Summary of Contents for Shure E2c
- Page 1 Earphone User Guide ©2002, Shure Incorporated 27A8809 (BI) Printed in U.S.A.
- Page 2 Shure recommends that you have your ears checked by an audiologist on a regular basis. If you experience wax buildup in your ears, stop using the earphones until an audiologist has examined your ears.
- Page 3 ENGLISH EARPHONE FEATURES The Shure E1c, E2c and E5c earphones are ideally suited for use with CD players, MP3 players, and any other listening device that has a 3.5 mm ( -inch ) stereo output. Features: E1c/E5c Low-mass, high-energy transducer Full–range dynamic transducer...
-
Page 4: Earphone Components
Earphones. For models E1c and E5c, the earphone with the BLUE marking fits in the left ear, while the earphone with the RED marking fits in the right ear. For model E2c, the bi-colored earphone fits in the right ear, while the earphone that is all one color fits in the left ear. -
Page 5: Inserting The Earphones
2. E1c and E2c: wrap the earphone cord over the top and down the back of the ear. E5c: wrap the form-fitted wire over the top and down the back of the ear. -
Page 6: Connecting To A Listening Device
Once tightly sealed, the sleeves hold the earphones firmly in place. The E1c and E5C come with yellow foam sleeves. The E2c earphones come with three sizes of orange foam sleeves to choose from —small, medium or large —for the best fit. -
Page 7: Care And Cleaning
E1c/E5c: clean the nozzles after each use using the supplied wax removal tool (see figure 1 on the following page). E2c: Routinely check the wax guard on the tips of the nozzles (see figure 2 on page 8). If the wax guards appear to be clogged, replace them. - Page 8 Evanston IL 60202-3696, U.S.A. WAX GUARD You should place wax guards on the nozzle of your E2c earphones before using them. To place a Wax Guard on one of your E2c earphones: 1. Remove the sleeve from the earphone nozzle.
-
Page 9: Specifications
5. Place the sleeve on the earphone. FOAM SLEEVE WAX GUARD NOZZLE FIGURE 2: E2c Wax Guard Installation IMPORTANT: Do not place Wax Guards on sleeves! Wax guards are intended for use on the tip of the earphone only, otherwise they will not function properly. - Page 10 ........95A2232 E2c Foam/Flex sleeve assortment w/ wax guards (2 each—small, medium, large) .
- Page 11 ENGLISH CUSTOM EAR MOLDS A Hearing Health Care Professional can make custom-fit ear molds for the E1c from im- pressions of your ears. Custom-made ear molds can provide better comfort and ambient noise isolation for some users. The E1c fits in a custom ear mold as shown in the following illustration.
- Page 12 SHURE Incorporated Web Address: http://www.shure.com 5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A. Phone: 800-257-4873 Fax: 847-866-2279 In Europe, Phone: 49-7131-72140 Fax: 49-7131-721414 In Asia, Phone: 852-2893-4290 Fax: 852-2893-4055 Elsewhere, Phone: 847-866-2200 Fax: 847-866-2585...
