Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS USER GUIDE Freestanding Wine Cabinets RF106RDWX1, RF206RDWX1, RF306RDWX1 and RF356RDWX1 models NZ AU GB IE EU AE IN... -
Page 3: Table Of Contents
CONTENTS Introduction Safety and warnings Installation instructions Moving or storing your appliance Operating instructions – External control panel Operating instructions – Special functions Interior and exterior features Storing your wine Loading your wine bottles Cleaning care – Exterior Cleaning care – Interior User warnings and sounds Troubleshooting Manufacturer’s Warranty... -
Page 5: Introduction
Other golden rules of excellent wine storage that your Wine Cabinet offers is frequent air circulation, as well as increased air circulation when large amounts of wine bottles are added (Air-Cool function). Condensation eliminator (Demist function*) and minimal vibrations with the low noise compressor. RF106RDWX1 model RF206RDWX1 model RF306RDWX1 model RF356RDWX1 model... -
Page 6: Safety And Warnings
SAfETy AND wARNINGS wARNING! Electric Shock Hazard Read and follow the safety and warnings outlined in this user guide before operating this appliance. failure to do so can result in death, electric shock, fire or injury to persons. This wine Cabinet contains flammable refrigerant isobutane (R600a). - Page 7 SAfETy AND wARNINGS • Cleaning and user maintenance shall not be made by children without supervision. • Keep ventilation openings in the appliance enclosure clear of obstruction. • In case of damage to the refrigerant circuit, ventilate the area by opening all windows. Do not operate electrical equipment or any other equipment that may produce arcs, sparks or flames in the area.
- Page 8 SAfETy AND wARNINGS • If the power supply cord is damaged, it must only be replaced by your fisher & Paykel Authorised Repairer. • when moving your appliance, be careful not to roll over or damage the power cord. • Do not use electrical appliances inside the wine Cabinet.
- Page 9 SAfETy AND wARNINGS • your fisher & Paykel Authorised Repairer will be able to give advice on environmentally friendly methods of disposing your old wine Cabinet. • It is hazardous for anyone other than an authorised repairer to service this appliance. In Queensland, Australia the authorised service person must hold a gas work licence or authorisation for hydrocarbon refrigerants to carry out service or repairs which...
-
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS Please follow the installation steps below to ensure your appliance operates correctly. Power The appliance must be installed so the plug is accessible. ● ● To ensure that the appliance is not accidentally switched off, connect your Wine Cabinet ●... - Page 11 INSTALLATION INSTRUCTIONS Product installation Your Wine Cabinet is fitted with rear rollers designed for moving the product in the ● ● forwards and backwards direction. Avoid moving the product in a sideways direction as this may damage the floor ● ●...
- Page 12 INSTALLATION INSTRUCTIONS Product and cabinetry dimensions Flush with Wine Cabinet chassis Flush with Wine Cabinet door – full door rotation – full door rotation Flush with Wine Cabinet door – 90° door rotation Power plug to power wall socket...
- Page 13 INSTALLATION INSTRUCTIONS PRODUCT DIMENSIONS Overall height of product 1270 1660 1855 Overall width of product Overall depth of product (excludes handle, includes back cover) CABINETRy DIMENSIONS (Including minimum air clearances) Inside height of cavity 1320 1710 1905 flush with wine Cabinet chassis – full door rotation Inside width Inside depth flush with wine Cabinet door –...
- Page 14 INSTALLATION INSTRUCTIONS what to do if your wine Cabinet is unstable Gently push the Wine Cabinet back until the rear contacts the floor. Measure the gap under the front foot, which ● ● has come off the floor. Obtain some solid packing material ●...
-
Page 15: Moving Or Storing Your Appliance
MOVING OR STORING yOUR APPLIANCE If your Wine Cabinet is turned off for any reason, wait 10 minutes before turning it back on. This will allow the refrigeration systems pressures to equalise before restarting. Moving your appliance Turn off the appliance and unplug from the power point. Remove all wine bottles. ●... -
Page 16: Operating Instructions - External Control Panel
If you wish to alter the temperature of either zone, this can be easily done by using the ● ● external control panel. External control panel RF106RDWX1 and RF206RDWX1 models RF306RDWX1 and RF356RDWX1 models Adjusting the temperature of each zone The zone last selected will automatically be illuminated. Press and hold the ‘Keylock’... -
Page 17: Operating Instructions - Special Functions
OPERATING INSTRUCTIONS – SPECIAL fUNCTIONS Special functions Keylock The external control panel automatically locks from any key presses after 30 seconds from being enabled. To deactivate Keylock and allow key presses. Press the ‘Keylock’ button for 3 seconds, when unlocked the back lit LED lights intensify. To activate Keylock press the ‘Keylock’... -
Page 18: Interior And Exterior Features
Door Switch Upper zone Standard shelf Fixed shelf Bottom zone Single Tier shelf UV-tempered glass door Fixed shelf Safety lock RF106RDWX1 model Door Switch Upper zone Presentation shelf Upper zone carbon filter Fixed shelf UV-tempered glass door Bottom zone Double Tier shelf... - Page 19 Push the shelf back into the Wine Cabinet until you feel it secure into the support lugs. Double Tier shelf (excludes RF106RDWX1 model) These shelves are located in the bottom zone only and is designed to hold up to 11 Bordeaux bottles. The ideal loading arrangement for these shelves is to have bottle necks facing the back of the Wine Cabinet.
