between MPH and km/h. PRIUS_OM_OM47A19E_(EE)
Page 233 2-2. Instrument cluster Instrument cluster light control When the tail light is on, the brightness of the instrument cluster lights can be adjusted. (For vehicles with the automatic light control sys- tem, the lights can be adjusted when the tail light is on and the sur- rounding area is dark.) Type A The brightness will change by 3...
Page 234 2-2. Instrument cluster  Brightness of the instrument panel light If the headlight switch is turned on while the surrounding area is dark, the instrument panel lights will dim. CAUTION  To prevent an accident Do not place anything or attach a sticker Instrument cluster in front of the instrument cluster.
Page 235: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and instrument panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration displays all indicators and warning lights illuminated.
Page 236 2-2. Instrument cluster  Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator “ECO MODE” (P. 227) indicator (P. 220) Tail light indicator Power mode indicator (P. 267) (P. 220) Headlight high beam Cruise control indicator indicator (P.
Page 237 Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.
Page 238 Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 239 Have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional immediately if this occurs.
Page 240: Multi-Information Display
2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the clock.  Energy monitor (P. 52)  Hybrid System Indicator (P. 241)  5-minute/1-minute fuel consumption (P. 61)  Monthly fuel consumption record/eco savings record (P. 63) ...
Page 241 2-2. Instrument cluster Switching the display To switch the display, press “DISP” button. On vehicles with touch tracer dis- play, the steering switches opera- tion status is displayed on the instrument cluster for confirma- tion purposes. (P. 231) To switch the odometer, trip meter and distance to empty, press “TRIP”...
Page 242 2-2. Instrument cluster  Names and meaning of each icons Hybrid battery (traction bat- tery) status (P. 57) EV indicator The EV indicator comes on when the vehicle is driven using only the electric motor (traction motor) or the gasoline engine is stopped. Eco Driving Indicator Light Turns on when the vehicle is driven in Eco-friendly.
Page 243 2-2. Instrument cluster  Reading Hybrid System Indicator Charge area Eco area Power area Hybrid Eco area As shown below, the driving conditions of the vehicle can be con- firmed by checking the status of the indicator bar. PRIUS_OM_OM47A19E_(EE)
Page 244 2-2. Instrument cluster Hybrid System Indicator Charge area: Shows regenerative charging. (P. 42) Hybrid Eco area: Shows that gasoline engine power is not being used very often. Eco area: Shows that the vehicle is driven in Eco-friendly. Power area: Shows that the driving power is more than the upper limit of Eco driving (during full power driving etc.).
Page 245 2-2. Instrument cluster Odometer/trip meter/distance to empty  Switching the display The display changes as follows each time the “TRIP” button is pressed. Also, if the button is kept pressed down while the trip meter is being displayed, the trip meter will be reset to 0.
Page 246 2-2. Instrument cluster  Display items  Odometer Displays the total distance the vehicle has been driven.  Trip meter Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different dis- tances independently.
Page 247 2-2. Instrument cluster Clock The clock can be adjusted by pressing the buttons. Adjusts the hours. Adjusts the minutes. Rounds to the nearest hour. : e.g. 1:00 to 1:29 1:00 1:30 to 1:59 2:00 Setting up the displays Press the “DISP” button until the STEP “SETTINGS”...
Page 248 2-2. Instrument cluster  Setting the gasoline price Select “PETROL PRICE”. STEP Press and hold the “DISP” button to enter the setting mode. Select gasoline price by pressing STEP the “DISP” or “TRIP” button. Press and hold the button to change the amount continuously.
Page 249 2-2. Instrument cluster  Switching the fuel consumption display Select “FUEL CONSU. DISP.”. STEP Press and hold the “DISP” button to enter the setting mode. Select “CONSUMP.” or “ECO STEP SAVINGS”. Press and hold the “DISP” button to finish setting. PRIUS_OM_OM47A19E_(EE)
Page 250 2-2. Instrument cluster  Setting the comparison consumption Select “COMP. CONSUMP- STEP TION”. Press and hold the “DISP” button to enter the setting mode. Select the comparison consump- STEP tion by pressing the “DISP” or “TRIP” button. Press and hold the button to change the amount continuously.
Page 251 2-2. Instrument cluster  Setting the calendar Select “CALENDAR”. STEP Press and hold the “DISP” button to enter the setting mode. Select the date by pressing the STEP “DISP” or “TRIP” button. Press and hold the button to change the date continuously. If neither button is operated for approximately 5 seconds, the set- ting will be changed and the...
Page 252 2-2. Instrument cluster  Switching the EV indicator and Eco Driving Indicator Light activated or deactivated Select “EV/ECO”. STEP Press and hold the “DISP” button to enter the setting mode. Select “ON” or “OFF”. STEP Press and hold the “DISP” button to finish setting.
Page 253 2-2. Instrument cluster  Switching the steering switch operation display on/off (if equipped) Select “STEERING SWITCH”. STEP Press and hold the “DISP” button to enter the setting mode. Select “ON” or “OFF”. STEP Press and hold the “DISP” button to finish setting. PRIUS_OM_OM47A19E_(EE)
Page 254 2-2. Instrument cluster  Selecting 12h/24h clock display Select “CLOCK”. STEP Press and hold the “DISP” button to enter the setting mode. Select “12h” or “24h”. STEP Press and hold the “DISP” button to finish setting. PRIUS_OM_OM47A19E_(EE)
Page 255 2-2. Instrument cluster  Selecting the language Select “LANGUAGE”. STEP Press and hold the “DISP” button to enter the setting mode. Select the language you want to STEP read. Press and hold the “DISP” button to set the language. PRIUS_OM_OM47A19E_(EE)
Page 256 2-2. Instrument cluster  Turning off the multi-information display Select “SCREEN OFF”. STEP Press and hold the “DISP” button to enter the setting mode. Select “OFF”. STEP Press and hold the “DISP” button to turn off the multi-information display. To re-display the multi-information display, press the “DISP”...
Page 257 2-2. Instrument cluster  System check display After switching the “POWER” switch to ON mode, “welcome to PRIUS” is dis- played while system operation checked. When the system check is com- plete, the normal screen will return.  Ending display P.
Page 258 2-2. Instrument cluster  Driving in Eco drive mode The multi-information display will automatically switch the display to Hybrid System Indicator, regardless of which display is currently being shown. (P. 241)  Touch tracer display (if equipped)  The touch tracer display can be set to not display even if the steering switches are touched.
Page 259 2-2. Instrument cluster  Vacuum fluorescent display Small spots or light spots may appear on the display. This phenomenon is characteristic of vacuum fluorescent displays, and there is no problem to continue using the display. NOTICE  Steering switches To prevent damage to the steering switches, observe the following precau- tions.
Page 260: Head-Up Display
2-2. Instrument cluster Head-up display The head-up display can be used to project vehicle speed and other information onto the windshield. Head-up display Display brightness will change automatically according to the brightness of the surrounding area. (Head-up display) main switch Turn-by-turn navigation switch (if equipped)
Page 261 2-2. Instrument cluster  Head-up display contents  Speedometer Displays the vehicle speed.  Hybrid System Indicator Provides assistance for Eco-friendly driving.  Turn-by-turn navigation Displays a notification of upcoming intersections during navigation system route guidance. (P. 264)  Dynamic radar cruise control Displays the approach warning.
Page 262 2-2. Instrument cluster Switching the head-up display Display items can be switched by pressing the “HUD” main switch. Speedometer Displays the vehicle speed. Speedometer and Hybrid Sys- tem Indicator Displays Hybrid System Indicator under the speedometer. (P. 241) When on, the indicator light on the “HUD”...
Page 263 2-2. Instrument cluster Setting up the display  Setting the brightness The brightness of the display is automatically adjusted in accor- dance with the brightness of the surrounding environment. How- ever, the brightness can also be manually adjusted in 5 stages. Darker Brighter The brightness can be manually...
Page 264 System check display When the “POWER” switch is turned OFF while the head-up display is on, and is then turned again to ON mode, “welcome to PRIUS” is displayed while system operation is checked. When the system check is complete, the normal screen will return.
Page 265 2-2. Instrument cluster  When driving on snowy roads or in other bright environments When the highest level of brightness has been reached, the display can be made even brighter by pressing and holding “” on the brightness control button. Pressing “”...
Page 266 2-2. Instrument cluster CAUTION  Before using the head-up display Check that the position and brightness of the head-up display image does not interfere with safe driving. Incorrect adjustment of the image’s position or brightness may obstruct the driver’s view and lead to an accident, resulting in death or serious injury.
Page 267: 2-3. Operating The Lights And Windshield Wipers
2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. Turning the end of the lever turns on the lights as follows: Type A The front position, tail, license plate and instrument panel lights turn on.
Page 268 2-3. Operating the lights and windshield wipers Type B The front position, tail, license plate and instrument panel lights turn on. The headlights and all the lights listed above turn on. The headlights, front (if equipped) position lights and so on turn on and off automatically (when the “POWER”...
Page 269 2-3. Operating the lights and windshield wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 270 2-3. Operating the lights and windshield wipers  Guide to dial settings Occupancy and luggage load conditions Dial position Occupants Luggage load Driver None Driver and front None passenger All seats occupied None All seats occupied Full luggage loading Driver Full luggage loading ...
Page 271 2-3. Operating the lights and windshield wipers  Automatic light off system  When the light switch is in the position: The headlights turn off automatically if the “POWER” switch is turned to ACCESSORY mode or OFF.  When the light switch is in the AUTO position: The headlights and all lights turn off automatically if the “POWER”...
Page 272: Fog Light Switch
2-3. Operating the lights and windshield wipers Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Type A Turns the front and rear fog lights off Turns the front fog lights on Turns both front and rear fog lights on Releasing the switch returns...
Page 273 2-3. Operating the lights and windshield wipers Type B Turns the front and rear fog lights off Turns the front fog lights on Turns both front and rear fog lights on Releasing the switch returns the ring to the position. Operating the switch ring again turns only the rear fog light off.
