- Page 1 E Series Earphone User Guide ©2006, Shure Incorporated 27D8791 (Rev. 9) Printed in U.S.A.
- Page 2 2. Ringing in the ears may indicate that the gain levels are too high. Try lowering the gain levels. 3. Shure recommends that you have your ears checked by an audiologist on a regular basis. If you experience wax buildup in your ears, stop using the earphones until an audiologist has examined your ears.
- Page 3 EARPHONE FEATURES The Shure E Series earphones are designed for use with Shure Personal Monitor Systems. They are also ideally suited for use with CD players, MP3 players, notebook computers and any other listening device that has a 3.5 mm (...
-
Page 4: Earphone Components
EARPHONE COMPONENTS The earphone components are illustrated below, using the E2 model as an example. Ear- phone shapes vary, depending on the model. Earphones: When properly inserted in the ear, the Shure logo will appear right-side up on the outside of the earphone with the cable exit pointing upwards. For complete in- structions on inserting earphones, see page 4. -
Page 5: Inserting The Earphones
2. E2 and E3: wrap the earphone cord over the top and down the back of the ear. E5: wrap the formfitting wire over the top and down the back of the ear. - Page 6 The E3 and E5 also come with a cleaning tool (see Figure 1 on page 7) and the E2 comes with wax guards (see the Wax Guard section on page 9) to prevent wax buildup in the earphone nozzle.
-
Page 7: Changing Sleeves
NOTE: On each foam sleeve there is a rough side and a smooth side. For greater com- fort, Shure recommends that you place the smooth side facing out, away from the ear- phone. On the E2 model earphones, the sleeve will only fit the earphone properly with the smooth side facing out. -
Page 8: Care And Cleaning
E3/E5: clean the nozzles after each use using the supplied wax removal tool. • E2: Routinely check the wax guard on the tips of the nozzles (see figure 2 on page 9). If the wax guards appear to be clogged, replace them. - Page 9 Wipe down the case and cable with an antiseptic after each use. Stop using the earphones if they are causing great discomfort or infection. CAUTION: Shure earphones are not immersible. Make sure flex and flange sleeves are completely dry before replacing on earphone nozzles.
- Page 10 WAX GUARD You should place wax guards on the nozzle of your E2 earphones before using them. These protective rings are found on an adhesive strip in the fit kit that comes with your earphones. To place a wax guard on one of your E2 earphones: 1.
-
Page 11: Specifications
Eligible to bear CE marking. Conforms to European EMC Directive 89/336/EEC. Meets ap- plicable tests and performance criteria in European Standard EN 55103 (1996) Parts 1 and 2, for residential (E1) and light industrial (E2) environments. FURNISHED ACCESSORIES E2 Carrying pouch ...95A2232 E3 Carrying pouch ...95B2232... -
Page 12: Optional Accessories
Bag of 500 foam sleeves...PA754 Bag of 10 clear flex sleeves (small)... PA756S Bag of 10 gray flex sleeves (small)... PA758S Triple-Flange sleeves (2) ...PA755 E2 Earphones: Bag of 10 foam sleeves (small) ... PA752S Bag of 10 flex sleeves (small)... PA757S (medium) ...PA757M (large) ...PA757L... - Page 13 CUSTOM EAR MOLDS A Hearing Health Care Professional can make custom-fit ear molds for the E3 from im- pressions of your ears. Custom-made ear molds can provide better comfort and ambient noise isolation for some users. The E3 fits in a custom ear mold as shown in the following illustration.
- Page 14 United States, Canada, Latin America, Caribbean: 5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A. Phone: 847-600-2000 U.S. Fax: 847-600-1212 Int’l Fax: 847-600-6446 Europe, Middle East, Africa: Shure Europe GmbH, Phone: 49-7131-72140 Fax: 49-7131-721414 Asia, Pacific: Shure Asia Limited, Phone: 852-2893-4290 Fax: 852-2893-4055...
