SERVICE MANUAL
COLOR TELEVISION
Sistemas de recepção de cores:
Recepção de canais (181 canais)
Cinescópio (tubo de imagens):
Alimentação elétrica (FREE VOLTAGE)110 a 240V AC - 50/60Hz
Consumo de energia
Potência acústica:
Peso
Dimensões (LxAxP):
• Design and specifications are subject to change without notice.
TV-AR205
SPECIFICATION
PAL-M/PAL-N/NTSC com seleção automática ou manual
VHF = canais de 2 a 13
UHF = canais de 14 a 69
CATV = canais de 1a 125
20 polegadas
Diagonal visual: 48 cm (19 polegadas)
85 W
2,5 W por canal
18,5 kg
610 x 440 x 483 mm
S/M Code No. 09-009-349-1N1
RHCAM
