Frequency Agile™ 900MHz
Universal Transmitter
User Manual
For technical support
or application assistance, call
800-782-2709 option #5
Inovonics Corporation
2100 Central Avenue
Boulder CO 80301
LIT-FA210-USER
P ro g ra m m in g p o rt
E xte rn a l co n ta ct te rm in a ls
R e se t b u tto n
External contacts:
Switch trigger:
Typical battery life:
Battery type:
Maximum distance, external switch to FA200:
FA200 Programming
1. When prompted to plug in transmitter, connect cable from programming device to
programming port on transmitter.
2. Press reset button on transmitter.
3. When programming is complete, disconnect cable.
NOTE: The FA200 retains programming data in non-volatile
memory. It does not require re-programming after loss of
power. Install new battery pack and press reset button to re-
initialize the transmitter and restore programming.
FA200
Rev 2.00 25-Aug-00
Tam p e r s w itc h
B a ttery te rm in a ls
4.5V
B a ttery
N/O or N/C, as needed
1.5 sec, minimum
2 to 3 years
4.5V alkaline battery pack (BAT601)
10 feet
FA200
Frequency Agile™ 900MHz
Universal Transmitter
User Manual
For technical support
or application assistance, call
800-782-2709 option #5
Inovonics Corporation
2100 Central Avenue
Boulder CO 80301
LIT-FA210-USER
P ro g ra m m in g p o rt
E xte rn a l co n ta ct te rm in a ls
R e se t b u tto n
External contacts:
Switch trigger:
Typical battery life:
Battery type:
Maximum distance, external switch to FA200:
FA200 Programming
1. When prompted to plug in transmitter, connect cable from programming device to
programming port on transmitter.
2. Press reset button on transmitter.
3. When programming is complete, disconnect cable.
NOTE: The FA200 retains programming data in non-volatile
memory. It does not require re-programming after loss of
power. Install new battery pack and press reset button to
re-initialize the transmitter and restore programming.
Rev 2.00 25-Aug-00
Tam p e r s w itc h
B a ttery te rm in a ls
4.5V
B a ttery
N/O or N/C, as needed
1.5 sec, minimum
2 to 3 years
4.5V alkaline battery pack (BAT601)
10 feet
