- Page 1 PROFESSIONAL SERIES Remote Start with Keyless Entry Installation Guide CA 5150 2010 Audiovox Electronics Corporation. All rights reserved.
-
Page 2: Table Of Contents
Table of Contents Before You Begin ..................3 Wire Connection Guide ................4 8 Pin Main Harness ................... 5 3 Pin Parking Light Harness ..............8 6 Pin Start Harness ................... 8 4 Pin Alternate Harness ................10 2 Pin Door Lock Harness ................ 11 Additional Ports .................. -
Page 3: Before You Begin
BEFORE YOU BEGIN PROFESSIONAL INSTALLATION STRONGLY RECOMMENDED Installation Precautions: Roll down window to avoid locking keys in vehicle during installation Avoid mounting components or routing wires near hot surfaces Avoid mounting components or routing wires near moving parts Tape or loom wires under hood for protection and appearance Use grommets when routing wires through metal surfaces... -
Page 4: Wire Connection Guide
8 Pin Main Harness 3 Pin Parking Light Harness 6 Pin Start Harness 4 Pin Alternate Harness 2010 Audiovox Electronics Corporation. All rights reserved. -
Page 5: Pin Main Harness
2 Pin Door Lock Harness 8 Pin Main Harness VIOLET/BLACK AUX 1 This wire provides a ( - ) 500mA output capable of driving relays. For Control of optional accessories (i.e. Power Window/Sunroof, etc.). To activate refer to the transmitter button configuration chart. Please refer to the selectable options for timing. - Page 6 RED/WHITE TRUNK RELEASE OUTPUT ( - ) Locate the vehicle’s trunk release wire at the trunk release switch. Verification: This wire will register either positive voltage or ground when the trunk release is activated. This is a low current output, 500mA. BLUE/BLACK IGNITION 3 / ACTIVE OUTPUT ( - ) The Active Output/Ignition 3 output wire provides a ground output when the remote...
- Page 7 PURPLE/WHITE TACH INPUT Locate the vehicle’s ignition coil or fuel injector in the engine compartment. Verification: Test using the following procedure: 1. Set voltmeter to AC VOLTS. 2. Attach positive lead of a volt meter to a constant 12-volt source. 3.
-
Page 8: Pin Parking Light Harness
3 Pin Parking Light Harness BLACK GROUND Connect the BLACK wire to a solid chassis ground point using a ring terminal and self tapping screw (not supplied). Scrape away paint from the grounding point to ensure a good connection. The recommended grounding point is a metal surface in the driver’s side kick panel area. - Page 9 BATTERY 12V ( + ) Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch. Verification: This wire will register ( + ) voltage in all positions of the ignition switch. Connect the RED wire to the constant 12 Volt battery wire. NOTE: Remove all fuses until all connections are made.
-
Page 10: Pin Alternate Harness
PINK IGNITION 1 ( + ) Locate the vehicle’s ignition wire at the ignition switch. Verification: This wire registers voltage when the key is turned to the ON (or RUN) position. The voltage does not drop out when the key is turned to the START (or CRANK) position. -
Page 11: Pin Door Lock Harness
BLACK/YELLOW PULSE DURING CRANK ( - ) Locate the vehicle’s second starter (crank) wire at the ignition switch. (if equipped) Verification: This wire registers voltage only in the start (crank) position of the ignition switch. Connect the BLACK/YELLOW wire as shown in the diagram below. Use an SPDT relay (not supplied). - Page 12 Negative Switching Locks All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: These wires will register ground when the Lock and Unlock switches are activated. Connect the GREEN and BLUE wires shown in the diagram below. Negative Locks: GREEN (-) Lock Output Lock...
- Page 13 Reverse Polarity Locks (5-Wire Door locks) All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: These wires will rest at ground and register positive voltage when the Lock and Unlock switches are activated. Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below using (2) SPDT relays (not supplied).
- Page 14 Positive Multiplexed Locks All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: This wire will show variable positive voltage when the switch is activated. Please consult the wire and location chart for specific resistor values for your vehicle.
-
Page 15: Additional Ports
Transponder Interface Activation Factory Alarm Arm / Disarm Manual Arm / Disarm Inputs (factory keyless controls system) Tracking Port This 4 pin port is used for Code Alarm Car Link or Vehicle Tracking accessories. 2010 Audiovox Electronics Corporation. All rights reserved. -
Page 16: Set Up & Programming
Set Up & Programming Transmitter Programming - Feature Bank 1 Turn the ignition ON. Press and hold the valet/override button. Within 10 seconds the system will chirp (3) three times. Press 1 button of each transmitter you wish to program. The system will respond with 1 chirp for each accepted transmitter. -
Page 17: Programming Feature Banks
Feature Bank 1 - 3 Chirps Transmitter Programming Refer to transmitter programming. Feature Bank 3 - 5 Chirps 1 LED Flash 2 LED flash 3 LED Flash 4 LED Flash 5 LED Flash 6 LED Flash Output Control 1 Second Lock, 30 Second Double Pulse 1 Second... -
Page 18: Tach Programming
Tach Programming The unit will not operate unless a tach signal is programmed or the tachless option is turned ON. If an attempt is made to start the vehicle via the remote start without first programming tach, the unit will flash the parking lights 7 times indicating tach has not been learned and stored. -
Page 19: Feature Descriptions
Feature Descriptions Feature Bank 2 - Security 1 - Silent Choice: Controls the normal arm/disarm chirps of the security system. ON - Silent arming/disarming upon first press of lock/unlock, pressing lock/ unlock a second time will activate the arm/disarm chirps respectively. The system will only sound the arm/disarm chirps upon a second press of the lock/unlock buttons. - Page 20 3 - Ignition Controlled Locks: Control of door locks when the ignition is cycled ON or OFF. OFF - Door locks not activated by ignition. Lock and Unlock - Doors lock when ignition is turned on and unlock when ignition is turned off. Lock Only - Doors lock when ignition is turned on only.
- Page 21 4 - Tach Mode: Determines how the system monitors the engine running during remote start. Tach - Hard wired directly to the tach wire of the vehicle to monitor AC voltage. Tachless (Crank Average/Voltage) - Determines crank time by averaging the last 8 times the vehicle was started with the key and then monitors the change in voltage after remote start.
-
Page 22: Transmitter Button Functions
9 - Single / Double Pulse Start: Switches the remote start activation between a single or double press from the transmitter. 10 - IGN 2 Output: Programmable high current output. Ignition 2 - Ignition output during remote start. Accessory - Accessory output during remote start. Start / Crank - Crank output during remote start. -
Page 23: Remote Start Shutdown Diagnostics
Remote Start Shutdown Diagnostics If the remote start shuts down or fails to start, the parking lights will flash one of the patterns below indicating the shutdown input. To manually enter diagnostics and view the last shutdown, turn the ignition ON and press and release the button. -
Page 24: System Layout
2010 Audiovox Electronics Corporation. All rights reserved. - Page 25 2010 Audiovox Electronics Corporation. All rights reserved.
- Page 26 Audiovox Electronics Corporation. Customer Service 1-800-421-3209 WWW.CODE-ALARM.COM FCC COMPLIANCE This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.
