Summary of Contents for Sinclair ASH-09AIK
- Page 1 USER'S MANUAL KITE SERIES ASH-09AIK, ASH-13AIK ASH-18AIK, ASH-24AIK...
- Page 2 “Original instructions” ...
- Page 3 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
- Page 4 Table of Contents Owner’s Manual Safety Precautions ..........04 Unit Specifications and Features ..06 SAFETY FIRST Manual Operation (Without Remote) ........11...
- Page 5 Care and Maintenance ..............Troubleshooting ................... 14 European Disposal Guidelines ..........18...
-
Page 6: Safety Precautions
Safety Precautions Read Safety Precautions Before Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classified as either a WARNING or CAUTION. This symbol indicates that ignoring instructions may cause death or serious injury. - Page 7 ELECTRICAL WARNINGS • Only use the specified power cord. If the power cord is damaged, it must be replaced by the manufacturer or certified service agent. • Keep power plug clean. Remove any dust or grime that accumulates on or around the plug. Dirty plugs can cause fire or electric shock.
-
Page 8: Unit Parts
Unit Specifications and Features Unit Parts Air Filter (pull out) Front Panel Power Cable (Some Units) Louver Remote Control Display window Remote Holder (Some Units) “ ” for 3 seconds when: • TIMER ON is set • FRESH, SWING, TURBO, or SILENCE features are turned on “... - Page 9 Achieving Optimal Performance Optimal performance for the COOL, HEAT, and DRY modes can be achieved in the following temperature ranges. When your air conditioner is used outside of these ranges, certain safety protection features will activate and cause the unit to perform less than optimally. Inverter Split Type FOR UNITS WITH COOL mode...
-
Page 10: Other Features
• Wi-Fi Control (some units) For a detailed explanation of each function, Wi-Fi control allows you to control your air refer to the Remote Control Manual. conditioner using your mobile phone and a Wi-Fi connection. Other Features • Louver Angle Memory(some units) •... - Page 11 • Setting Angle of Air Flow Setting vertical angle of air flow While the unit is on, use the SWING /DIRECT button to set the direction (vertical angle) of airflow. 1. Press the SWING /DIRECT button once to activate the louver. Each time you press the button, it will adjust the louver by 6°.
-
Page 12: Sleep Operation
• Sleep Operation The SLEEP function is used to decrease energy use while you sleep (and don’t need the same temperature settings to stay comfortable). This function can only be activated via remote control. Press the SLEEP button when you are ready to go to sleep. - Page 13 Manual Operation (Without Remote) How to operate your unit without CAUTION the remote control The manual button is intended for testing In the event that your remote control fails to purposes and emergency operation only. Please work, your unit can be operated manually with do not use this function unless the remote is the MANUAL CONTROL button located on lost and it is absolutely necessary.
-
Page 14: Care And Maintenance
Care and Maintenance Cleaning Your Indoor Unit BEFORE CLEANING OR MAINTENANCE ALWAYS TURN OFF YOUR AIR CONDITIONER SYSTEM AND DISCONNECT ITS POWER SUPPLY BEFORE CLEANING OR MAINTENANCE. Filter Tab CAUTION Only use a soft, dry cloth to wipe the unit clean. If the unit is especially dirty, you can use a cloth soaked in warm water to wipe it clean. - Page 15 Maintenance – CAUTION Long Periods of Non-Use • Before changing the filter or cleaning, If you plan not to use your air conditioner for an turn off the unit and disconnect its power extended period of time, do the following: supply.
-
Page 16: Troubleshooting
Troubleshooting S AFETY PRECAUTIONS If ANY of the following conditions occurs, turn off your unit immediately! • The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •... - Page 17 Issue Possible Causes A rushing air sound may occur when the louver resets its position. The indoor unit makes noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’ s plastic parts.
- Page 18 Troubleshooting When troubles occur, please check the following points before contacting a repair company. Problem Possible Causes Solution Temperature setting may be higher than ambient Lower the temperature setting room temperature The heat exchanger on the indoor or outdoor unit is Clean the affected heat exchanger dirty Remove the filter and clean it...
- Page 19 Problem Possible Causes Solution Wait for the power to be Power failure restored The power is turned off Turn on the power The fuse is burned out Replace the fuse The unit is not working Remote control batteries are Replace batteries dead The Unit’...
- Page 20 In case of quality problem or other please contact your local supplier or authorized service center. Emergency number: 112 PRODUCER Producer: SINCLAIR CORPORATION Ltd., 1-4 Argyll St., London W1F 7LD, UK, www.sinclair-eu.com This product was manufactured in China (Made in China). REPRESENTATIVE, TECHNICAL SUPPORT NEPA spol.
