VTEL Vista Quick Reference Install Manual

Table of Contents

Download this manual

Table of Contents

Need help?

Do you have a question about the Vista and is the answer not in the manual?

Page 2 Unpacking Your New Page 1...
Page 3 VGA monitor, or the s-video monitor. See examples at the left. ™ To install the mounting blocks, carefully position the Vista on its back, remove the appropriate pair of mounting blocks from the plastic bag and mount to the Velcro™ patches as shown below.
Page 4 Page 3...
Page 5 Selecting a Location The room you choose for setup should be free of general work areas and large enough for free movement. Doorways, columns, or other distracting elements should not be within the setup space. Environmental Concerns When choosing the system’s location, avoid general work areas with noise and high traffic; and your room size should be large enough to accommodate the appropriate viewing distance for the monitor size.
Page 6 Connect one end of the microphone cable to the microphone and the other end into the Microphone-1 port on the back of the unit. ™ Connect the 3.5mm stereo end of the audio cable into the Audio port on the back of the Vista and the RCA (phono) ends to the Audio In connectors at the back of the monitor.
Page 7 Launching the Online User Guide ™ An icon is placed on your desktop for easy access to the online User Guide. This Guide introduces the user to videoconferencing basics and instructs how to use the Vista ™ ™...
Page 8 If trouble is experienced with this equipment, please contact the VTEL Products Corporation Customer Satisfaction Center at 800-438-8835 (or) 512-821-7101 for repair and (or) warranty information.