Page 274: Windshield Wipers And Washer (Type A)
2-3. Operating the lights and windshield wipers Windshield wipers and washer (type A) Intermittent windshield wipers with interval adjuster (if equipped) The wiper operation is selected by moving the lever as follows. When intermittent windshield wiper operation is selected, wiper intervals can be also adjusted.
Page 275 2-3. Operating the lights and windshield wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. PRIUS_OM_OM47A19E_(EE)
Page 276 2-3. Operating the lights and windshield wipers Rain-sensing windshield wipers (if equipped) The wiper operation is selected by moving the lever as follows. When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed.
Page 277 2-3. Operating the lights and windshield wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. PRIUS_OM_OM47A19E_(EE)
Page 278 2-3. Operating the lights and windshield wipers  The windshield wipers and washer can be operated when The “POWER” switch is in ON mode.  Raindrop sensor (vehicles with rain-sensing windshield wipers)  The raindrop sensor judges the amount of raindrops. ...
Page 279  When a nozzle becomes blocked In this case, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 280: Windshield Wipers And Washer (Type B)
2-3. Operating the lights and windshield wipers Windshield wipers and washer (type B) Intermittent windshield wipers with interval adjuster (if equipped) The wiper operation is selected by moving the lever as follows. When intermittent windshield wiper operation is selected, wiper intervals can be also adjusted.
Page 281 2-3. Operating the lights and windshield wipers Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency Washer/wiper dual opera- tion Wipers operate automatically. PRIUS_OM_OM47A19E_(EE)
Page 282 2-3. Operating the lights and windshield wipers Rain-sensing windshield wipers (if equipped) The wiper operation is selected by moving the lever as follows. When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed.
Page 283 2-3. Operating the lights and windshield wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. PRIUS_OM_OM47A19E_(EE)
Page 284 2-3. Operating the lights and windshield wipers  The windshield wipers and washer can be operated when The “POWER” switch is in ON mode.  Raindrop sensor (vehicles with rain-sensing windshield wipers)  The raindrop sensor judges the amount of raindrops. ITO23P128 ...
Page 285  When a nozzle becomes blocked In this case, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 286: Rear Window Wiper And Washer
2-3. Operating the lights and windshield wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper and washer as follows: Type A Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion...
Page 287 2-3. Operating the lights and windshield wipers Type B Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion  The rear window wiper and washer can be operated when The “POWER” switch is in ON mode. ...
Page 288 2-3. Operating the lights and windshield wipers NOTICE  When the rear window is dry Do not use the wiper, as it may damage the rear window.  When the washer fluid tank is empty Do not operate the switch continually as the washer fluid pump may over- heat.
Page 289: Headlight Cleaner Switch
2-3. Operating the lights and windshield wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights.  The headlight cleaners can be operated when The “POWER” switch is in ON mode and the headlight switch is turned on. If equipped, the headlight switch is in the “AUTO”...
Page 290: Using Other Driving Systems Cruise Control
2-4. Using other driving systems  Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Cruise control switch Indicators  Setting the vehicle speed Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on.
Page 291 2-4. Using other driving systems Accelerate or decelerate the STEP vehicle to the desired speed, and push the lever down to set the speed. “SET” indicator will come on. The vehicle speed at the moment the lever is released becomes the set speed. ...
Page 292 2-4. Using other driving systems  Canceling and resuming the constant speed control Pulling the lever toward you cancels the constant speed control. The speed setting is also can- celed when the brakes are applied. Pushing lever resumes constant ITO24P106 speed control.
Page 293 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 294 2-4. Using other driving systems CAUTION  To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use.  Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 295: Dynamic Radar Cruise Control
2-4. Using other driving systems  Dynamic radar cruise control Dynamic radar cruise control supplements conventional cruise con- trol with a vehicle-to-vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates or decelerates in order to maintain a set following distance from vehi- cles ahead.
Page 296 2-4. Using other driving systems  Setting the vehicle speed (vehicle-to-vehicle distance con- trol mode) Press the “ON-OFF” button to STEP activate the cruise control. Radar cruise control indicator will come on. Press the button again to deactivate the cruise control. Accelerate or decelerate the STEP vehicle to the desired speed,...
Page 297 2-4. Using other driving systems  Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 298 2-4. Using other driving systems  Changing the vehicle-to-vehicle distance Pressing the button changes Preceding vehicle mark vehicle-to-vehicle dis- tance as follows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the “POWER” switch is turned to ON mode. If a vehicle is running ahead of you, the preceding vehicle mark will also be displayed.
Page 299 2-4. Using other driving systems  Canceling and resuming the speed control Pulling the lever toward you cancels the cruise control. The speed setting is also can- celed when the brakes are applied. Pushing lever resumes the cruise control and returns vehicle speed ITO24P127 to the set speed.
Page 300 2-4. Using other driving systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 120 m (400 ft.) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 301 2-4. Using other driving systems Example of constant speed cruising When there are no vehicles ahead The vehicle travels at the speed set by the driver. The desired vehicle-to- vehicle distance can also be set by operating the vehicle-to-vehicle dis- tance control.
Page 302 2-4. Using other driving systems Approach warning When your vehicle is too close to a vehicle ahead, and sufficient automatic deceleration via the cruise control is not possible, the dis- play will flash and the buzzer will sound to alert the driver. An exam- ple of this would be if another driver cuts in front of you while you are following a vehicle.
Page 303 2-4. Using other driving systems Selecting conventional constant speed control mode Constant speed control mode differs from vehicle-to-vehicle distance control mode. When constant speed mode is selected, your vehicle will maintain a set speed regardless of whether or not there are other vehicles in the lane ahead.
Page 304 2-4. Using other driving systems If the “POWER” switch is turned off and then turned to ON mode again, the vehicle will automati- cally return to vehicle-to-vehicle distance control mode. Adjusting the speed setting: P. 297 Canceling resuming speed setting: P. 299 ...
Page 305 If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional.  Automatic cancelation of constant speed control...
Page 306 2-4. Using other driving systems  Radar sensor and grille cover Always keep the sensor and grille cover clean to ensure that the vehicle-to- vehicle distance control operates properly. (Some obstructions, such as snow, ice and plastic objects, cannot be detected by the obstruction sensor.) Dynamic radar cruise control (vehicle-to-vehicle distance control mode) will be canceled if dirt is detected.
Page 307 2-4. Using other driving systems PRIUS_OM_OM47A19E_(EE)
Page 308 2-4. Using other driving systems PRIUS_OM_OM47A19E_(EE)
Page 309 2-4. Using other driving systems CAUTION  Before using dynamic radar cruise control Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 310 2-4. Using other driving systems CAUTION  To avoid inadvertent cruise control activation Switch the cruise control off using the “ON-OFF” button when not in use.  Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 311 2-4. Using other driving systems CAUTION  When the sensor may not be correctly detecting the vehicle ahead Apply the brakes (or accelerator pedal) as necessary when any of the follow- ing types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the approach warning (P.
Page 312 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
Page 313: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ...
Page 314 2-4. Using other driving systems  Hill-start assist control P. 318  PCS (Pre-Crash Safety System) (if equipped) P. 321  Emergency brake signal (if equipped) When the brakes are applied suddenly, the stop lights automati- cally flash to alert the vehicle behind. When the TRC/VSC/ABS systems are operating The slip indicator light will flash while the TRC/VSC/ABS sys-...
Page 315 2-4. Using other driving systems  Sounds and vibrations caused by the ABS, brake assist, VSC and TRC  A sound may be heard from the engine compartment when the hybrid system is started, just after the vehicle begins to move, if the brake pedal is depressed forcefully or repeatedly, or 1-2 minutes after the hybrid sys- tem is stopped.
Page 316 2-4. Using other driving systems  Operating conditions of emergency brake signal When the following three conditions are met, the emergency brake signal will operate:  The emergency flashers are off.  Actual vehicle speed is over 55 km/h (35 mph). ...
Page 317 The ABS and VSC systems will not function correctly if different tires are installed on the vehicle. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional for further information when replacing tires or wheels.
Page 318: Hill-Start Assist Control
2-4. Using other driving systems Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 319 • The brake pedal has been depressed for more than approximately 3 minutes.  If the slip indicator light comes on It may indicate a malfunction in the system. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 320 2-4. Using other driving systems CAUTION  Hill-start assist control  Do not overly rely on the hill-start assist control. Hill-start assist control may not operate effectively on extremely steep inclines or roads covered in ice.  Unlike the parking brake, hill-start assist control is not intended to hold the vehicle stationary for an extended period of time.
Page 321: Pcs (Pre-Crash Safety System)
2-4. Using other driving systems  PCS (Pre-Crash Safety System) When the radar sensor detects possibility of a frontal collision, the pre-crash safety systems such as the brakes and seat belts are auto- matically engaged to lessen impact as well as vehicle damage. ...
Page 322 2-4. Using other driving systems Disabling pre-crash braking Pre-crash braking enabled Pre-crash braking disabled The “PCS” warning light will turn on when pre-crash brak- ing is disabled. Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and deter- mines whether a collision is imminent based on the position,...
Page 323 2-4. Using other driving systems  The pre-crash safety system is operational when  Pre-crash seat belts (operating conditions A): • Vehicle speed is greater than about 30 km/h (19 mph). • The system detects sudden braking or skidding. • The front occupants are wearing a seat belt. ...
Page 324 2-4. Using other driving systems  Conditions that may trigger the system even if there is no possibility of a collision  When there is an object by the roadside at the entrance to a curve  When passing an oncoming vehicle on a curve ...
Page 325 2-4. Using other driving systems  Obstacles not detected The sensor cannot detect plastic obstacles such as traffic cones. There may also be occasions when the sensor cannot detect pedestrians, animals, bicycles, motorcycles, trees, or snowdrifts.  Situations in which the pre-crash safety system does not function properly The system may not function effectively in situations such as the following: ...
