STAPLER
N 5008AF
Read through carefully and understand these instructions before use.

Handling instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the N 5008AF and is the answer not in the manual?

Questions and answers

Related Manuals for Hitachi Koki N 5008AF

Summary of Contents for Hitachi Koki N 5008AF

  • Page 1: Handling Instructions

    STAPLER N 5008AF Read through carefully and understand these instructions before use. Handling instructions...

  • Page 2: General Operational Precautions

    GENERAL OPERATIONAL PRECAUTIONS PRECAUTIONS ON USING STAPLER 1. Operate the power tool safely for correct uses. Safe operation through correct usage Do not use the power tool for uses other than those This tool was designed for driving staples into wood specified in this instructions.

  • Page 3: Specifications

    Before using the power tool, check the push lever. 16. Take care when stapling thin boards or the corners Before using the power tool make sure to check that of wood. the push lever and valve operate properly. Without When stapling thin boards, the staples may pass staples loaded into the power tool, connect the hose right through, as may also be the case when stapling and check the following.
  • Page 4 STAPLE SELECTION Choose a suitable staple from Fig. Staples which are not shown in Fig. can not be driven with this tool. 8.3mm 1.4mm (.327") (.055") Dimensions of nails Wear eye protector. STANDARD ACCESSORIES Check the retaining screws which fix the exhaust cover, etc.
  • Page 5 CAUTION Trigger To prevent unintentional operation, never touch the trigger of place the top end of the push lever on a work bench of floor. Also, never face the staple outlet toward any part of a person. Push Lever Fig. 2 Staple Magazine Staple Feeder...

  • Page 6: Inspection And Maintenance

    Flush Too deep Too Shallow Single-Contact Change Lever Contact Driving Position Fig. 7 Fig. 5 NOTES: CAUTION: When adjusting the adjuster, it does not rotate more Exercise care when stapling corners of lumber. When than 3 mm from the deepest point where a staple goes continuous stapling corners of lumber, a staple may down.
  • Page 7 Get rid of the staples, fragments, adhesives, wood 4. Inspecting the magazine chips, etc., jammed in the guide groove using a slotted Clean up the magazine from time to time. head screwdriver or the like. (Fig. 10) Remove the dust, wood chips, etc., accumulated in it. Lubricate the staple feeder’s spring sometimes.
  • Page 8 APPLICABLE LUBRICANTS Type of lubricant Name of lubricant Recommended oil SHELL TONNA Motor oil SAE10W, SAE20W Turbine oil ISO VG32 ~ 68 (#90 ~ #180) Noise Information Noise characteristic values in accordance with Dr prEN 792-13, JUNE, 1997: The typical A-weighted single-event sound power level ,1s,d = 97 dB The typical A-weighted single-event emission sound pressure level at work station...
  • Page 12 2) Year of construction: coded in serial no. Hitachi Power Tools Europe GmbH January 1, 2000 Siemensring 34, 47877 Willich, F. R. Germany Hitachi Koki Co., Ltd. Shinagawa Intercity Tower A, 15-1, Konan 2-chome Y. Hirano Minato-ku, Tokyo, Japan Hitachi Koki Co., Ltd.
