TM
STVG785BT
INSTRUCTION MANUAL/ MANUAL DE INSTRUCCIONES
/ MODE D'EMPLOI
www.singingmachine.com
The Singing Machine® is a registered trademark of The Singing Machine Co., Inc.
The Singing Machine® es marca registrada de The Singing Machine Co., Inc.
The Singing Machine® est une marque déposée de The Singing Machine Co., Inc.

Advertisement

Table of Contents
loading

Related Manuals for The Singing Machine STVG785BT

Summary of Contents for The Singing Machine STVG785BT

  • Page 1 / MODE D’EMPLOI www.singingmachine.com The Singing Machine® is a registered trademark of The Singing Machine Co., Inc. The Singing Machine® es marca registrada de The Singing Machine Co., Inc. The Singing Machine® est une marque déposée de The Singing Machine Co., Inc.

  • Page 2: Important Safety Information

    Warnings WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE CAUTION THIS UNIT TO RAIN OR MOISTURE. RISK OF ELECTRIC SHOCK FCC WARNING: This equipment may generate or use radio frequency DO NOT OPEN energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT instruction manual.
  • Page 3 Included Please make sure that the following items are included. Main Unit Wired Microphone AC Adapter Manual Audio/Video Cables — E2 —...

  • Page 4: Monitor On/Off

    Location of Controls (Top/Front) 1. ON/STANDBY Button 8. Mic Holders 18. Stop < /PAIR Button 2. Screen 9. MIC VOLUME Control 19. Skip 9 / 5 Button 3. FUNCTION Button 10. ECHO Control 20. Skip : / 6 Button 4. MONITOR ON/OFF 11.

  • Page 5: Location Of Controls (Rear)

    Location of Controls (Rear) 1. AUDIO OUT Left Jack 2. VIDEO OUT Jack 3. AUDIO OUT Right Jack 4. DC IN Jack — E4 —...
  • Page 6 Connection Connecting the Microphone(s) Microphones: Connect a microphone into Mic jack 1 u as well as Mic jack 2 v (when desired). Note: Do not drop or tap the Mic as damage to the Mic or speakers may occur. Do not twirl the microphone cord as it will cause damage to the encased wiring.
  • Page 7 Connection Connecting to AC Power Insert the small end of the AC adapter into the DC IN jack on the rear of the unit. Insert the other end (with the 2 blades) into a conveniently located AC outlet having 120V AC, 60Hz. Note: Make all connections before connecting to AC power.
  • Page 8 Operation Playing a CD Connect the unit as described previously. Press the ON/STANDBY button to turn the unit on. Lift open the CD door and insert a CD (with standard or MP3+G files) or a CD+G by gently pressing it on the center spindle.
  • Page 9 Operation Playing a CD (Continued) Adjust the volume to a comfortable level using the MASTER VOLUME control. Connect microphone(s) and slide the ON/OFF switch on the microphone to the ON position. Adjust the MIC VOLUME control as desired. Increasing this control will increase the volume of both microphones.
  • Page 10 Operation Playing a CD (Continued) AUTO VOICE CONTROL can be activated by pressing the AUTO VOICE CONTROL ON/OFF button. The vocals on a multiplex recording will be muted as soon as the singer begins singing into the microphone. When the singer stops singing, the recorded vocals on the multiplex recording will resume to normal.
  • Page 11 Operation Playing a CD (Continued) PROGRAM: You can program up to 20 tracks for playback in any desired order. While in Stop mode, press the PROGRAM/ REPEAT button; PROG SET 00:XX (xx is the total tracks) will appear in the display. Select the first track using the SKIP 9 / 5 or SKIP : / 6 buttons, then press the PROGRAM/REPEAT button.
  • Page 12 Operation Playing Songs from the USB Connect the unit as described previously. Press the ON/STANDBY button to turn the unit on. Insert a USB flash drive into the USB port on the unit so it faces upward. Make sure to download music from the Karaoke store, see page E20.
  • Page 13 Operation Playing Songs from the USB (Continued) Connect microphone(s) and slide the ON/OFF switch on the microphone to the ON position. Adjust the MIC VOLUME control as desired. Increasing this control will increase the volume of both microphones. Rotate the ECHO control to add an echo effect to your voice.
  • Page 14 Operation Playing Songs from the USB (Continued) SKIP: Advance or go back one file by pressing the SKIP 9 / 5 or SKIP : / 6 buttons. You can also skip ahead 10 files/tracks using the 10+ button. SEARCH: When playing any audio from the USB, press and hold the SKIP 9 / 5 or SKIP : / 6 buttons.
  • Page 15 Operation Playing Songs from the USB (Continued) PROGRAM: You can program up to 20 tracks for playback in any desired order. While in Stop mode, press the PROGRAM/ REPEAT button; PROG SET 00:XX (xx is the total tracks) will appear in the display.
  • Page 16 Operation Using a Bluetooth Device Connect the unit as described previously. Press the ON/STANDBY button to turn the unit on. Repeatedly press the FUNCTION button to select the Bluetooth; “Bluetooth” will flash on the screen. The screen will show your Bluetooth device is ready to connect with a notification sound.
  • Page 17 Operation Using a Bluetooth Device (Continued) To control your Bluetooth device from this unit, press the PLAY/ PAUSE /ENTER button to start playback (music app must be open). Press the PLAY/PAUSE /ENTER button during playback to pause the song. Adjust the volume to a comfortable level using the MASTER VOLUME control on this unit as well as the volume on your Bluetooth...
  • Page 18 Operation Using a Bluetooth Device (Continued) RECORDING YOUR SINGING: Insert an USB drive during playing, then press the RECORD button. Recording will begin and “Recording” will flash at the top left of the screen. When done recording, press the RECORD button again to stop recording.
  • Page 19 Operation Using the LINE IN Jack Connect the unit as described previously. Press the ON/STANDBY button to turn the unit on Connect the external unit to the LINE IN Jack on the front of this unit. Connecting an external unit will allow the audio to be played through your Singing Machine.
  • Page 20 Operation Using the LINE IN Jack (Continued) Adjust the MIC VOLUME control as desired. Increasing this control will increase the volume of both microphones. Rotate the ECHO control to add an echo effect to your voice. Rotate towards MAX to increase the echo effect.
  • Page 21 • Remove (eject) the USB flash drive from your Select and purchase your favorite computer. karaoke music from the Singing Turn on the Singing Machine and connect the USB Machine Download Store. flash drive. Download your selected purchase(s) from the Singing Machine Digital •...

  • Page 22: Troubleshooting Guide

    Troubleshooting Guide Should this unit exhibit a problem, check the following before seeking service: No Power • Power is not on; press the ON/STANDBY button to turn power on. • Confirm that the AC adapter is connected securely to the back of the unit. •...

  • Page 23: Specifications

    The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks and logos by The Singing Machine Company, Inc. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 24 The Singing Machine Company, Inc. 4060 E Jurupa Street, Unit B Ontario, CA 91761-1413 USA The Responsible Party Company Name : The Singing Machine Company, Inc. Address : 6301 NW 5th Way, Suite 2900, Fort Lauderdale, PRINTED IN CHINA FL33309, USA...