Page 326 2-4. Using other driving systems  Certification The latest “DECLARATION of CONFORMITY” (DoC) is available at the fol- lowing: http://www.globaldenso.com/en/products/oem/index.html#2 PRIUS_OM_OM47A19E_(EE)
Page 327 2-4. Using other driving systems PRIUS_OM_OM47A19E_(EE)
Page 328 2-4. Using other driving systems PRIUS_OM_OM47A19E_(EE)
Page 329 2-4. Using other driving systems CAUTION  Limitations of the pre-crash safety system Do not overly rely on the pre-crash safety system. Always drive safely, taking care to observe your surroundings and checking for any obstacles or other road hazards. Failure to do so may cause an accident resulting in death or serious injury.
Page 330 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional. ...
Page 331: 2-5. Driving Information
2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load:  Stow cargo and luggage in the luggage compartment whenever possible.  Be sure all items are secured in place.  To maintain vehicle balance while driving, position luggage evenly within the luggage compartment.
Page 332 2-5. Driving information CAUTION  Storage precautions Observe the following precautions. Failure to do so may result in death or serious injury.  Stow cargo and luggage in the luggage compartment whenever possible.  Do not stack cargo and luggage in the luggage compartment higher than the seatbacks.
Page 333: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions.  Pre-winter preparations  Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 334 2-5. Driving information  Before driving the vehicle Perform the following according to the driving conditions:  Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 335 2-5. Driving information Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain: 3.0 mm (0.12 in.) 30.0 mm (1.18 in.) 10.0 mm (0.39 in.) Cross chain: 4.0 mm (0.16 in.) 25.0 mm (0.98 in.) 14.0 mm (0.55 in.)
Page 336 2-5. Driving information  Tire chain installation Observe the following precautions when installing and removing chains:  Install and remove tire chains in a safe location.  Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 337  Repairing or replacing snow tires (vehicles with the tire pressure warn- ing system) Request repairs or replacement of snow tires from any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 338: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 339: Interior Features
Interior features 3-1. Using the air conditioning 3-3. Using the interior lights system and defogger Interior lights list....368 • Front interior lights..369 Air conditioning system..340 • Personal lights ....370 Using the steering wheel • Rear interior light .... 370 climate remote control switches......
Page 340: 3-1. Using The Air Conditioning System And Defogger
3-1. Using the air conditioning system and defogger Air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting.  Outside temperature display ( P. 383) Fan speed Temperature Air outlet control button control button display Windshield Temperature Fan speed...
Page 341 3-1. Using the air conditioning system and defogger Using the automatic mode STEP Press Air outlets and fan speed are automatically adjusted according to the temperature setting. STEP Press “” to increase the temperature and “” to decrease the temperature on the STEP Press The cooling and dehumidification function switches between on and...
Page 342 3-1. Using the air conditioning system and defogger Adjusting the settings  Changing the cooling and dehumidification function Press The cooling and dehumidification function switches between on and off each time the button is pressed.  Adjusting the temperature setting Press “”...
Page 343 3-1. Using the air conditioning system and defogger  Changing the air outlets Press The air outlets switch each time the button is pressed. Air flows to the upper body. Air flows to the upper body and feet. PRIUS_OM_OM47A19E_(EE)
Page 344 3-1. Using the air conditioning system and defogger Mainly air flows to the feet. Air flows to the feet and the windshield defogger operates.  Switching between outside air and recirculated air modes Press The modes switches between (recycles air inside the vehicle) (introduces air from outside the vehicle) modes each time the button is pressed.
Page 345 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air mode. Pollen removal mode Press Outside air mode switches to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body.
Page 346 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets  Adjusting the air outlets Center outlets Direct air flow to the left or right, up or down. Right and left side outlets Direct air flow to the left or right, up or down.
Page 347 3-1. Using the air conditioning system and defogger  Opening and closing the air outlets Center outlets Open the vent. Close the vent. Right and left side outlets Open the vent. Close the vent. PRIUS_OM_OM47A19E_(EE)
Page 348 3-1. Using the air conditioning system and defogger  Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur.  Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
Page 349 OFF.  If air flow from the vents decreases dramatically The filter may be clogged. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  Operation of the air conditioning system in Eco drive mode...
Page 350 3-1. Using the air conditioning system and defogger  Ventilation and air conditioning odors  To let fresh air in, set the air conditioning system to the outside air mode.  During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system.
Page 351: Using The Steering Wheel Climate Remote Control Switches
3-1. Using the air conditioning system and defogger Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature control Outside air or recirculated air mode Adjusting the temperature setting Press “”...
Page 352 3-1. Using the air conditioning system and defogger  When operating the steering switches (vehicles with touch tracer dis- play)  The steering switches operation status is displayed on the instrument cluster for confirmation purposes. (P. 231)  Settings are shown on the multi-infor- mation display when the steering switch is operated.
Page 353: Solar Ventilation System
3-1. Using the air conditioning system and defogger  Solar Ventilation System The Solar Ventilation System uses energy provided by solar panel built into the roof to operate a fan contained within the air condition- ing system, allowing ventilation of the vehicle interior when the vehi- cle is parked in direct sunlight.
Page 354 3-1. Using the air conditioning system and defogger  Operating conditions The Solar Ventilation System may not operate under the following circum- stances due to a lack of power from the solar panel:  Low amount of sunlight  Ever when a part of the solar panel is cast by a shadow. ...
Page 355 3-1. Using the air conditioning system and defogger  Sounds when using the Solar Ventilation System If the amount of sunlight is insufficient, you may hear a sound coming from the air conditioning system. This is the sound of a control function to pre- serve the fan and does not indicate a malfunction.
Page 356: Remote Air Conditioning System
3-1. Using the air conditioning system and defogger  Remote Air Conditioning System The Remote Air Conditioning System uses electrical energy stored in the hybrid battery (traction battery) and allows the air conditioning to be operated by remote control.  Before leaving the vehicle Check the temperature setting of the air conditioning system.
Page 357 3-1. Using the air conditioning system and defogger  Operating conditions The system will only operate if all of the following conditions are met:  The shift position is in P.  The “POWER” switch is OFF.  All doors are closed. ...
Page 358 3-1. Using the air conditioning system and defogger  Conditions affecting operation The system may not start in the following situations:  The charge level of the hybrid battery (traction battery) is low (P. 52)  The air conditioning temperature is set at a high level or outside tempera- ture is low ...
Page 359 3-1. Using the air conditioning system and defogger CAUTION  Precautions for the Remote Air Conditioning System  Do not use the system if people are in the vehicle. • Even when the system is in use, the internal temperature may still reach a high level due to features such as the automatic shut-off.
Page 360: Rear Window And Outside Rear View Mirror Defoggers Switch
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers switch Defoggers are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. Left-hand drive vehicles Turns the rear window and outside rear view mirror defog- gers on/off...
Page 361 3-1. Using the air conditioning system and defogger CAUTION  When the outside rear view mirror defoggers are on Do not touch the outside surface of the rear view mirrors, as they can become very hot and burn you. NOTICE ...
Page 362: 3-2. Using The Audio System
3-2. Using the audio system Audio system types Vehicles with “touch screen” Type A Type B Refer to the ““touch screen” Owner’s manual”. The illustration is for a left-hand drive vehicles. Some button posi- tions are reversed for right-hand drive vehicles. PRIUS_OM_OM47A19E_(EE)
Page 363 3-2. Using the audio system Vehicles with a navigation system Refer to the “Navigation System Owner’s Manual”. The illustration is for a left-hand drive vehicles. Some button posi- tions are reversed for right-hand drive vehicles. Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel.
Page 364 3-2. Using the audio system ®  About Bluetooth (vehicles with “touch screen”) Bluetooth is a registered trade mark of Bluetooth SIG, Inc. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corpo- ration is under license.
Page 365 3-2. Using the audio system PRIUS_OM_OM47A19E_(EE)
Page 366 3-2. Using the audio system PRIUS_OM_OM47A19E_(EE)
Page 367: Using The Aux Port/Usb Port
3-2. Using the audio system  Using the AUX port/USB port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. STEP Open the console box lid. (P. 375) Connect the portable audio STEP device.
Page 368: 3-3. Using The Interior Lights
3-3. Using the interior lights Interior lights list Rear interior light (P. 370) Front interior/personal lights (P. 369) Shift lever lighting “POWER” switch lighting Foot lights (if equipped) Front door courtesy lights PRIUS_OM_OM47A19E_(EE)
Page 369: Front Interior Lights
3-3. Using the interior lights Front interior lights Front interior lights Type A Turns the lights off Turns the door position on Turns the lights on Type B Turns the lights off Turns the door position on Turns the lights on PRIUS_OM_OM47A19E_(EE)
Page 370: Personal Lights
3-3. Using the interior lights Personal lights and rear interior light Personal lights Type A Turns the lights on/off Type B Turns the lights on/off Rear interior light The light will turn on/off in con- junction with the front interior lights Turns the light on ITO34P111...
Page 371 3-3. Using the interior lights Rear interior light  Illuminated entry system The lights automatically turn on/off according to “POWER” switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed.  To prevent 12-volt battery discharge If the interior lights remain on when the door is not fully closed and the inte- rior light switch (door position on/off) is on, the lights will go off automatically...
Page 372: 3-4. Using The Storage Features
3-4. Using the storage features List of storage features Bottle holders Auxiliary boxes Glove boxes Cup holders Console box PRIUS_OM_OM47A19E_(EE)
Page 373 3-4. Using the storage features CAUTION  Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ...
Page 374: Glove Boxes
3-4. Using the storage features Glove boxes Glove boxes Upper glove box Push the button. Lower glove box Push the button.  Glove box light (lower glove box only) The glove box light turns on when the tail lights are on. CAUTION ...
Page 375: Console Box
3-4. Using the storage features Console box Console box Pull up the lever to release the lock. Lift the console box lid to open. CAUTION  While driving Keep the console box closed when not is use. In the event of sudden brak- ing or sudden swerving, an accident may occur due to an occupant being struck by the open console box or the items stored inside.
