CONTENTS SAFETY AND WARNINGS INSTALL DOOR PANEL INTEGRATED COLUMNS — WINE CABINET Hanging door panel COMPONENTS Adjusting door panel DOOR PANEL AND HANDLE SETS INSTALL TOE KICK MOUNTING PLATE WINE DISPLAY ACCESSORIES Adjusting toe kick grille TOOLS Installing toe kick mounting plate APPLIANCE DIMENSIONS INSTALL TOE KICK AND GRILLES CAVITY DIMENSIONS...
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS WARNING! Electric Shock Hazard BEFORE INSTALLATION Read and follow the safety and warnings The appliance has front and rear rollers for moving the appliance forward and backward. Do not move the appliance sideways to avoid damaging the rollers or the floor outlined in this installation guide before covering/surface.
Leave the protective film on the panels when hanging and remove the film only when the installation is complete. RS6121VR2K1 RS6121VL2K1 Custom If using Custom door panels, ensure they are prepared as per 'Custom door panel dimensions' section.
COMPONENTS Installation kit (Internal box) Supplied with appliance Door panel attachment kit Miscellaneous components Side bracket Bracket slider Side spacer bracket Hinge limiting pin Air toe kick seal For SS door panels: For Custom door panels: Flow divider cap Locking clip 8Gx16 Mush washer screw (30) M5x12 Cross-head screw (30) Anti-tip bracket assembly kit...
Page 7
Supplied with appliance Not supplied and must be purchased separately INTEGRATED COLUMNS INTEGRATED COLUMN WINE CABINET WINE CABINET RS2484VL2K1, RS2484VR2K1, RS2484VL2K1, RS2484VR2K1, RS6121VL2K1, RS6121VR2K1 RS6121VL2K1, RS6121VR2K1 models models SERVICE & WARRANTY SERVICE ET GARANTIE ΣΈΡΒΙΣ ΚΑΙ ΕΓΓΎΗΣΗ SERVIZIO E GARANZIA SERVICE &...
DOOR PANEL AND HANDLE SETS Door panel set Not supplied and must be purchased separately Stainless steel door panel set: Custom door panel set: (Fisher & Paykel) Supplied by customers to match their cabinetry. Custom Door Panel must leave glass pane visible. A full custom panel sheathing over the glass pane does not meet the specifications of this appliance.
WINE DISPLAY ACCESSORIES TOOLS IMPORTANT! Required tools Wine display accessories are not supplied with the appliance. A wine display kit and a label Not supplied kit are sold separately and can be purchased online at fisherpaykel.com. Wine display kit Powered driver Flathead screwdriver Ruler Handle assembly (1)
APPLIANCE DIMENSIONS PRODUCT DIMENSIONS Overall height of product 2134 Overall width of product Overall depth of product (excluding front door panel) Weight (including packaging) 172kg...
CAVITY DIMENSIONS CAVITY DIMENSIONS Overall height of cavity 2134 24” Overall width of cavity Overall depth* (including door panel) if power plug is located in adjacent cabinet Overall depth* (including door panel) if power plug is located behind appliance * Cavity depth assumes door panel thickness of 19mm.
Page 12
CAVITY DIMENSIONS Frameless Cabinetry Framed Cabinetry Aligns appliance flush with the cabinetry Aligns appliance flush with the frame of cabinetry CAVITY DIMENSIONS Minimum required finished return (cavity sides and top) Minimum cabinetry gap clearance from edge of door panels...
DOOR PANEL DIMENSIONS STAINLESS STEEL/CUSTOM DOOR PANEL DOOR PANEL DIMENSIONS (STAINLESS STEEL) Height of door panel 2029 Width of door panel Depth of door panel (excluding door handle) 3/4" (19) DOOR PANEL DIMENSIONS (CUSTOM)* Height of door panel 1978 – 2080 Width of door panel Depth of door panel 16 – 25 DOOR PANEL WEIGHT...
TOE KICK PANEL DIMENSIONS TOE KICK DIMENSIONS Width of toe kick Stainless steel panel/Custom panel Height of toe kick Stainless steel panel Custom panel** 50 – 152 Depth of toe kick (measured from front of door) Stainless steel panel/Custom panel 73 –102 Standard toe kick height is 4" (102mm) with the optional Stainless door panel. For Custom door panel installation, a custom toe kick 2 – 6" (50 – 152mm) can be manufactured and fitted by cabinetmaker.
CUSTOM DOOR PANEL DIMENSIONS Custom door panel dimensions 302mm 203mm Dimensions apply for the preparation and installation of Custom door panels. 51mm For Dwg and Dxf files of the below panel preparation download the folder on thekitchentools.fisherpaykel.com. IMPORTANT! The thickness of the custom door 22mm x Ø2mm panel can vary as long as the screws do not penetrate beyond the full...
DOOR CLEARANCE IMPORTANT! IMPORTANT! Ensure the appliance is stable before opening the door. Ensure the hinge limiting pin is inserted before pushing the appliance into the cabinetry. The pin fits in the boreholes of the top hinge. Insert hinge limiting pin (supplied) to limit door swing to 90°.
