Processor Options - Lenovo Flex System x222 Compute Node Product Manual

Processor options

The x222 supports the processor options that are listed in the following table. The x222 supports up to
four Intel Xeon E5-2400 processors, one or two in each independent server. All four processors that are
used in an x222 must be identical.
Note: The two servers are independent and cannot be combined to form a single four-socket system.
The table also shows which server models have each processor as standard. If no corresponding where
used model for a particular processor is listed, then this processor is available only through the
configure-to-order (CTO) process.
Table 4. Processor options
Part Feature code*
number
Intel Xeon processors
00D1266 A35X / A370
00D1265 A35W / A36Z
00D1264 A35V / A36Y
00D1263 A35U / A36X
00D1262 A35T / A36W
00D1261 A35S / A36V
00D1260 A35R / A36U
Intel Xeon processors - Low power
00D1269 A360 / A373
00D1271 A362 / A375
00D1268 A35Z / A372
00D1270 A361 / A374
00D1267 A35Y / A371
* The first feature code is for processor 1 and the second feature code is for processor 2.
Flex System x222 Compute Node
Intel Xeon processor description
Intel Xeon E5-2403 4C 1.8GHz 10MB 1066MHz 80W
Intel Xeon E5-2407 4C 2.2GHz 10MB 1066MHz 80W
Intel Xeon E5-2420 6C 1.9GHz 15MB 1333MHz 95W
Intel Xeon E5-2430 6C 2.2GHz 15MB 1333MHz 95W
Intel Xeon E5-2440 6C 2.4GHz 15MB 1333MHz 95W
Intel Xeon E5-2450 8C 2.1GHz 20MB 1600MHz 95W
Intel Xeon E5-2470 8C 2.3GHz 20MB 1600MHz 95W
Intel Xeon E5-2418L 4C 2.0GHz 10MB 1333MHz 50W
Intel Xeon E5-2428L 6C 1.8GHz 15MB 1333MHz 60W
Intel Xeon E5-2430L 6C 2.0GHz 15MB 1333MHz 60W
Intel Xeon E5-2448L 8C 1.8GHz 20MB 1333MHz 70W
Intel Xeon E5-2450L 8C 1.8GHz 20MB 1600MHz 70W
Models
where used
D2x
F2x
G2x
H2x, H6x
J2x
M2x
N2x
A2x
-
B2x
-
C2x
