Table 2 EWS pages
EWS Page
Printer Status
Security Setup
Network Setup
Diagnostics
36
Using the Printer
Description
Access to printer information, ink levels, and usage metrics.
Also shows the current printer settings.
(See
Change Password Set the passwords for accessing the following:
• Embedded Web Server (EWS).
• Level 1 (Supervisor) security on control panel.
• Level 2 (Administrator) security on control panel.
The control panel password must contain 3 digits.
Printer Settings Set the minimum security level allowed to access the
following protected settings:
• Language
• LCD Brightness/Contrast
• Sensor Sensitivity
Network settings for the printer.
Perform diagnostics & print a PQ test plot
Print test pages Load 4" x 4" or larger labels (with inter-label gap or
continuous).
• Specify whether the media loaded in the printer is
• Click a test page to print it.
Sensor Threshold • Trigger the printer to run a length (about 1m or 40") of
Values
• Save and import this file into MS Excel or any
• The user needs to open the clamshell and remove the
EWS Security Setup on page 39.)
3 to 12 alphanumeric characters. No special characters.
Continuous, Black mark or with Inter-Label Gap and click
Submit.
This setting applies when printing all test pages and
other printer internal pages.
labels while it records the reading of the gap/mark
sensor. At the end of the run, a comma delimited text
(.csv) file is generated. (See
Sensor Readings on page 42)
spreadsheet to chart the readings. This is useful for
evaluating if there is sufficient contrast (between the
gap/mark and label) for the printer to detect the
inter-gap/black mark reliably and help with adjusting the
sensor threshold to improve the detection.
labels from the printer after each test run. (See
a Media Jam on page 70)
Interpreting the Gap/Mark
Clearing