Page 376: Cup Holders
3-4. Using the storage features Cup holders Cup holders Front (type A) Lift the lid. Front (type B) Rear Pull down the armrest. PRIUS_OM_OM47A19E_(EE)
Page 377 3-4. Using the storage features Cup holders CAUTION  Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of sudden braking, sudden swerving or an accident and cause injury.
Page 378: Bottle Holders
3-4. Using the storage features Bottle holders Bottle holders ITO35P121 CAUTION  Items unsuitable for the bottle holder Do not place anything other than pet bottles in the bottle holders. Other items may be thrown out of the holders in the event of sudden braking, sudden swerving or an accident and cause injury.
Page 379: Auxiliary Boxes
3-4. Using the storage features Auxiliary boxes Auxiliary boxes Type A Type B (if equipped) Push the lid. The overhead console is useful temporarily storing small items. CAUTION  While driving Do not leave the overhead console open. Items may fall out and cause injury. ...
Page 380: Card Holder
3-4. Using the storage features Card holder Card holder (right-hand drive vehicles only) PRIUS_OM_OM47A19E_(EE)
Page 381: 3-5. Other Interior Features
3-5. Other interior features Sun visors To set the visor in the for- ward position, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side. ITO36P101 PRIUS_OM_OM47A19E_(EE)
Page 382: Vanity Mirrors
3-5. Other interior features Vanity mirrors Slide the cover to open. The light turns on when the cover is opened. ITO36P103 NOTICE  To prevent 12-volt battery discharge Do not leave the vanity lights on for extended periods while the hybrid sys- tem is off.
Page 383: Outside Temperature Display
3-5. Other interior features Outside temperature display The displayed temperature ranges from -40 °C (-40 °F) up to 50 °C (122 °F).  Operating conditions The “POWER” switch is in ON mode.  Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
Page 384: Power Outlets
3-5. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. Instrument panel Open the cover. Rear console box Open the cover.  The power outlets can be used when The “POWER”...
Page 385 3-5. Other interior features NOTICE  To avoid damaging the power outlets Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. ...
Page 386: Seat Heaters
3-5. Other interior features  Seat heaters Heats the left front seat Heats the right front seat The indicator light comes on. Press the button again to turn off the seat heater. The indicator light turns off.  The seat heaters can be used when The “POWER”...
Page 387 3-5. Other interior features CAUTION  Burns  Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 388: Armrest
3-5. Other interior features Armrest Pull the armrest down for use. NOTICE  To prevent damage to the armrest Do not place too much strain on the armrest. PRIUS_OM_OM47A19E_(EE)
Page 389: Assist Grips
3-5. Other interior features Assist grips An assist grip installed on the ceiling can be used to support your body while sitting on the seat. CAUTION  Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 390: Floor Mats
3-5. Other interior features Floor mats Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks STEP (clips) into the floor mat eye- lets.
Page 391 When installing the driver’s floor mat  Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats.  Only use floor mats designed for the driver’s seat. ...
Page 392: Luggage Compartment Features
3-5. Other interior features Luggage compartment features  Cargo hooks Raise the hook to use. The cargo hooks are provided for securing loose items.  Deck boards Center When using the auxiliary box, STEP turn knob “UNLOCK” position and open the lid.
Page 393 3-5. Other interior features Side Lift the side deck board to remove it.  Auxiliary boxes Center ITI35P139 Side PRIUS_OM_OM47A19E_(EE)
Page 394 3-5. Other interior features  First-aid kit holder Hold the first-aid kit with a band. To loosen To tighten The first-aid kit itself is not included as an original equip- ment.  Luggage cover Pull out the luggage cover and secure it to the hook brackets.
Page 395 3-5. Other interior features Removing the luggage cover Lift it up. Stowing the luggage cover Remove the side deck board and STEP open the center deck board. Adjust the cover so that “TOP” is STEP facing up. STEP Replace the side deck board and the center deck board. PRIUS_OM_OM47A19E_(EE)
Page 396 3-5. Other interior features CAUTION  When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions.  Caution while driving Keep the lid of each storage spaces closed while driving. In the event of sud- den braking or sudden swerving, an accident may occur due to an occupant being struck by an open auxiliary box or the items stored inside.
Page 397 Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior ..398 Cleaning and protecting the vehicle interior ..403 4-2. Maintenance Maintenance requirements....407 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ..... 410 Hood ......... 414 Positioning a floor jack..417 Engine compartment..
Page 398: Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition:  Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 399 • Do not use any metallic objects to remove condensation build up.  When the water-repellent performance has become insufficient, the coat- ing can be repaired. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 400 4-1. Maintenance and care CAUTION  When washing the vehicle Do not apply water to the inside of the engine compartment. Doing so may cause the electrical components etc. to catch fire.  Precautions regarding the exhaust pipe Exhaust gasses cause the exhaust pipe to become quite hot. When washing the vehicle, be careful not to touch the pipe until it has cooled sufficiently, as touching a hot exhaust pipe can cause burns.
Page 401 4-1. Maintenance and care NOTICE  To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.)  Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 402 4-1. Maintenance and care NOTICE  Antenna installation and removal precautions  Before driving, ensure that the antenna is installed.  When the antenna is removed, such as before entering an automatic car wash, make sure to store it in a suitable place so as not to lose it. Also, before driving, make sure to reinstall the antenna in its original position.
Page 403: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition:  Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 404 4-1. Maintenance and care  Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior.  Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 405 4-1. Maintenance and care NOTICE  Cleaning detergents  Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 406 4-1. Maintenance and care NOTICE  Water on the floor Do not wash the vehicle floor with water. Vehicle systems such as the audio system may be damaged if water comes into contact with electrical components such as the audio system above or under the floor of the vehicle.
Page 407: Maintenance Maintenance Requirements
Toyota dealer or repairer, or another duly qualified and equipped profes- sional. Any authorized Toyota dealer or repairer will keep a record of maintenance, which could be useful should you ever require Warranty Service.
Page 408  Where to go for maintenance service? In order to maintain your vehicle in the best possible condition, Toyota rec- ommends that all repairs and maintenance service operations be carried out by authorized Toyota dealers or repairers or other duly qualified and equipped professionals.
Page 409  Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. Your vehicle may need adjustment or repair.
Page 410: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
• Grease 12-volt battery condition • Conventional wrench (P. 430) (for terminal clamp bolts) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine/power control unit coolant organic acid technology.
Page 411 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (P. 462) as original • Bulb with same number and watt- age rating as original Light bulbs (P. 475) • Phillips-head screwdriver • Flathead screwdriver • Wrench Radiator and condenser ...
Page 412 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions.  When working on the engine compartment  Make sure that the indicator on the “POWER”...
Page 413 4-3. Do-it-yourself maintenance NOTICE  If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air.  If the brake fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 414: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. Pull up the auxiliary catch STEP lever and lift the hood. PRIUS_OM_OM47A19E_(EE)
Page 415 4-3. Do-it-yourself maintenance Hold the hood open by insert- STEP ing the supporting rod into either of the slots. Use the forward slot to open the hood normally, or use the rearward slot when the hood needs to be opened wide. CAUTION ...
Page 416 4-3. Do-it-yourself maintenance NOTICE  When closing the hood Be sure to return the support rod to its clip before closing the hood. Closing the hood without returning the support rod properly could cause the hood to bend. PRIUS_OM_OM47A19E_(EE)
Page 417: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement (such as under rear suspension etc.) may damage your vehicle or cause injury.  Front  Rear ITO43P106 PRIUS_OM_OM47A19E_(EE)
Page 418 4-3. Do-it-yourself maintenance CAUTION  When raising your vehicle Make sure to observe the following precautions to reduce the possibility of death or serious injury:  Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 419 4-3. Do-it-yourself maintenance CAUTION  Do not raise the vehicle while someone is in the vehicle.  When raising the vehicle, do not place any object on top of or underneath the floor jack.  When raising the vehicle, do not set the Rear suspension floor jack under the rear suspension.
Page 420: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Fuse box (P. 462) (P. 425) Radiator (P. 427) Engine oil level dipstick Condenser (P. 427) (P. 421) Electric cooling fans Engine oil filler cap Washer fluid tank (P. 428) (P. 422) Power control unit coolant reservoir (P.
Page 421 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick.  Checking the engine oil STEP Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 422 4-3. Do-it-yourself maintenance Flat dipstick Normal Excessive The shape of the dipstick may dif- fer depending on the type of vehi- cle or engine. Non-flat dipstick Normal Excessive The shape of the dipstick may dif- fer depending on the type of vehi- cle or engine.
Page 423 4-3. Do-it-yourself maintenance Make sure to check the oil type and prepare the items needed before adding oil. P. 593 Engine oil selection Oil quantity 1.5 L (1.6 qt., 1.3 Imp.qt.) (Low  Full) Items Clean funnel STEP Remove the oil filler cap by turning it counterclockwise. STEP Add engine oil slowly, checking the dipstick.
Page 424 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, service station or auto parts store for information concerning recycling or disposal.
Page 425 4-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the full (“FULL” or “F”) and low (“LOW” or “L”) lines on the reservoir when the hybrid system is cold. Engine coolant reservoir Reservoir cap “FULL” line “LOW”...
Page 426 Visually check the radiator, hoses, engine/power control unit coolant reser- voir caps, drain cock and water pump. If you cannot find a leak, have any authorized Toyota dealer or repairer, or another duly qualified and equipped professional test the cap and check for leaks in the cooling system.
Page 427 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional.
Page 428 4-3. Do-it-yourself maintenance Washer fluid Open the lid. STEP Check the washer fluid level on STEP the level gauge. “NORMAL” “LOW” If the washer fluid level is at STEP “LOW”, add washer fluid. PRIUS_OM_OM47A19E_(EE)
Page 429 4-3. Do-it-yourself maintenance CAUTION  When adding washer fluid Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE  Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
Page 430: 12-Volt Battery
4-3. Do-it-yourself maintenance 12-volt battery  Location The 12-volt battery is located in the right-hand side of lug- gage compartment.  Removing the 12-volt battery cover STEP Open the center deck board. (P. 392) STEP Remove the center auxiliary box. (P. 393) Remove the side deck board STEP and 12-volt battery cover.