- Page 20 INTERIOR AND EXTERIOR fEATURES Activated carbon filters (all models) Air quality is critical for preserving wine, the activated carbon filters helps to remove stale, unwanted odours and replenishes with fresh air. The filters are fitted to the rear wall on ●...
-
Page 21: Storing Your Wine
STORING yOUR wINE Short-term storage/serving This Wine Cabinet is perfect for short-term storage such as entertaining. ● ● Red wines are best served at warmer temperatures and white wines are best served at ● ● cooler temperatures. The ideal serving temperature of your wine is crucial for your taste and enjoyment. ●... -
Page 22: Loading Your Wine Bottles
The loading arrangement outlined for the following models is recommended when using the Presentation shelf. Maximum capacities are listed, and storage can be maximised by removing the Presentation shelf and replacing with the additional Standard shelf supplied (except RF106RDWX1). DON’Ts Before loading wine into the cabinet Do not load more than the ●... - Page 23 LOADING yOUR wINE BOTTLES Presentation shelf 9 wine bottles in the upright position only Upper zone Standard shelf 22 wine bottles only fixed shelf 8 wine bottles only Double Tier shelf 11 wine bottles only Standard shelf 8 wine bottles only Bottom zone Single Tier shelf...
- Page 24 LOADING yOUR wINE BOTTLES Presentation shelf 9 wine bottles in the upright position only Upper zone Standard shelf 22 wine bottles only fixed shelf 8 wine bottles only Double Tier shelf 11 wine bottles only Standard shelf 22 wine bottles only Bottom zone Standard shelf...
- Page 25 LOADING yOUR wINE BOTTLES Presentation shelf 9 wine bottles in the upright position only Upper zone Standard shelf 22 wine bottles only fixed shelf 8 wine bottles only Double Tier shelf 6 wine bottles only Bottom Standard shelf zone 22 wine bottles only Single Tier shelf 6 wine bottles only fixed shelf...
-
Page 26: Cleaning Care - Exterior
CLEANING CARE – EXTERIOR Stainless steel exterior door Use only liquid dishwashing detergent dissolved in warm water and a soft lint-free cloth ● ● to clean the exterior door surface. Rinse with clean water and dry with a clean, lint-free cloth. ●... -
Page 27: Cleaning Care - Interior
CLEANING CARE – INTERIOR Interior For ease of cleaning, empty the Wine Cabinet first and remove all shelves. ● ● Wipe interior surfaces using only liquid dishwashing detergent dissolved in warm water ● ● and a soft lint-free cloth. Rinse with clean water and dry with a clean, lint-free cloth. Do not use harsh chemicals, abrasives, ammonia, chlorine, bleach, concentrated ●... -
Page 28: User Warnings And Sounds
USER wARNINGS AND SOUNDS User warnings – faults In the unlikely event of a fault occurring, a fault code will be displayed on the external control panel and an alarm will sound. Please take note of the fault code and contact our Customer Care Centre. Contact ●... -
Page 29: Troubleshooting
TROUBLESHOOTING If there is a problem with your Wine Cabinet, please check the following points before contacting your local Fisher & Paykel Authorised Repairer or Customer Care Centre. Product parts and accessories can be purchased through Fisher & Paykel Customer Care or online at www.fisherpaykel.com (this service is available to selected markets only). - Page 30 TROUBLESHOOTING PROBLEM POSSIBLE CAUSES wHAT TO DO Unfamiliar noises. The cabinet is not stable Level the cabinet. Refer to the or level. ‘Installation instructions’ section or refer to ‘User warnings and sounds’ section. Door alarm sounds This is dependent on the Please take note of the fault code and continuously displayed fault code.
-
Page 31: Manufacturer's Warranty
MANUfACTURER’S wARRANTy You automatically receive a 2 year Manufacturer’s Warranty with the purchase of this Wine Cabinet covering parts and labour for servicing within the countries New Zealand, Australia, The Republic of Ireland and Northern Ireland. All other countries are excluded. fisher &... - Page 32 MANUfACTURER’S wARRANTy Service under this Manufacturer’s Warranty must be provided by a Fisher & Paykel Authorised Repairer (refer to the ‘Customer Care’ section at the back of this book). Such service shall be provided during normal business hours. This Manufacturer’s Warranty certificate should be shown when making any claim. for Australian customers This Manufacturer’s Warranty is an extra benefit and does not affect your legal rights.
-
Page 33: Customer Care
CUSTOMER CARE Before you call for service or assistance... Check the things you can do yourself. Refer to your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. You have read the ‘Troubleshooting’ section at the back of the book. If after checking these points you still need assistance or parts, please refer to your nearest Authorised Service Centre, Customer Care, or contact us through our website www.fisherpaykel.com. -
Page 34: Registration
CUSTOMER CARE In Ireland if you need assistance…* Phone: 1800 625 174 or 01-8077960 fax: 1800 635 012 website: www.fisherpaykel.com Postal address: Fisher & Paykel Appliances, Unit D2, North Dublin Corporate Park, Swords, Co. Dublin for rest of the world…* Call your Fisher &... - Page 35 EUROPEAN DIRECTIVE 2012/19/EU ON wASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (wEEE) EU This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate handling of this product.
-
Page 36: Www.fisherpaykel.com
www.fisherpaykel.com Copyright © Fisher & Paykel 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your dealer to ensure this booklet correctly describes the product currently available.
