12 - Turbo Timer: Not available on this model.
13 - Transmission Mode: Select the type of remote start activation based on
the vehicle's transmission type.
Automatic - For use with automatic transmission vehicles. Standard remote
start operation.
Manual - For use with manual transmission vehicles. Remote start ready
mode must be set upon exit of vehicle to enable remote start.
Feature Bank 5 - 4 Pin Alternate Output Control
1 - Black/Yellow Output : Controls the BLACK/YELLOW output activation type
and timing.
Pulse During Crank - Output becomes active with the same timing as the
starter output wire, during crank only.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition - Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory - Output becomes active with the same timing as the accessory
output, drops out during crank.
2 - Green/White Output : Controls the GREEN/WHITE output activation type and
timing.
Pulse After Shutdown - 1 second pulse after the remote start has
shutdown.
Ground While Running - Continuous output for the entire remote start
sequence until after the vehicle shuts down.
Ignition - Output becomes active with the same timing as the ignition output
and does not drop out during crank.
Accessory - Output becomes active with the same timing as the accessory
output, drops out during crank.
Pulse During Crank - Output becomes active with the same timing as the
starter output wire, during crank only.