Page 431 4-3. Do-it-yourself maintenance  Exterior Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp  Caution symbol The meanings of each caution symbol on the top of the battery are as follows: No smoking, no naked Battery acid...
Page 432 Restart the hybrid system, depress the brake pedal, and confirm that it is possible to shift into each shift position. If the system will not start even after multiple attempts at all methods above, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 433 4-3. Do-it-yourself maintenance CAUTION  Chemicals in the 12-volt battery The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12-volt battery: ...
Page 434 Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explo- sion. For replacement of the 12-volt battery, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 435 4-3. Do-it-yourself maintenance CAUTION  When disconnecting the 12-volt battery Do not disconnect the negative (-) termi- nal on the body side as shown. The dis- connected negative (-) terminal may touch the positive (+) terminal, which may cause a short and result in death or seri- ous injury.
Page 436: Tires
 Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that you rotate tires Front approximately every 10000 km (6000 miles). Vehicle with the tire pressure...
Page 437 ID codes must be registered in the tire pressure warn- ing computer and the tire pressure warning system must be initial- ized. Have tire pressure warning valve and transmitter ID codes registered by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. (P. 439) PRIUS_OM_OM47A19E_(EE)
Page 438 4-3. Do-it-yourself maintenance Initializing the tire pressure warning system (vehicles with the tire pressure warning system)  The tire pressure warning system must be initialized in the fol- lowing circumstances:  When rotating front and rear tires which have different tire infla- tion pressures ...
Page 439 ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 440 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 441 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 442 4-3. Do-it-yourself maintenance  Certification for tire pressure warning system (vehicles with the tire pressure warning system) PRIUS_OM_OM47A19E_(EE)
Page 443 4-3. Do-it-yourself maintenance PRIUS_OM_OM47A19E_(EE)
Page 444 4-3. Do-it-yourself maintenance PRIUS_OM_OM47A19E_(EE)
Page 445 4-3. Do-it-yourself maintenance For vehicles sold in Morocco PRIUS_OM_OM47A19E_(EE)
Page 446 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear.  Do not use tire sizes other than those recommended by Toyota.  Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 447 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or other qualified service shop as soon as possible.
Page 448 4-3. Do-it-yourself maintenance NOTICE  Low profile tires (vehicles with 17-inch tires) Low profile tires may cause greater damage than usual to the wheel when receiving impact from the road surface. Therefore pay attention to the follow- ing:  Be sure to use proper tire inflation pressure. If tires are under-inflated, they may be damaged more severely.
Page 449: Tire Inflation Pressure
 Reduced driving comfort and tire life  Reduced safety  Damage to the drive train If a tire needs frequent inflating, have it checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 450 4-3. Do-it-yourself maintenance  Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following:  Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1.5 km or 1 mile, you will get an accurate cold tire inflation pressure reading.
Page 451 4-3. Do-it-yourself maintenance CAUTION  Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury:  Excessive wear  Uneven wear ...
Page 452: Wheels
 Bent wheels that have been straightened  Aluminum wheel precautions  Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels.  When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 453 4-3. Do-it-yourself maintenance  When replacing wheels (vehicles with the tire pressure warning sys- tem) The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and transmit- ters must be installed.
Page 454 Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional or other qualified service shop. In addition, make sure to...
Page 455: Air Conditioning Filter
Left-hand drive vehicles When cleaning or replacing the air conditioning filter, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Right-hand drive vehicles When cleaning or replacing the air conditioning filter, follow the procedure below.
Page 456 4-3. Do-it-yourself maintenance Push each side of the glove STEP box to release the pins. Then disconnect the claws at the bottom and remove the glove box. ITO43P122 Remove the filter cover. STEP ITO43P124 Slide and pull out the filter. STEP ITO43P169 PRIUS_OM_OM47A19E_(EE)
Page 457 2 minutes at 500 kPa (5.0 kgf/cm or bar, 72 psi). If an air gun is not available, have the filter cleaned by any authorized Toyota dealer or repairer, or another duly quali- fied equipped profes- sional. ...
Page 458 Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, please refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”.) ...
Page 459: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted.  You will need the following items:  Flathead screwdriver  Lithium battery CR1632  Replacing the battery Take out the mechanical key. STEP Remove the cover.
Page 460 When installing, reverse the steps listed.  Use a CR1632 lithium battery  Batteries can be purchased at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional, local electrical appli- ance shops or camera stores. ...
Page 461 4-3. Do-it-yourself maintenance CAUTION  Removed battery and other parts These parts are small and if swallowed by a child, they can cause choking. Keep away from children. Failure to do so could result in death or serious injury.  Certification for the smart entry &...
Page 462: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “POWER” switch off. Vehicles with Solar Ventilation System: Turn the Solar Ventilation System off and make sure not to operate the Remote Air Condi- tioning System.
Page 463 4-3. Do-it-yourself maintenance Left side instrument panel (right-hand drive vehicles) Remove the cover. Remove the lid. ITO43P130 STEP After a system failure, see “Fuse layout and amperage rat- ings” (P. 466) for details about which fuse to check. PRIUS_OM_OM47A19E_(EE)
Page 464 4-3. Do-it-yourself maintenance STEP Remove the fuse. Only type A fuse can be removed using the pullout tool. STEP Check if the fuse is blown. Type A Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating.
Page 465 4-3. Do-it-yourself maintenance Type B Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating.
Page 466 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings  Engine compartment FUSE Ampere Circuit Air conditioning system Electric cooling fans Electric cooling fans S-HORN S-HORN ENG W/P Cooling system ABS MAIN 7.5A Anti-lock brake system NO.2 H-LP CLN Headlight cleaner P-CON MTR Shift control system, transmission PRIUS_OM_OM47A19E_(EE)
Page 467 4-3. Do-it-yourself maintenance FUSE Ampere Circuit AMP NO.1 Audio system IGCT PCU, IGCT NO.2, IGCT NO.3 DC/DC-S Inverter and converter Shift control system, P position P CON MAIN 7.5A switch 7.5A Power management system Smart entry & start system, hybrid ECU-B2 7.5A system...
Page 468 4-3. Do-it-yourself maintenance FUSE Ampere Circuit ABS MTR 1 Anti-lock brake system ABS MTR 2 Anti-lock brake system H-LP HI MAIN Headlight high beams 7.5A Daytime running lights AMP NO.2 Audio system, navigation system P/I 1 IG2, EFI MAIN, BATT FAN Electric power steering H-LP RH LO Right-hand headlight (low beam)
Page 469 4-3. Do-it-yourself maintenance FUSE Ampere Circuit Smart entry & start system, per- ECU-B 7.5A sonal lights, gauges and meters, emergency flashers H-LP LH HI Left-hand headlight (high beam) H-LP RH HI Right-hand headlight (high beam) Multiport fuel injection system/ EFI NO.2 sequential multiport fuel injection system IGCT NO.3...
Page 470 4-3. Do-it-yourself maintenance  Left side instrument panel 9 10 15 16 17 18 20 21 23 24 25 26 27 28 29 30 ITO43P133 FUSE Ampere Circuit Power outlets Multiplex communication system, outside rear view mirrors, driver ECU-ACC support system, audio system, navigation system, intelligent park- ing guidance system PWR OUTLET...
Page 471 4-3. Do-it-yourself maintenance FUSE Ampere Circuit PWR SEAT FL Front seat lumbar support 7.5A On-board diagnosis system RR FOG 7.5A Rear fog light Stop lights, high mounted stop- STOP light, brake system, driver support system P FR DOOR Power windows D FR DOOR Power windows DOOR RR...
Page 472 4-3. Do-it-yourself maintenance FUSE Ampere Circuit Headlight leveling system, gauges GAUGE and meters, emergency flashers, turn signal lights Air conditioning system, Solar Ventilation System, Remote Air Conditioning System WASHER Windshield washer RR WIP Rear window wiper and washer Windshield wipers 7.5A Gauges and meters Brake system, driver support sys-...
Page 473 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 475)  If the replaced fuse blows again, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 474 Doing so may cause electric shock, resulting in death or serious injury. NOTICE  Before replacing fuses Have the cause of electrical overload determined and repaired by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped pro- fessional as soon as possible. PRIUS_OM_OM47A19E_(EE)
Page 475: Light Bulbs
You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. As there is a danger that components may be damaged, we recommend that replacement is carried out by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. ...
Page 476 4-3. Do-it-yourself maintenance  Rear bulb locations Rear turn signal light Rear fog light (right- Rear fog light (left- hand drive vehicles) hand drive vehicles) or back-up light or back-up light License plate lights Replacing light bulbs  Headlight low beams (halogen headlights) STEP Turn the bulb base counterclock- wise.
Page 477 4-3. Do-it-yourself maintenance Unplug connector while STEP pressing the lock release. ITO43P163 Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the...
Page 478 4-3. Do-it-yourself maintenance  Headlight high beams STEP Turn the bulb base counterclockwise. Vehicles with halogen headlights Vehicles with LED headlights Unplug connector while STEP pressing the lock release. ITO43P165 PRIUS_OM_OM47A19E_(EE)
Page 479 4-3. Do-it-yourself maintenance Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlights on once and visually confirm that no light is leaking through the mounting.
