DTR-2000/1000
CONTENTS
1) Structural Diagram: Page 2 -3
2) Circuit Diagram: Page 4-7
4) Test Mode: Page 8
5) Parts List: Page 9-12
1st Edition
Issued date: September 2nd, 2002
Issued by: KORG INC.

Advertising

   Also See for Korg DTR-1000

   Related Manuals for Korg DTR-1000

   Summary of Contents for Korg DTR-1000

  • Page 1

    DTR-2000/1000 CONTENTS 1) Structural Diagram: Page 2 -3 2) Circuit Diagram: Page 4-7 4) Test Mode: Page 8 5) Parts List: Page 9-12 1st Edition Issued date: September 2nd, 2002 Issued by: KORG INC.

  • Page 4

    H_MAIN.sch-1 - Mon Aug 19 13:26:25 2002...

  • Page 5

    161jack.sch-1 - Mon Aug 19 13:36:01 2002...

  • Page 6

    L_MAIN.sch-1 - Mon Aug 19 13:28:25 2002...

  • Page 7

    161_ljack.sch-1 - Mon Aug 19 13:34:13 2002...

  • Page 8

    161jack.sch-2 - Mon Aug 19 13:31:34 2002...

  • Page 9

    DTR-1000 How to start the test mode [DISPLAY] + [CALIB] & [POWER ON] NOTE: Do NOT insert any plug into the MUTE terminal while starting the test mode. DTR-2000 How to start the test mode [CHROMATIC] + [DISPLAY/SOUND] & [POWER ON]...

  • Page 10

    PART CODE PART NAME NOTE Q’TY 001235600 PCB ASSY KLM-2356/57 DTR-2000 M.PART 001235800 PCB ASSY KLM-2358 DTR-2000 M.PART 304050140 DIGITAL TR DTC114EKA T146(TS) KLM-2356/57 DT 304050140 DIGITAL TR DTC114EKA T146(TS) KLM-2358 DTR-2 304050150 DIGITAL TR DTA114EKA T146 (TS) KLM-2358 DTR-2 304060070 FET 2SK433-T12-1C (TS)

  • Page 11

    DTR-2000 PART CODE PART NAME NOTE Q’TY *464X161H00 FUSE T125MA/250V M.PART 100JP *464X161H01 FUSE T63MA/250V M.PART 230GE *464X161H01 FUSE T63MA/250V M.PART 230UK *464X161H01 FUSE T63MA/250V M.PART 240AU *471X161H00 CONECTOR TOP B4P7-VH KLM-2356/57 DT *475X161H00 HARNESS HNS-2067 M.PART *475X161H01 HARNESS HNS-2068 M.PART *475X161H02 HARNESS HNS-3174...

  • Page 12

    PART CODE PART NAME NOTE Q’TY 001235601 PCB ASSY KLM-2356/57 DTR-1000 M.PART 001235900 PCB ASSY KLM-2359 DTR-1000 M.PART 304050140 DIGITAL TR DTC114EKA T146(TS) KLM-2356/57 DT 304050140 DIGITAL TR DTC114EKA T146(TS) KLM-2359 DTR-1 304050150 DIGITAL TR DTA114EKA T146 (TS) KLM-2359 DTR-1...

  • Page 13

    DTR-1000 PART CODE PART NAME NOTE Q’TY *475X161H00 HARNESS HNS-2067 M.PART *475X161H05 HARNESS HNS-3156 M.PART 100JP *475X161H06 HARNESS HNS-3157 M.PART 117CN *475X161H06 HARNESS HNS-3157 M.PART 117US *475X161H07 HARNESS HNS-3158 M.PART 230GE *475X161H07 HARNESS HNS-3158 M.PART 230UK *475X161H07 HARNESS HNS-3158 M.PART 240AU...
