Using the Control Panel

The icons above the printer buttons indicate their functions
• When the printer is online, press
options are described in
• Press and to scroll through the menus.
• Press (Select) to select an option or setting.
• Press (Return) to return to the previous menu.
Printer Online
Table 2 Printer Buttons
Function
Config
Up, Down
Select
Return
Unload Media
Pause, Resume
Cancel
(Config) to access the configuration menus. The
Config Options on the Control Panel
CONFIGURATION
1. Setup
Description
Access the Configuration menus.
Move through the menu options.
Select a menu option or confirm a setting.
Return to previous menu.
Unload the labels.
Pause or resume printing.
If printing roll to roll, the printer pauses for 10 seconds,
then prints the next page and pauses again. It will
continue to print and pause.
Cancel printing.
ColorMaxLP Label Printer
(Table 2).
on page 78.
Setting Up the Printer