Page 480 4-3. Do-it-yourself maintenance  Front position lights (halogen headlights) Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ITO43P167 STEP When installing, reverse the steps listed. PRIUS_OM_OM47A19E_(EE)
Page 481 4-3. Do-it-yourself maintenance  Front fog lights Remove the fender liner bolt and STEP clip and pull down the fender liner. Unplug connector while STEP pressing the lock release. Turn the bulb base counterclock- STEP wise. PRIUS_OM_OM47A19E_(EE)
Page 482 4-3. Do-it-yourself maintenance STEP When installing, reverse the steps listed. After installing the bulb base, shake the bulb base gently to check that it is not loose. Insert the clip. PRIUS_OM_OM47A19E_(EE)
Page 483 4-3. Do-it-yourself maintenance  Front turn signal lights STEP Remove the fender liner bolt and clip and pull down the fender liner. (P. 481) Type A Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP PRIUS_OM_OM47A19E_(EE)
Page 484 4-3. Do-it-yourself maintenance Type B Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ITO43P144 STEP When installing, reverse the steps listed. Insert the clip. PRIUS_OM_OM47A19E_(EE)
Page 485 4-3. Do-it-yourself maintenance  Rear turn signal lights and back-up/rear fog lights Open the back door and remove STEP the cover. Turn the bulb base counterclock- STEP wise. Rear turn signal light Back-up/rear fog light Remove the light bulb. STEP Rear turn signal light Back-up/rear fog light ITO43P147...
Page 486 4-3. Do-it-yourself maintenance  License plate lights Open the back door and remove STEP the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counterclock- STEP wise. ITO43P149 Remove the light bulb. STEP ITO43P150 STEP...
Page 487 LEDs. If any of the LEDs burn out, take your vehicle to any authorized Toyota dealer or repairer, or another duly qualified and equipped professional to have the light replaced.
Page 488 4-3. Do-it-yourself maintenance  When replacing light bulbs P. 474 CAUTION  Replacing light bulbs  Be sure to stop the hybrid system and turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns.
Page 489: When Trouble Arises
When trouble arises 5-1. Essential information Emergency flashers ..490 If your vehicle needs to be towed ......491 If you think something is wrong ......498 5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer sounds ......
Page 490: Essential Information Emergency Flashers
5-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 491: If Your Vehicle Needs To Be Towed
In the following situations, it is not possible to be towed by another vehicle using cables or chains, as the front wheels may be locked due to the parking lock. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or a commercial towing service.
Page 492 5-1. Essential information Situations needs to contact dealers before towing The following may indicate a problem with your hybrid transmission. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or a commercial towing service before towing.
Page 493 From the rear Use a towing dolly under the front wheels. Using a flatbed truck If your Toyota is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 494 5-1. Essential information Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for short distances at low speeds.
Page 495 5-1. Essential information Tighten down the towing eyelet STEP securely using a wheel nut wrench or hard metal bar. STEP Securely attach a cable or chain to the towing eyelet. Take care not to damage the vehicle body. STEP Enter the vehicle being towed and start the hybrid system. If the hybrid system does not start, turn the “POWER”...
Page 496 5-1. Essential information CAUTION Observe the following precautions. Failure to do so may result in death or serious injury.  When towing the vehicle Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
Page 497 5-1. Essential information NOTICE  To prevent damage to the vehicle when towing using a wheel-lift type truck When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
Page 498: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible.
Page 499: 5-2. Steps To Take In An Emergency
However, if this continues to occur, have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 500 The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 501 5-2. Steps to take in an emergency Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
Page 502 5-2. Steps to take in an emergency Warning light Warning light/Details Pre-crash safety system warning light Indicates a malfunction in the pre-crash safety system The warning light will operate as follows, even when the system is not malfunctioning: • The light will flash quickly when the system is operating. (Flashes) (P.
Page 503 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Correction Warning light Warning light/Details procedure Open door warning light (warning buzzer) Check that all the Indicates that a door is doors are closed.
Page 504 • Natural causes (P. 506) is adjusted, have • Flat tire (P. 528, 543) the system checked by any (If equipped) authorized Toyota dealer or repairer, or another duly qualified and equipped profes- sional. Have the system checked by any...
Page 505 5-2. Steps to take in an emergency Correction Warning light Warning light/Details procedure Master warning light The warning light comes on and flashes to indicate P. 510 that the master warning system has detected a malfunction. : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 5 km/h [3 mph]).
Page 506 5-2. Steps to take in an emergency  Electric power steering system warning light (warning buzzer) When the 12-volt battery charge becomes insufficient or the voltage tempo- rarily drops, the electric power steering system warning light may come on and the warning buzzer may sound. ...
Page 507 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings  If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ...
Page 508 If the tire pressure warning light frequently comes on after blinking for 1 min- ute when the “POWER” switch is turned to ON mode, have it checked by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 509 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 510: If A Warning Message Is Displayed
If any of the warning light turns on again after performing the fol- lowing actions, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 511 The following warnings indicate the possibility of dam- age to the vehicle that may lead to an accident. Immediately stop the vehicle in a safe place and contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 512 Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional immedi- ately.
Page 513 5-2. Steps to take in an emergency Warning message Details Indicates a malfunction in the shift control system communication. A buzzer also sounds. The automatically P position selection function (P. 212) may not function. Before turning the “POWER” switch off, securely press the P position switch, and be sure to check that the shift position is in P by verifying the shift position indicator or P posi- tion switch indicator lights.
Page 514 5-2. Steps to take in an emergency Warning message Details Indicates a malfunction in the pre-crash safety sys- tem. (Flashes) A buzzer also sounds. (If equipped) Indicates a malfunction in: • The cruise control system; or • The dynamic radar cruise control system A buzzer also sounds.
Page 515 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning message turns off. Correction Warning message Details procedure • Check the grille • Indicates that the pre-crash and the sensor and safety system is not currently clean them if they...
Page 516 5-2. Steps to take in an emergency Correction Warning message Details procedure Indicates that there is a high possibility of a frontal collision, or that the pre-crash braking function is operating. Slow the vehicle by A buzzer also sounds. applying the At the same time, (Flashes brakes.
Page 517 5-2. Steps to take in an emergency Correction Warning message Details procedure The hybrid system has over- heated. This message may be dis- played when driving under severe operating conditions, and the output of the hybrid Stop and check. system may temporarily (P.
Page 518 5-2. Steps to take in an emergency Correction Warning message Details procedure The hybrid battery (traction battery) power has dropped Restart the hybrid because a long period of time system when start- has elapsed after shifting the ing the vehicle. shift position to N.
Page 519 5-2. Steps to take in an emergency Correction Warning message Details procedure • To shift the shift position to P, stop the vehicle com- Pressed the P position switch pletely and press while the vehicle is running. the P position A buzzer also sounds.
Page 520 (traction battery) tem (traction battery) cooling cooling component component is required at any authorized The filter may be clogged, or Toyota dealer or the air vent or duct may be repairer, or another blocked. duly qualified and equipped profes- sional.
Page 521 5-2. Steps to take in an emergency Have the malfunction repaired immediately. If any of the following warnings is displayed when a hybrid system start operation is performed, perform the appropriate action accord- ing to the warning message display. Correction Warning message Details procedure...
Page 522 5-2. Steps to take in an emergency Have the malfunction repaired immediately. After taking the specified steps to correct the suspected problem, check that the warning message and light turn off. Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic Confirm key is not...
Page 523 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The driver’s door is opened and closed Turn the while the elec- “POWER” tronic key is out- switch to side the OFF or detection range Once 3 times confirm...
Page 524 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic key has been Turn the taken outside “POWER” the vehicle and switch to Contin- the doors have Once OFF and uous been locked lock the without first doors...
Page 525 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure An attempt to lock the doors has been made using the smart entry & start system while the electronic key is inside the vehicle. Take the With the key electronic...
Page 526 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The driver’s door is opened and closed while the elec- • Shift the tronic key is out- shift posi- side the tion to P. Contin- Contin- detection range...
Page 527 5-2. Steps to take in an emergency Interior Exterior Correction Warning message Details buzzer buzzer procedure The elec- tronic key  P. 569 Once does not operate (Flashes) properly. Next time when starting the Power hybrid system, increase the turned off engine speed due to ...
Page 528: If You Have A Flat Tire (Vehicles With A Spare Tire)
5-2. Steps to take in an emergency If you have a flat tire (vehicles with a spare tire) Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire.  Before jacking up the vehicle ...
Page 529 5-2. Steps to take in an emergency Taking out the jack Turn the knob to the “UNLOCK” STEP position to unfasten the lock, and remove the center deck board. Fold the center deck board toward the front of the vehicle, and unload it from the vehicle.
Page 530 5-2. Steps to take in an emergency Taking out the spare tire Loosen the center fastener that secures the spare tire. CAUTION  Service plug Be careful not to hit the service plug when loading or unloading the tool holder or the spare tire. (P. 45) PRIUS_OM_OM47A19E_(EE)
Page 531 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 532 5-2. Steps to take in an emergency STEP Slightly loosen the wheel nuts (one turn). ITO52P108 Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground.
Page 533 5-2. Steps to take in an emergency Remove all the wheel nuts and STEP the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface. ITO52P114 Installing the spare tire Remove any dirt or foreign mat- STEP...
Page 534 5-2. Steps to take in an emergency Replacing an aluminum wheel with a compact spare tire Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel seat. Disc wheel seat Replacing an aluminum wheel with an aluminum wheel Turn the nut washers until they Disc wheel come into contact with the disc...
Page 535 5-2. Steps to take in an emergency Lower the vehicle. STEP ITO52P119 Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 103 N m (10.5 kgf m, 76 ft lbf) • •...
Page 536 5-2. Steps to take in an emergency  The compact spare tire  The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ...
Page 537 5-2. Steps to take in an emergency  Certification for the jack PRIUS_OM_OM47A19E_(EE)
Page 538 5-2. Steps to take in an emergency CAUTION  When using the compact spare tire  Remember that the spare tire provided is specifically designed for use with your vehicle. Do not use your spare tire on another vehicle.  Do not use more than one spare tire simultaneously.
Page 539 5-2. Steps to take in an emergency CAUTION  When the compact spare tire is attached The vehicle speed may not be correctly detected, and the following systems may not operate correctly:  ABS & Brake assist    Cruise control (if equipped) ...
Page 540 5-2. Steps to take in an emergency CAUTION  Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. Observe the following precautions:  Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 541 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional. • When installing the wheel nuts, be sure to install the wheel nuts with the tapered ends facing inward.