ELECTRICAL DIMENSIONS WARNING! Electric shock hazard! Assume all parts live. Disconnect power supply before servicing and installation. ELECTRICAL AND PLUMBING CONNECTIONS Recommended location for connections in adjacent area or unit Alternative location for connections at rear of cavity REAR OF CAVITY Floor Electrical connection must be within this space if located behind the appliance and must not protrude from the back wall.
ELECTRICAL SPECIFICATIONS Power cord (excluding plug) Power cord (excluding plug) MAXIMUM DISTANCE OF POWER CORD AND WATER HOSE ELECTRICAL SPECIFICATIONS Power cord length from left side edge of appliance (excluding plug) 1309 Supply 230 VAC, 50 Hz Power cord length from right side edge of appliance (excluding plug) 1335 Service 10 amp circuit...
BEFORE INSTALLATION Check your appliance IMPORTANT! Top door panel Ensure that your appliance is the Top trim extrusion correct model as per your order. Check that the components and install kits are complete. Keep the detached parts to reinstall later. air flow divider top door panel extrusion top trim...
BEFORE INSTALLATION Check the installation location Check the cabinetry Check the dimensions of the cabinetry: height, width, depth, floor level, finished alcove returns. Check the power supply connection Ensure that there is a separate power socket for each appliance. Avoid sharing the power point with other appliances to prevent accidental switching off of the appliance.
INSTALL ANTI-TIP BRACKET Anti-tip bracket Measure height from floor to alcove return (A). Use this Mark a horizontal line on the back wall Mark screw hole locations, and drill Place the bracket to the backwall. based on measured attachment height. assembly kit measurement to locate the attachment height (B) of Align the undersurface of bracket...
CONNECT TO POWER SUPPLY Move appliance in front of cabinetry close enough to allow access at the back for power connection. Rear view of appliance Connect to the power supply Uncoil the power cord from the clips . (230 VAC, 50 Hz)
ATTACH DEPTH ALIGNMENT GAUGES IMPORTANT! Install fasteners kit The alignment gauges are only temporary and must be removed after installation. Cabinet depth alignment gauge Tools Left Right Cross-head screwdriver Loosen right and left screws at top and Locate alignment gauges to screws at correct orientation. bottom sides of door.
POSITION APPLIANCE INSIDE THE CABINETRY Install fasteners kit Attach barbed plugs IMPORTANT! Check clearance between floor and feet. Rollers must roll freely on the floor. Be careful not to run over the power cord when rolling Barbed plug in the appliance. Barbed plug Before rolling into the cavity, insert barbed plugs into large holes on the top right and left sides of...
ALIGN APPLIANCE INSIDE THE CABINETRY Align depth gauges with cabinetry Tools Cross-head screwdriver Ruler Right Left Mark the step of depth gauge on each side of the door based on the thickness of door panel. adjacent cabinetry adjacent cabinetry Check if the gaps between appliance and cabinetry side walls are Move the appliance to align the marked steps of gauges to be flush with front surface of even on both sides.
ALIGN APPLIANCE INSIDE THE CABINETRY IMPORTANT! Adjusting appliance inside the cabinetry Tools Turn front and rear adjustment screws clockwise to raise height of appliance and counter-clockwise to lower height. One turn of adjustment screw is equal to 0.5mm height adjustment. Use a cross-head screwdriver to turn the screws.
FIX APPLIANCE INSIDE THE CABINETRY IMPORTANT! Install fasteners kit Remove the alignment gauges before fixing the appliance to the cabinetry. Ensure the appliance does not move as you open the door when you tighten the screws. 8Gx16 Countersunk screw (6) Tools Open the door and remove Re-tighten the screws.
INSTALL CARBON FILTER MI pack Housing Push-open latch Carbon filter Remove filter from packaging. Open the cover of filter housing by pushing the latch. Cover Hatch Filter housing Insert carbon filter in hatch. Filter housing Push the filter gently into the hatch until flush, and then close the cover until it locks to the latch. IMPORTANT! Ensure the cover is completely closed to prevent hatch or filter from being damaged.
PREPARE FOR DOOR PANEL INSTALLATION Tools Removing hanging bracket M4 hex key 13mm spanner (1) M8 nut M8 washer adjustment screw Remove the M8 washer and M8 nut from the adjustment screw at the top the door. Loosen the adjustment screw by 3mm. Remove hanging bracket and set aside to use later.
PREPARE FOR DOOR PANEL INSTALLATION Door handle kit IMPORTANT! A stainless steel door panel has pre-drilled screw holes for attaching door handle and brackets. For custom door panels, see 'Custom door panel dimensions' (page 15) for correct screw hole locations of handles and brackets. hanging bracket Remove the protective film around the handle attachment area of the stainless steel panel before M5x25 Hex screw...
ATTACH DOOR PANEL GLASS TRIM IMPORTANT! Attaching long glass trims Installation kit Glass trims are attached to cover the gap between the door panel and the glass panel. hanging bracket long trim long trim Long trim (2) red protective film Peel off a small portion of red protective film from one end Continue attaching the long trim for the length of the Tools...
