Manual
DUE TO THE ISOLATING CHARACTERISTICS OF THESE EARPHONES, DO NOT USE
THEM WHILE DRIVING OR WHILE BIKING, WALKING OR JOGGING WHERE VEHICULAR
TRAFFIC IS PRESENT, OR IN ANY OTHER ACTIVITY WHERE A FAILURE TO HEAR
SAFE USE
Here are some general tips to follow for safe use of this product:
•
Turn up the volume control only far enough to hear properly.
•
Ringing in the ears may indicate that the volume level is too high. Try lowering
the volume.
•
If you are connecting these earphones to an airplane's sound system, listen at
low levels so when loud messages from the pilot break into the program you do not
experience discomfort.
•
Shure recommends that you have your ears checked by an audiologist on a regular
basis. If you experience wax buildup in your ears, stop using the earphones until an
audiologist has examined your ears.
•
Wipe the earphones with an antiseptic before and after use to avoid infections.
Stop using the earphones if they are causing great discomfort or infection.
©2003, Shure Incorporated
27B8809 (Rev. 3)
WARNING!
SURROUNDING SOUNDS COULD BE DANGEROUS.
WARNING!
USING THESE EARPHONES AT EXCESSIVE VOLUMES
CAN CAUSE PERMANENT HEARING DAMAGE.
USE THE LOWEST VOLUME LEVEL POSSIBLE.
ENGLISH
1
Printed in U.S.A
Advertisement
Table of Contents
Related Manuals for Shure E2c
Summary of Contents for Shure E2c
- Page 1 • Shure recommends that you have your ears checked by an audiologist on a regular basis. If you experience wax buildup in your ears, stop using the earphones until an audiologist has examined your ears.
- Page 2 ENGLISH EARPHONE FEATURES The Shure E2c, E3c and E5c earphones are ideally suited for use with CD players, MP3 players, notebook computers and any other listening device that has a 3.5 mm ( -inch) stereo output. Features: Low-mass, high-energy transducer...
-
Page 3: Earphone Components
ENGLISH EARPHONE COMPONENTS The earphone components are illustrated below, using the E2c model as an example. Ear- phone shapes vary, depending on the model. Earphones: When properly inserted in the ear, the Shure logo will appear right-side up on the outside of the earphone with the cable exit pointing upwards. For complete in- structions on inserting earphones, see page 4. -
Page 4: Inserting The Earphones
2. E2c and E3c: wrap the earphone cord over the top and down the back of the ear. E5c: wrap the formfitting wire over the top and down the back of the ear. -
Page 5: Connecting To A Listening Device
The E3c and E5c also come with a cleaning tool (see Figure 1 on page 7) and the E2c comes with wax guards (see the Wax Guard section on page 9) to pre- vent wax buildup in the earphone nozzle. -
Page 6: Changing Sleeves
NOTE: On each foam sleeve there is a rough side and a smooth side. For greater com- fort, Shure recommends that you place the smooth side facing out, away from the ear- phone. With the E2c model earphones, the sleeve will only fit the earphone properly with the smooth side facing out. -
Page 7: Care And Cleaning
NOZZLE FIGURE 1: E3c/E5c Wax Removal • E2c: Routinely check the wax guard on the tips of the nozzles (see figure 2 on page 9). If the wax guards appear to be clogged, replace them. • Foam sleeves should be disposed of and replaced when they get dirty. - Page 8 Wipe down the case and cable with an antiseptic after each use. Stop using the earphones if they are causing great discomfort or infection. CAUTION: Shure earphones are not immersible. Make sure flex and flange sleeves are completely dry before reattaching to earphone nozzles.
- Page 9 ENGLISH WAX GUARD You should place wax guards on the nozzle of your E2c earphones before using them. These protective rings are found on an adhesive strip in the fit kit that comes with your earphones. To place a wax guard on one of your E2c earphones: 1.
-
Page 10: Specifications
E2c Carrying pouch............... 95A2232 E3c Carrying pouch............... 95B2232 E5c Carrying pouch............... 95A2259 E2c Fit Kit w/ wax guards (2 each-small, medium, large foam and clear flex sleeves).. 90WW1371 E3c/E5c Fit Kit w/cleaning tool (2 each-small, medium, large clear flex and soft gray flex sleeves, one pair foam sleeves) ..........90XC1371... -
Page 11: Optional Accessories
Bag of 10 gray flex sleeves (small) ..........PA758S (medium) ........... PA758M (large) ..........PA758L Triple-Flange sleeves (2) ..............PA755 E2c Earphones: Bag of 10 foam sleeves (small)............PA752S (medium) ..........PA752M (large) ............PA752L Bag of 10 flex sleeves (small)............PA757S (medium) ............ - Page 12 ENGLISH CUSTOM EAR MOLDS A Hearing Health Care Professional can make custom-fit ear molds for the E3c from im- pressions of your ears. Custom-made ear molds can provide better comfort and ambient noise isolation for some users. The E3c fits in a custom ear mold as shown in the following illustration.