Page 542 When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as the tire pressure warn- ing valve and transmitter may be damaged if not handled correctly.
Page 543: If You Have A Flat Tire (Vehicles Without A Spare Tire)
After temporarily repairing the tire with the kit, have the tire repaired or replaced by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 544 5-2. Steps to take in an emergency  Emergency tire puncture repair kit components Bottle Stickers Hose Air release cap PRIUS_OM_OM47A19E_(EE)
Page 545 5-2. Steps to take in an emergency Compressor Air pressure gauge Compressor switch Power plug PRIUS_OM_OM47A19E_(EE)
Page 546 5-2. Steps to take in an emergency Before performing emergency repair Check the degree of the tire damage. A tire should only be repaired with the emergency tire puncture repair kit if the damage is caused by a nail or screw passing through the tire tread.
Page 547 5-2. Steps to take in an emergency  In the following cases, the tire cannot be repaired with the emergency tire puncture repair kit. Contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.  When the tire is damaged due to driving without sufficient air pressure ...
Page 548 5-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Remove the center deck board. STEP Remove the center auxiliary box. STEP Take out the emergency tire STEP puncture repair kit. PRIUS_OM_OM47A19E_(EE)
Page 549 5-2. Steps to take in an emergency CAUTION  Service plug Be careful not to hit the service plug when loading or unloading the emer- gency tire puncture repair kit. (P. 45) Emergency repair method STEP Take out the repair kit from the plastic bag. Remove the valve cap from the STEP valve of the punctured tire.
Page 550 5-2. Steps to take in an emergency Connect the hose to the valve. STEP Screw the end of the hose clock- wise as far as possible. Make sure that the compressor STEP switch is off. Remove the rubber stopper from STEP the compressor.
Page 551 5-2. Steps to take in an emergency STEP Connect the power plug to the power outlet socket. (P. 384) Instrument panel Rear console box PRIUS_OM_OM47A19E_(EE)
Page 552 If you are unable to apply the stickers, inform nearest authorized Toyota dealer, tire dealer or repairer, or another duly qualified and equipped profes- sional that sealant has been applied to the puncture when hav- ing the tire repaired or replaced.
Page 553 5-2. Steps to take in an emergency STEP Check the specified tire inflation pressure. Tire inflation pressure is specified on the label on the driver’s side pillar as shown. (P. 598) Left-hand drive vehicles ITO52P163 Right-hand drive vehicles ITO52P164 STEP Start the hybrid system.
Page 554 5-2. Steps to take in an emergency Inflate the tire until the specified STEP air pressure is reached. The sealant will be injected and the pressure will spike to 300 kPa (3.1 kgf/cm or bar, 44 psi) or 400 kPa (4.1 kgf/cm or bar, 58 psi), and then gradually decrease.
Page 555 (40 minutes at low tem- perature) with the switch on, the tire is too damaged to be repaired. Turn the compressor switch off and contact any authorized Toyota dealer or repairer, or another duly quali- fied equipped profes- sional.
Page 556 5-2. Steps to take in an emergency STEP With the compressor switch off, disconnect the hose from the valve on the tire and then pull out the power plug from the power outlet socket. Some sealant may leak when the hose is removed. STEP Install the valve cap onto the valve of the emergency repaired tire.
Page 557 5-2. Steps to take in an emergency STEP Temporarily store the bottle in the luggage compartment while it is connected to the compressor. STEP To spread the liquid sealant evenly within the tire, immediately drive safely for about 5 km (3 miles) below 80 km/h (50 mph). After driving for about 5 km (3 STEP miles), stop your vehicle in a...
Page 558 If the tire inflation pressure is under 130 kPa (1.3 kgf/cm bar, 19 psi): The puncture can- not be repaired. Contact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped profes- sional. If the tire inflation pressure is 130 kPa (1.3 kgf/cm...
Page 559 Taking precautions to avoid sudden braking, sudden accelera- tion and sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest authorized Toyota dealer or repairer, or another duly qualified and equipped professional for tire repair or replacement.
Page 560 5-2. Steps to take in an emergency  If the tire is inflated to more than the specified air pressure STEP Disconnect the hose from the valve. Install the air release cap to the end of the STEP hose and push the protrusion on the air release cap into the tire valve to let some air out.
Page 561 The sealant stored in the emergency tire puncture repair kit can be used only once to temporarily repair a single tire. If the sealant has been used and needs to be purchased, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 562 5-2. Steps to take in an emergency CAUTION  Do not drive the vehicle with a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 563 5-2. Steps to take in an emergency CAUTION  When fixing the flat tire  Stop your vehicle in a safe and flat area.  Do not touch the wheels or the area around the brakes immediately after the vehicle has been driven. After the vehicle has been driven, the wheels and the area around the brakes may be extremely hot.
Page 564 5-2. Steps to take in an emergency CAUTION  The repair kit may overheat if operated for a long period of time. Do not operate the repair kit continuously for more than 60 minutes.  Parts of the repair kit become hot during operation. Be careful handling the repair kit during and after operation.
Page 565 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or other qualified service shop as soon as possible.
Page 566: If The Hybrid System Will Not Start
5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure:  The hybrid system will not start even though the correct starting procedure is being followed (P.
Page 567  One or both of the 12-volt battery terminals may be discon- nected.  The 12-volt battery may be discharged. (P. 572) Contact any authorized Toyota dealer or repairer, or another duly quali- fied and equipped professional if the problem cannot be repaired, or if repair procedures are unknown.
Page 568: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional using the other key and the key number stamped on your key number plate.
Page 569: If The Electronic Key Does Not Operate Properly
5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is inter- rupted (P. 84) or the electronic key cannot be used because the battery is depleted, the smart entry & start system and wireless remote control cannot be used.
Page 570 Press the “POWER” switch within 10 seconds of the buzzer sounding, keeping the brake pedal depressed. In the event that the hybrid system still cannot be operated, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 571 5-2. Steps to take in an emergency  Stopping the hybrid system Set the parking brake, shift the shift position to P and press the “POWER” switch as you normally do when stopping the hybrid system.  Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 572: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid system if the vehicle’s 12-volt battery is discharged. You can also call any authorized Toyota dealer or repairer, or another duly qualified and equipped professional or a qualified repair shop.
Page 573 5-2. Steps to take in an emergency STEP Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the exclusive jump starting terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 574 When installing, first hook the fuse box cover onto the two rear tabs. Once the hybrid system starts, have the vehicle inspected at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. PRIUS_OM_OM47A19E_(EE)
Page 575 5-2. Steps to take in an emergency  Starting the hybrid system when the 12-volt battery is discharged The hybrid system cannot be started by push-starting.  To prevent 12-volt battery discharge  Turn off the headlights and the audio system while the hybrid system is off.
Page 576 5-2. Steps to take in an emergency CAUTION  Avoiding 12-volt battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the 12-volt battery:  Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 577 CAUTION  After recharging the 12-volt battery Have the 12-volt battery inspected at any authorized Toyota dealer or repairer, or another duly qualified and equipped professional as soon as possible. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 578: If Your Vehicle Overheats
5-2. Steps to take in an emergency If your vehicle overheats The following may indicate that your vehicle is overheating.  The high coolant temperature warning light (P. 500) comes on or flashes, or a loss of hybrid system power is experienced. (For example, the vehicle speed does not increase.) ...
Page 579 (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact any autho- rized Toyota dealer or repairer, or another duly qualified equipped professional. The coolant level is satisfactory if STEP it is between the “FULL”...
Page 580 STEP If the fans are not operating: Stop the hybrid system immediately and contact any autho- rized Toyota dealer or repairer, or another duly qualified and equipped professional. If the fans are operating: Have the vehicle inspected at the nearest any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 581 (radiator) for any leaks. Radiator Cooling fans If a large amount of coolant leaks, immediately contact any autho- rized Toyota dealer or repairer, or another duly qualified equipped professional. The coolant level is satisfactory if STEP it is between the “F”...
Page 582 If the message is not displayed: The hybrid system temperature has dropped and the vehi- cle may be driven normally. However, if the message appears again frequently, contact any authorized Toyota dealer or repairer, or another duly qualified and equipped professional. PRIUS_OM_OM47A19E_(EE)
Page 583 5-2. Steps to take in an emergency CAUTION  To prevent an accident or injury when inspecting under the hood of your vehicle  If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injuries such as burns.
Page 584: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: STEP Set the parking brake and shift the shift position to P. Stop the hybrid system.
Page 585 5-2. Steps to take in an emergency NOTICE  To avoid damage to the hybrid transmission and other components  Avoid spinning the wheels and depressing the accelerator pedal more than necessary.  If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
Page 586: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
Page 587 5-2. Steps to take in an emergency CAUTION  If the hybrid system has to be turned off while driving Power assist for the steering will be lost, making the steering wheel heavier to turn. Decelerate as much as possible before turning off the hybrid system. PRIUS_OM_OM47A19E_(EE)
Page 588 5-2. Steps to take in an emergency PRIUS_OM_OM47A19E_(EE)
Page 589 Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.)..590 Fuel information ....601 6-2. Customization Customizable features ..603 6-3. Initialization Item to initialize ....611 PRIUS_OM_OM47A19E_(EE)
Page 590: Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 4480 mm (176.4 in.) Overall width 1745 mm (68.7 in.) 1490 mm (58.7 in.) Overall height 1505 mm (59.3 in.) Wheelbase 2700 mm (106.3 in.) 1525 mm (60.0 in.) Front 1515 mm (59.6 in.) Tread...
Page 591 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 592 6-1. Specifications  Engine number The engine number is stamped on the engine block as shown. Engine Model 2ZR-FXE Type 4-cylinder in line, 4-cycle, gasoline 80.5  88.3 mm (3.17  3.48 in.) Bore and stroke Displacement 1798 cm (109.7 cu.in.) Valve clearance Automatic adjustment (engine cold)
Page 593 6-1. Specifications Electric motor (Traction motor) Type Permanent magnet motor Maximum output 60 kW Maximum torque 207 N•m (21.1 kgf•m, 153 ft•lbf) Hybrid battery (traction battery) Type Nickel-Metal hydride battery Voltage 7.2 V/module Capacity 6.5 Ah (3HR) Quantity 28 modules Overall voltage 201.6 V Lubrication system...
