- Page 1 READ AND SAVE THIS INSTRUCTIONS FOR DOMESTIC COOKING ONLY Installer: Leave this manual with the homeowner. Homeowner: Cleaning, Maintenance and Operating instructions on the coming pages. RANGE HOOD ITEM NO.: K1009R/K1009C/K1009RA/K1009CA REFERED MODEL NO.: 3388F MOTOR WITH UL CERTIFICATE...
-
Page 2: Table Of Contents
CONTENTS YOUR RANGE HOOD’S SPECIFICATIONS .….……………..………….2 IMPORTANT SAFETY INFORMATION……………………………… .…3-4 USING YOUR RANGE HOOD………………………………..……………..5 MAINTAINING AND CLEANING YOUR RANGE HOOD ……….6-8 Installing/Changing the Carbon Filter….………………………………………9-10 INSTALLATION INSTRUCTIONS ……………………….……...….11-19 ELECTRICAL CONNECTION……………11 INSTALLING THE RANGE HOOD………12 ATTACHING THE HOOD……………………………13-14 FITTING THE CHIMNEY…………………15-16 ATTACHING THE GLASS…..17 INSTALLATION NOTES –... -
Page 3: Your Range Hood's Specifications
Specifications of your Range Hood Congratulations on purchasing a Range Hood! To fully enjoy using your appliance long into the future, please firstly familiarise yourself with its specifications, safety advice and operational instructions included in this manual. You will also need this manual to ensure that your Range Hood has been installed properly. -
Page 4: Important Safety Information
Important Safety Information: Please Read this before installing & using. Any installation work must be DO NOT CLEAN IN carried out by a qualified electrician or BEHIND THE GREASE competent person. FILTERS! o If the room where the The hood must be installed in cooker hood is to be used accordance with the installation contains a fuel burning... - Page 5 Please dispose of the the hood, including Important Safety Information: Please Read this before installing & using. packing material replacing light bulbs. carefully – children are especially vulnerable to it. Do not connect the Dirty oil is an even ducting system of this greater fire risk.
-
Page 6: Using Your Range Hood
Using your Range Hood: To use your Range hood: Make sure it has been properly installed. Find the CONTROL PANEL. It is located at the front of the canopy, to the right. The CONTROL PANEL contains buttons as shown in the Figure below. -
Page 7: Maintaining And Cleaning Your Range Hood
Cleaning your Range Hood: Before cleaning, always ensure that you have IMPORTANT: switched your range hood OFF at the omni-polar switch, set at the wall from the cable: Cleaning Clean the external parts with Be sure to replace the mild liquid detergents on a carbon filters at the damp cloth. - Page 8 Maintenance - Cleaning the Anti-grease Filters Please Read this before installing & using. First remove the grille by pulling down on it. Undo the side catches. You can now clean the anti-grease filter grilles. Soak them for about one hour in hot water with a grease-loosening detergent then rinse off thoroughly with hot water.
- Page 9 Maintenance – Changing the Light Bulb and Carbon Filter Changing the light bulb Before changing the light bulb, ensure that the appliance is not live (i.e., ensure that you have switched it off at the wall switch). Remove the metal anti-grease filters (see Figure 2 below) and find the old bulb located in the light fixture up inside the exposed canopy.
-
Page 10: Installing/Changing The Carbon Filter
Installing / Changing the Carbon Filter Installing / Changing the Carbon Filter. For model K1009R/K1009RA The Cooker Hood uses a pair of CARBON FILTERS to purify the air for the air recirculation function. You will find the round carbon filters are packed in a plastic bag besides the cooker hood. - Page 11 For model K1009C/K1009CA The Cooker Hood uses a piece of CARBON FILTERS ( Pls see FIG 3) to purify the air for the air recirculation function. You will find the square carbon filters are packed in a paper box besides the cooker hood. And the filters will attach to both sides of the fan motor (please see FIG 4).
-
Page 12: Electrical Connection
INSTALLATION INSTRUCTIONS – Electrical Connection. Before installation and usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the identification plate (found inside your Range Hood) and all the data inside the appliance are exactly the same as the voltage and frequency in your home. -
Page 13: Installation Instructions
INSTALLATION INSTRUCTIONS – Installing your Range Hood The range hood must not be fitted above stoves with a PLEASE NOTE THAT YOU WILL HAVE radiant top plate. TO DECIDE BEFORE INSTALLING YOUR RANGE HOOD THAT YOU CAN ADAPT IT AS AN EXTRACTION FAN. PLEASE We recommend that at least SEE PAGE 18 NOW TO UNDERSTAND two people install this hood. -
Page 14: Attaching The Hood
INSTALLATION INSTRUCTIONS – Attaching the Hood Rear view of your range hood. -------------------------------------------------------------------------- 3) Using a drill bit with a 8 mm diameter, make holes in the wall where you have marked these positions (see below). -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 4) Insert the expansion fixings (rawlplugs) in the holes and then screw the support screws halfway in (see below figure, at right). -
Page 15: Attaching The Hood
INSTALLATION INSTRUCTIONS – Attaching the Hood ------------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------- 6) (EXTRACTION FUNCTION ONLY) Connect the coupling to the top of the cooker hood (see below). Then connect the discharge pipe to the coupling as shown below. Remember that your ducting will have to match the specifications shown in the notes on Extraction / Air Purifier (Recirculation) Modes on p.18. -
Page 16: Fitting The Chimney
INSTALLATION INSTRUCTIONS – Fitting the Chimney FITTING THE PIPE – Once your Cooker Hood has been installed, you can now fit the pipe. 1) Take the two casings ‘A’ and ‘B’: 2) Rest the bottom of the casing ‘A’ on the top of the hood, taking care to position the tabs of the casing correctly on the back of the hood as shown as part ‘X’... - Page 17 INSTALLATION INSTRUCTIONS – Fitting the Chimney 6) Take the fixing bracket ‘G’ (Fig. 4 – previous page), centre it with respect to the mark you previously made, keeping it in contact with the ceiling, and then mark the anchoring holes (‘H’).
-
Page 18: Attaching The Glass
ATTACHING THE GLASS Remove the metal grease filters from the hood Slacken both anchoring screws “F” Place the glass ‘Q’ on the upper shelf of the hood, pushing it in towards the wall. Tightening the screws ‘F’ again in the hole and connecting them to the unit. -
Page 19: Installation Notes - Extraction / Purifying Version
Extraction / Air Purifier Modes of Operation EXTRACTION OPERATION – Installation Instructions Ensure that you have fitted the union (‘N’) to the upper part of the hood using the packaged two screws supplied inside the packing (Fig. 1 – on right). Using a 125 mm diameter pipe, connect the union (N) on the upper part of the hood (see Fig. -
Page 20: Note On Installing The Version With Lower Bracket
If your Range Hood comes with a Lower Bracket * Note on what to do if your Range Hood is the version that comes with a BRACKET. Please note that your range hood may include a lower bracket. If this is the case, you will need to have it installed as such. -
Page 21: Troubleshooting
Troubleshooting If something has gone wrong with your Range Hood, checking against this chart might keep you from having to call for service. Symptom Solution • Check that the hood is connected to the electricity supply. The range hood will not start! •... -
Page 22: Warranty
WARRANTY We will warrant this product free from defects in material and quality for one year and motor for 5 years. If any problems occur from correct usage, please contact the service department for under warranty service. This warranty does not cover the following: The filter mesh and bulb. - Page 23 K-Star International Group Inc. K-Star Electronic Appliance Inc. Toll Free:(800) 893-2168 Email:info@kstarus.com http://www.kstarus.com...