ATTACH DOOR PANEL GLASS TRIM Attaching short glass trims Installation kit short trim Attach the peeled portion starting from one end of (D). flange perpendicular to top end of long trim Place the short trim along the length of the top of door panel cutout to determine the correct length between long trims.
INSTALL DOOR PANEL Tools Hanging door panel hanging bracket Cross-head screwdriver M4 hex key Align door panel to door at an angle. Align the holes of the hanging bracket over the adjustment screws and lower the door panel into place. 13mm spanner Side brackets Align door panel straight...
INSTALL DOOR PANEL IMPORTANT! Tools Adjusting door panel Check gaps 1/8" (3mm) between door panel/cabinetry using depth gauge. All door panels have full axis adjustment to ensure flushness with adjacent walls. Cross-head screwdriver bracket M4 hex key Lower Raise To adjust door panel further, remove door panel then loosen the fixing screws of hanging bracket and move the bracket sideways to suit.
INSTALL TOE KICK MOUNTING PLATE Toe kick grilles Adjusting toe kick grille Installing toe kick mounting plate Magnet with Top grille double-sided tape Toe kick mounting plate Magnet with double-sided tape Bottom grille Reinstall toe kick mounting plate to plinth using same screws set aside previously. Top bracket NOTE: If toe kick depth is less than 92mm, attach an air toe kick seal to the mounting Tools...
INSTALL TOE KICK AND GRILLES Miscellaneous Installing toe kick Attaching top and bottom grilles components Air toe kick seal Toe kick install kit Reinstall top grille using same screws set aside previously, and reattach cover to bottom hinge pocket. Peel off the adhesive tape backing of the magnets. Toe kick Cutter NOTE: For toe kick heights...
INSTALL CABINET TRIMS Dual install Re-installing top trim Re-installing flow divider Twist to prise open Expose adhesive Exploded with machine screw joiner kit The flow divider blocks the air flow from bypassing in front of the bottom grille. IMPORTANT! hinge side For toe kick height greater than 102mm, shorten the air flow divider.
INSTALL CABINET TRIMS Install parts Installing side trims Four (4) dual-lock strips are pre-installed along each side trim. dual lock strips trim Cabinet side trim assembly door hinge Dual-lock strip Peel off the liners from Position the trim on the throat at an angle. Tools the dual-lock strips.
INSTALL DOOR TRIMS Miscellaneous Installing door trims components Position door panel top extrusion to top of door. Peel off the liners from the dual-lock strips. Press top Press side extrusions to fit into the right and left extrusion down so that dual lock strips engage each other. side gaps between door and door panel.
WINE DISPLAY Installing wine display kit Installing wine label kit Handle assembly Retainer blocks are pre-assembled at the bottom of both ends of the handle. Loosen the screws until the retainer Align handle to the front end of Rotate retainer block to lock Write the name or type Fit label over front edge of rack to position and tighten screw to lock...
OPTIONAL — CHANGE DOOR HINGES IMPORTANT! Tools You have the option to change the door hinge side of your appliance from right hand hinge to left hand hinge or vice versa. A hinge change kit is required for this We recommend to lay the appliance (door closed) onto its back on the pallet installation, and must be purchased separately.
OPTIONAL — CHANGE DOOR HINGES Tools Removing top door hinge Rotate the top hinge (A) outwards and remove the top hinge pocket cover (B) using the flat head screwdriver in the slot of the cover. T2 star-head Unscrew M5x12 pan head screws (C) to remove screwdriver top hinge, and set aside to use later.
OPTIONAL — CHANGE DOOR HINGES Tools Moving the sensor housing T2 star-head screwdriver Flat-head screwdriver Unclip the reed switch Unhook the interceptor board harness Remove the #8x16 screws (2x) from from the housing (A). from sensor housing so harness the sensor housing (C). is loose (B).
OPTIONAL — CHANGE DOOR HINGES Hinge change Top hinge installation assembly Reinstall the hinge top bracket and bracket spacer with M5x12 countersunk screws (A) on the new hinge side at the other side of the appliance. Install the new hinge pocket and alcove top Hinge (right or left) bracket on the new hinge side using two (2x) top pocket (1)
OPTIONAL — CHANGE DOOR HINGES Hinge change Door brackets assembly Remove the top adapter bracket from the top of the door by unscrewing M5x10 screws (4x) (A). Install the new top adapter bracket into the other side of K05 top adaptor the top of the door with M5x10 screws (4x) (B). bracket R/L (1) Remove the door panel locking bracket and washer from the bottom of the door by unscrewing M6x25 screw (1x) (C).
OPTIONAL — CHANGE DOOR HINGES Tools Door installation Activate the hinge spring by turning the star T20 Reinstall the door to the appliance using M6x10 hex screws to the I position (B). screws (4x) into the hinges (A). T2 star-head screwdriver Top hinge Flat-head screwdriver Hex key Bottom hinge...
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER All models Check all parts are installed. Ensure the appliance is level. Ensure the appliance is securely fastened to the cabinetry with the supplied anti-tip bracket and fittings. Ensure the door can open and close freely with no resistance from surrounding cabinetry.