Page 594 6-1. Specifications  Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”...
Page 595 6-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 596 Power control 2.1 L (2.2 qt., 1.8 Imp.qt.) unit Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 597 NOTICE  Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. PRIUS_OM_OM47A19E_(EE)
Page 598 6-1. Specifications Brakes Left-hand drive vehicles 77 mm (3.03 in.) Min. Pedal clearance Right-hand drive vehicles 80 mm (3.15 in.) Min. 1.0  6.0 mm (0.04  0.24 in.) Pedal free play 8 11 clicks Parking brake pedal travel • SAE J1703 or FMVSS No. 116 DOT 3 Fluid type •...
Page 599 6-1. Specifications 17-inch tires Tire size 215/45R17 87W Front tire Tire inflation pressure 230 kPa (2.3 kgf/cm or bar, 33 psi) (Recommended cold tire Rear tire inflation pressure) 220 kPa (2.2 kgf/cm or bar, 32 psi) 17  7J Wheel size Wheel nut torque 103 N•m (10.5 kgf•m, 76 ft•lbf) Compact spare tire (if equipped)
Page 600 6-1. Specifications Light bulbs Light Bulbs Type Halogen headlights Low beam High beam LED headlights High beam Front fog lights Front turn signal lights Exterior Front position lights (halogen headlights) Rear turn signal lights Back-up lights Rear fog light License plate lights Front interior/personal lights Rear interior light Interior...
Page 601: Fuel Information
Research Octane Number of 95 or higher.  Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps.  If your engine knocks ...
Page 602 “E50” or “E85” and fuel containing a large amount of ethanol should not be used. The use of these fuels will damage the vehicle’s fuel system. In case of any doubt, ask any authorized Toyota dealer or repairer, or another duly qualified and equipped professional.
Page 603: Customization Customizable Features
(For further information on customizing settings using the naviga- tion system, refer to the “Navigation System Owner’s Manual”.) Settings that can be changed by any authorized Toyota dealer or repairer, or another duly qualified and equipped professional Definition of symbols: O = Available, — = Not available...
Page 604 6-2. Customization Custom- Default Item Function ized setting setting Smart entry & start sys- Smart entry & start system (P. 73) Wireless remote – – control Wireless remote Buzzer sounds control when pushing – – (P. 98) with any door not closed Operation signals –...
Page 605 6-2. Customization Custom- Default Item Function ized setting setting Operation when doors are Alarm unlocked using – – (P. 149) the mechanical The one-touch Power closing operation windows – – except for (P. 128) driver’s seat Automatic light control Light sensor Levels 1 to Level 3 system...
Page 606 6-2. Customization Custom- Default Item Function ized setting setting Operation after the “POWER” – – switch turned Operation when you approach the vehicle with the electric key on your person – – Illumination (When the per- (P. 368) sonal/interior light main switch is door position) Foot lights –...
Page 607 6-2. Customization Custom- Default Item Function ized setting setting Sensor sensitiv- ity for darkening the brightness of the meter, navi- gation system -2 to +2 – – and instrument panel depend- ing on the out- side brightness Meter and instrument Sensor sensitiv- panel ity for returning...
Page 608 6-2. Customization Custom- Default Item Function ized setting setting Switching between outside air and recircu- – Automatic lated air mode linked to “AUTO” conditioning switch operation system Heating/cooling (P. 340) operation mini- – – mized in Eco drive mode PRIUS_OM_OM47A19E_(EE)
Page 609 6-2. Customization Custom- Default Item Function ized setting setting Push once Push twice Operation using Push and the “A/C” button Push and hold for 0.8 – – on the wireless hold for 2.4 seconds remote control seconds Remote Air Condition- Push once ing System Push and...
Page 610 6-2. Customization Custom- Default Item Function ized setting setting Reverse Operation sig- warning nals (Buzzer) Beeps Beeps – – buzzer when shifting repeatedly once (P. 223) into R Multi-information display (P. 240) Left-hand drive vehicles English, French, German, Italian, Spanish and Russian Available languages Right-hand drive vehicles...
Page 611: Initialization Item To Initialize
6-3. Initialization Item to initialize The following item must be initialized for normal system operation after such cases as the 12-volt battery being reconnected, or mainte- nance being performed on the vehicle. Item When to initialize Reference • When rotating the tires on vehicles Tire pressure warning with differing front and rear tire infla- P.
Page 612 6-3. Initialization PRIUS_OM_OM47A19E_(EE)
Page 613: Index
Index Abbreviation list ...... 614 Alphabetical index....615 What to do if......626 Vehicles with a “touch screen”: For details of equipment related to the “touch screen”, such as the audio system, refer to the ““touch screen” Owner’s manual”. Vehicles with a navigation system: For details of equipment related to the navigation sys- tem and touch screen, such as the audio systems, refer...
Page 614: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Charge Child Restraint System DISP Display Economy/Ecology Electronic Control Unit Emergency Locking Retractor Electric Power Steering Electric Vehicle Intelligent Parking Assist Light Emitting Diode On Board Diagnostics Pre-Crash Safety System Power Supplemental Restraint System TPMS...
Page 615: Alphabetical Index
Alphabetical index Alphabetical index Alarm ........149 Air conditioning filter....455 Antenna ........402 Automatic air conditioning Anti-lock brake system ... 313 system ........ 340 Armrest........388 ABS ........... 313 Assist grips ......389 Active head restraint ....109 Audio input ......
Page 616 Alphabetical index Back door Camera Back door......103 Care Smart entry & start system..73 Exterior ......... 398 Wireless remote control ..98 Interior........403 Back-up lights Seat belts......404 Replacing light bulbs..... 475 Cargo hooks......392 Wattage......... 600 CD player Battery Chains........
Page 617 Alphabetical index Child safety Daytime running light Airbag precautions ....167 system........270 Back door precautions ..105 Deck board ....... 392 Child restraint system ... 174 Defogger Child-protectors..... 101 Rear window ......360 How your child should wear Side mirrors ......360 the seat belt ......
Page 618 Alphabetical index Eco drive mode switch.... 220 Engine Electric power steering ... 313 Accessory mode ....210 Electronic key Compartment ......420 If the electronic key does not Hood ........414 operate properly ....569 How to start the hybrid Replacing battery ....
Page 619 Alphabetical index Floor mats ........ 390 Gauges ........230 Fluid Glove boxes ......374 Brake........598 Washer........428 Hands-free system Fog lights (for cellular phone) Replacing light bulbs..... 475 Hazard lights Switch ........272 Switch ........490 Wattage......... 600 Head restraints Foot lights ........
Page 620 Alphabetical index Identification Language........610 Engine........592 License plate lights Vehicle ........591 Replacing light bulbs..... 475 Ignition switch......208 Wattage ........ 600 Illuminated entry system..371 Light bulbs Immobilizer system ....142 Replacing......475 Indicator lights ......235 Wattage ........ 600 Initialization Lights Item to initialize .....
Page 621 Alphabetical index Maintenance Parking brake......228 Do-it-yourself PCS ........... 321 maintenance .......410 Personal lights Maintenance data ....590 Switch ........370 Maintenance Wattage ........ 600 requirements.......407 Pollen removal mode ....345 Meter Power outlets ......384 Instrument cluster light “POWER” switch ..... 208 control.........
Page 622 Alphabetical index Seat belt reminder light... 503 Side airbags ......158 Seat belts Side mirrors Adjusting the seat belt... 118 Adjusting and folding .... 126 Child restraint system Smart entry & start system installation......184 Antenna location ..... 76 Cleaning and maintaining Entry functions ......
Page 623 Alphabetical index Power door lock switch ..100 Tonneau cover ......394 “POWER” switch ....208 Tools ......... 528, 543 Power window switch.... 128 Touch tracer display ....231 Pre-crash braking off Towing switch........322 Emergency towing ....494 Talk switch Trailer towing ......
Page 624 Alphabetical index Warning buzzers Warning messages....510 Brake system ......499 Washer Open door ......503 Checking....... 428 Seat belt reminder....503 Preparing and checking Warning lights before winter....... 333 Anti-lock brake system Switch ....274, 280, 286 (ABS) ........501 Washing and waxing ....
Page 625 Alphabetical index : Refer to ““touch screen” Owner’s manual” or “Navigation System Owner’s Manual”. PRIUS_OM_OM47A19E_(EE)
Page 626: What To Do If
What to do if... What to do if... P. 528, If you have a flat tire A tire punctures If the hybrid system will not start P. 566 Immobilizer system P. 142 The hybrid system does not start If the 12-volt battery is P.
Page 627 What to do if... If a warning light turns on or a A warning light or indicator P. 499 light comes on warning buzzer sounds  Warning lights Master warning light ABS warning light P. 505 P. 501 Brake system warning Electric power steering light (red indicator) system warning light...
Page 628 What to do if... Open door warning light Driver’s seat belt reminder light P. 503 P. 503 Low fuel level warning light P. 503 Front passenger’s seat belt Tire pressure warning P. 503 reminder light light P. 504 : The light flashes to indicate a malfunction. PRIUS_OM_OM47A19E_(EE)
Page 629 What to do if... PRIUS_OM_OM47A19E_(EE)
Page 630 What to do if... PRIUS_OM_OM47A19E_(EE)
Page 631 What to do if... PRIUS_OM_OM47A19E_(EE)
Page 632: Gas Station Information
(Drain and refill  With filter 4.2 (4.4, 3.7) reference) Without filter 3.9 (4.1, 3.4 Toyota Genuine Motor Oil or equivalent Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy- Engine oil type Conserving” or SN “Resource-Conserving”; or...
