Summary of Contents for The Singing Machine STVG888W
- Page 1 Instruction Manual STVG888W Please read before using this unit. THE SINGING MACHINE is a registered trademark of The Singing Machine Company, Inc.
-
Page 2: Important Safety Information
Warnings FCC WARNING: This equipment may generate or use radio frequency CAUTION energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the RISK OF ELECTRIC SHOCK instruction manual. The user could lose the authority to operate this DO NOT OPEN equipment if an unauthorized change or modification is made. -
Page 3: Location Of Controls
Location of Controls Front View 1. Adjustable Camera 13. Listed clockwise, from 17. Tweeters top: 2. POWER ON/OFF Button 18. LINE IN Jack PROGRAM 3. Screen 19. Speakers Play/Pause Button 4. BLUETOOTH Button 20. SD Card Slot 5. SD CARD MODE Button Skip/Search Forward 21. - Page 4 Location of Controls Rear View 1. AUDIO OUT Left Jack 3. AUDIO OUT Right Jack 2. VIDEO OUT Jack 4. DC IN Jack...
- Page 5 DVD players or video game consoles, as follows: Connect the Audio/Video cables yellow plug to the yellow VIDEO OUT jack on the STVG888W and the other end to the external unit yellow Video In jack. REAR VIEW OF THE STVG888W...
- Page 6 Connection Insert the small end of the AC adapter into the DC IN jack on the rear of the unit. Insert the other end (with the 2 blades) into a conveniently located AC outlet having 110-240V AC, 50/60Hz. Notes: • Only use the supplied AC adapter. Failure to do so may cause a fire or damage the unit.
- Page 7 Operation Playing a CD (with or without MP3+G files), CD+G or USB Drive Connect the unit as described previously. Press the POWER ON/OFF button to the in position to turn the unit on; the POWER ON/OFF button will light. CD: Press the CD Open/Close button to open the CD door and then insert a CD (with standard or MP3+G files) or a CD+G.
- Page 8 Operation Playing a CD (with or without MP3+G files), CD+G or USB Drive If listening to an MP3+G or CD+G files, view as follows: To view the image and lyrics on the screen, rotate the MONITOR control to the CDG position. To view the image and lyrics on an external TV (if connected), rotate the VIDEO OUT control to the CDG/USB...
- Page 9 Operation Playing a CD (with or without MP3+G files), CD+G or USB Drive Adjust the Key to obtain the best key for the singer on the track. Adjust the key using the KEY – and KEY + buttons. Press the AVC (Auto Voice Control) ON/OFF button to the On position and the vocals on a multiplex recording will be muted as soon as the...
- Page 10 Operation Playing a CD (with or without MP3+G files), CD+G or USB Drive SEARCH: During playback, press and hold the Skip Back /Skip Forward button to move the player backward or forward within a track to locate a specific musical passage. When you release the respective button, normal playback will resume.
- Page 11 Operation Playing a CD (with or without MP3+G files), CD+G or USB Drive PAUSE: During playback, if you wish to pause the disc momentarily, press the Play/Pause button. Press again to resume normal playback. Note: Pausing the unit while playing a CD+G may distort the lyrics on the screen.
- Page 12 BLUETOOTH button until it does. Switch on the Bluetooth function of your Bluetooth compatible device within three feet of the STVG888W. You will see “Singing Machine” appear on your device’s search list. Note: Please always refer to the user manual of your Bluetooth device for detailed instructions.
- Page 13 Operation Using a Bluetooth Device PLAY/PAUSE: Press the BLUETOOTH button to pause the playback. Press again to resume normal playback. Make sure the Bluetooth device has its volume set to mid range, then adjust the volume to a comfortable level using the MASTER VOLUME control.
- Page 14 Operation Using a Bluetooth Device BALANCE: Balance allows you to eliminate the lead singer’s voice by rotating the knob to the left when playing a multiplex recording, or eliminate the music by rotating the knob to the right. Note: When playing a music-only recording, the balance will shift to the right or left speaker.
-
Page 15: Operation
KEYBOARD Ext. Input jack. LINE IN: Connect a music player using a 3.5mm standard audio cable from the external unit’s Audio Output/ Headphone jack to the STVG888W’s LINE IN Ext. Input jack. GUITAR /KEYBOARD Press the POWER ON/OFF button to the in position to turn the unit on;... - Page 16 Operation Using a Guitar, Keyboard or External Music Player Connect microphone(s) as shown on page 5, and slide the ON/OFF switch to the ON position. Adjust the MIC VOLUME control as desired. Increasing this control will increase the volume of the respective microphone.
- Page 17 Operation Recording the Camera and Singing on an SD Card Connect the unit as described previously. Press the POWER ON/OFF button to the in position to turn the unit on; the POWER ON/OFF button will light. Rotate the FUNCTION control to the CAMERA position to select the Camera mode.
- Page 18 Operation Recording the Camera and Singing on an SD Card Press the RECORD button to start recording; a red will appear on the screen and the RECORD button will start blinking. Note: If there is no SD card inserted, will appear. Connect microphone(s) as shown on page 5, and slide the ON/OFF switch to the ON position.
- Page 19 Operation Recording the Camera and Singing on an SD Card To watch the recorded video, press the MODE button and then the SD CARD Right/PLAY-PAUSE -ENTER button to play, press again to pause. Press the SD CARD +/- to choose the video to play.
- Page 20 Machine Download Store. • Remove (eject) the USB flash drive from your computer. Download your selected purchase(s) Turn on the Singing Machine and connect the USB from the Singing Machine Digital Locker flash drive. to your USB flash drive. Insert the USB flash drive as shown on •...
-
Page 21: Care And Maintenance
Care and Maintenance Care for Compact Discs Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. Do not attach adhesive tape, stickers, etc. to the compact disc label. -
Page 22: Troubleshooting Guide
Troubleshooting Guide Should this unit exhibit a problem, check the following before seeking service: No Power • Power is not on; press the POWER ON/OFF button to turn power on. • Make sure the unit is connected to AC power. No Sound –... -
Page 23: Specifications
Specifications AUDIO Output Power (Maximum)...................... 20 0 W (RMS) Output Impedance ..........................6 Ohms CD PLAYER Frequency Response ......................100 Hz-20 KHz Signal to Noise Ratio..........................50 dB Sampling System ....................8 Times Oversampling Disc Diameter ........................4.72" (120 mm) ..........................3.15" (80 mm) Single CD BLUETOOTH Bluetooth Version ........................V3.0 + EDR Working Distance..............Up to 10 meters measured in open space... - Page 24 The Singing Machine Company, Inc. 888W-1501-ENG02 6301 NW 5th Way, Suite 2900, Fort Lauderdale, FL 33309, USA © 2014 PRINTED IN CHINA PRINTED IN CHINA www.singingmachine.com VISIT OUR WEBSITE...
