Summary of Contents for Proline PLF220A
- Page 1 Larder Fridge PLF220A INSTRUCTIONS...
- Page 2 This booklet contains the information you will require to install and operate your new appliance. It is important and worthwhile spending time to fully read this booklet so you will understand how to operate the appliance safely and efficiently. Please keep this booklet in a safe place so that you can refer to it when required. Safety information This information is provided in the interest of your safety.
-
Page 3: Electrical Connection
Thank you for buying this PROLINE larder fridge. To ensure that you get the best results from your new fridge, please take time to read through these simple instructions in this booklet. Please ensure that the packaging material is disposed of in accordance with the current environmental requirements. -
Page 4: Name Of Parts
Name of parts PARTS AND FEATURES PARTS AND FEATURES Worktop Worktop Cabinet Cabinet Shelves Shelves Crisper Cover Crisper Cover Crisper Box Crisper Box Adjustable Foot Adjustable Foot Control Unit Door Switch Door Switch Door Assembly Door Assembly Door Handle Door Handle Door Balcony Door Balcony Door Gasket... -
Page 5: Installation
INSTALLATION Siting of the appliance Do not keep your appliance in a room where the temperature is likely to fall below 16ºC (61 degrees F) at night and/or especially in winter, as it is designed to operate in ambient temperatures between +16ºC and +32ºC (61 and 90 degrees F). At lower temperatures the appliance may not operate, resulting in a reduction in the storage life of the food. -
Page 6: Use Of The Appliance
Some fruit and vegetables suffer damage if kept at temperatures near Freezing. Therefore wrap pineapples, melons, cucumbers, tomatoes and similar produce in polythene bags. Leftover canned food should not be stored in the fridge, transfer it to an airtight container. Alcohol must be stored upright in tightly closed containers. -
Page 7: Do's And Don'ts
Shut the door! To prevent cold air escaping, limit the number of times you open the door. When returning from shopping, sort foods to be kept in your larder fridge while the door is closed. Where to store your foods in the larder fridge. Coldest area: 1°C to 5°C This is where to store foods which will keep longer if they are kept cool. - Page 8 Do- Leave lettuce, cabbage, parsley and cauliflower on the stem. Do- Wrap cheese firstly in greaseproof paper and then in a polythene bag, excluding As much air as possible. For best results, take out of the fridge compartment an hour before eating.
- Page 9 appliance works, check the fuse in the larder fridge plug. Condensation appears on the outside of the larder fridge This may be due to a change in the room temperature. Wipe off any residue of moisture. Noises You may hear some unusual noises from time to time this is quite normal. Do not attempt to repair your larder fridge yourself contact the store from were you purchased this appliance.
-
Page 10: Reversing The Door
Reversing the door Warning! When changing the way the door opens, the appliance must not be connected to the mains. Remove the plug from the mains before working on the door. Remove the two screws (6) and remove the worktop by raising the rear and pushing it forwards. Remove the two screws (1) and remove the upper hinge (5) from the right side of the fridge. -
Page 11: Technical Data
Technical data Proline Brand Appliance type Upright Larder Fridge 280L Total gross volume (l.) 215L Total usable volume (l.) Energy class (1) Power consumption (kWh/year) (2) 161 220-240V~/50Hz Supply voltage (V/Hz) <39 Noise [dB(A)re 1 pW] R600a Refrigerating agent 500x580x1430mm... - Page 12 After Sales Service If you experience a problem with your appliance and you require advice please contact the technical help line on 0113 2793520 If you require a service engineer Call Service the number on your receipt. If something doesn't seem to work If there is something about your appliance which you do not understand and you live in the UK you can phone our help line during normal office hours on: 0113 2793520 If you need a service engineer please phone the number on your sales receipt.
