3
GREEN
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door is closed and the interior light is off.
Connect the GREEN wire to the vehicle's negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
4
BLACK/WHITE
This wire provides a ( - ) 500mA output for 30 seconds when the system is
disarmed capable of driving relays.
Locate the vehicle's dome light or pin switch wire.
Verification: This wire will register positive voltage or ground when the
vehicle's dome light is turned ON.
5
BROWN/BLACK
Locate the vehicle's horn wire.
Verification: This wire will register at positive voltage and register
ground when the horn switch is pressed.
Connect the BROWN/BLACK wire to the vehicle's horn wire. This is a low current
output, 500mA.
6
RED/WHITE
Locate the vehicle's trunk release wire at the trunk release switch.
Verification: This wire will register either positive voltage or ground when
the trunk release is activated.
This is a low current output, 500mA and is configurable in option programming.
6
DOOR TRIGGER INPUT ( - )
ILLUMINATED ENTRY OUTPUT ( - )
HORN OUTPUT ( - )
TRUNK RELEASE OUTPUT ( - )
ca5153 / 5153sst rev A
