- Page 1 OPERATION MANUAL NORDIC SERIE ASH-09AIN PT, ASH-12AIN PT...
- Page 2 SINCLAIR...
-
Page 3: Structure And Operation
Structure and operation Name of each part Indoor Unit Air in Surface panel Display Air out Louver power Zoom in the display plug Remote Set Temp control Heating Cooling Auto Power/Run Drain hose Drying Ｆ Air in Outdoor Unit ｐ ｉ ｐ ｅ ａ ｎ ｄ Connection pipe and connecting... -
Page 4: The Instructions Before Use
The instructions before use... - Page 6 １９５Ｖ...
-
Page 7: Models & Specifications
Models & specifications Model ASH-09AIN PT ASH-12AIN PT Functions Cool/Heat Cool/Heat Accessory Air Cleaner Cooling capacity (W) 2500W (1120W~3000) 3600W (1220~4000) Heating capacity (W) 2750W (1200~3200) 4100 (1310~4300) Power supply (V) 220-240~ Frequency (Hz) Cooling/Heating rated current (A) 6.2/6.3 7.0/7.2... - Page 8 Romote control operation procedure Name and Function-Remote conteol Note: Be sure that there is on obstruction. Don’t drop or throw the remote control. Don’t place the remote control in a location exposed to direct sunlight. Whe the unit is restarted after stopped,it can automatically resume its most latest running mode,and the outdoor unit starts a little bit later.
- Page 9 Name and Function-Remote control(continue) Note: This type of remote control is a kind of new current.Some buttons of the control which have extra function will be described below. ON/OFF Button Liquid crystal displayer Ｐｒｅｓｓ ｔｈｉｓ ｂｕｔｔｏｎ ｏｎｃｅ Ｉｔ ｓｈｏｗｓ ａｌｌ ｓｅｔ ｔｏ ｔｕｒｎ ｏｎ ｔｈｅ ｕｎｉｔ， ｃｏｎｔｅｎｔｓ． ｗｈｅｎ ｒｅｐｒｅｓｓｅｄ ｔｏ ｔｕｒｎ ｏｆｆ ｔｈｅ ｕｎｉｔ． SWING Button Ａｔ ｏｐｅｒａｔｉｎｇ，Ｗｈｅｎ ｉｔ ｉｓ ...
-
Page 10: How To Insert Batteries
How to insert batteries 1.Remove the cover from the back of the remote control. 2.Insert the two batteries(Two AAA dry-cell batteries). 3.Re-attach the cover. NOTE: Don’t confuse the new and worn or different batteries. Remove batteries when not in use for a longtime. The batteries can be used for about one year. - Page 11 Operation Guided Plasma Technology PLASMA TEC Plasma Air Purification Technology PLASMA TEC produces a natural bio-climate rich in active oxygen molecules, known as ions. It creates optimal quantity of positive and negative oxygen ions. Such an ion-enriched environment is notably cleaner and fresher. Plasma Technology has the capacity of breaking down bacteria into harmless particles, air purification, odor neutralization and reduction of particles in the air.
- Page 12 Installtion Installtion location Indoor Unit 9． 10． O utdoor unit...
-
Page 13: Electric Wiring
Electric wiring Earth requirement... -
Page 14: Installation Dimension Diagram
Installation dimension diagram ASH-09AIN ASH-12AIN... - Page 15 Install the indoor unit Install the rear panel Install the piping hole Install the drainage hose Install the connection pipes Electric wiring...
- Page 16 ASH-09AIN ASH-12AIN black the brown one to 3 Brown Black...
-
Page 17: Install The Indoor Unit
Install the indoor unit... -
Page 18: Install The Outdoor Unit
Install the outdoor unit Install the connection pipe Electric wiring connection Black Brown... - Page 19 Air purging and leakage test Electric heating belt...
- Page 20 Test operation and check after installation Test operation Check after installation...
-
Page 21: Care And Maintenance
Care and maintenance Care and maintenance... -
Page 25: Environmental Information
ENVIRONMENTAL INFORMATION This unit contains fluorinated gases with greenhouse effect covered by the Kyoto Protocol. Maintenance and disposal must be carried out by qualified persons only. Refrigerant gas R410A, GWP = 1730 EXTRA REFRIGERANT CHARGE Pursuant to Regulation EC 842/2006 on certain fluorinated greenhouse gases, in case of extra refrigerant charge, it is compulsory to: Fill in the label accompanying the unit inserting the factory quantity of refrigerant charge (see the technical label), the extra refrigerant charge and the total charge.
