Memorex MVR4041 Owner's Manual

Video cassette recorder
Hide thumbs Also See for MVR4041:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
OWNER'S MANUAL
MANUAL DE INSTRUCCIONES
VIDEO CASSETTE RECORDER
VIDEOGRABADOR DE CASSETTE
MVR4041
If you purchase a universal remote control from your local retailer, please contact the
remote manufacturer for the required programming code.
Si usted a comprado un control de remoto universal, por favor comunicace con el fabricante
para el codico de programaccion requerido.
When shipped from the factory, the TV/CATV menu option is set to the "CATV" (Cable
Television) mode.
If not using CATV (Cable TV), set this menu option to the "TV" mode.
A la salida de fábrica, la opción de menú TV/CATV está en el modo "CATV" (televisión por cable).
Si no se va a utilizar el CATV (TV cable), cambie la opción de este menú al modo TV.
Before operating the unit, please read this manual thoroughly.
Antes de utilizar su aparato favor de leer las siguientes instrucciones.
4E40401A E COV-07
ATTENTION
ATENCION
TV/CATV MODE SELECTION
SELECCION DE MODO DE TV/CATV
1
4/1/01, 5:03 PM
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVR4041 and is the answer not in the manual?

Questions and answers

Related Manuals for Memorex MVR4041

Summary of Contents for Memorex MVR4041

  • Page 1 MANUAL DE INSTRUCCIONES VIDEO CASSETTE RECORDER VIDEOGRABADOR DE CASSETTE MVR4041 If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code. Si usted a comprado un control de remoto universal, por favor comunicace con el fabricante para el codico de programaccion requerido.

  • Page 2: Important Safeguards

    ENGLISH CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
  • Page 3 IMPORTANT SAFEGUARDS 9. VENTILATION Slots and openings in the cabinet back or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface.
  • Page 4 IMPORTANT SAFEGUARDS 19. DAMAGE REQUIRING SERVICE Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power-supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen into the unit.

  • Page 5: Precautions

    This is called moisture condensation. MOISTURE WILL CONDENSE ON THE UNIT IN THE FOLLOWING CASES; • When you move this VCR from a cold to a warm place. • After heating a cold room or under extremely humid conditions.

  • Page 6: Battery Cautions

    Remote Sensor, the remote operation may be unstable. • When there is an obstacle between the VCR and the remote control, the remote control may not operate. 4E40401A E COV-07...

  • Page 7: Table Of Contents

    On-Screen 3 Language Display - This TV can display the on screen language in English, Spanish or French. Slow Motion - This VCR provides slow motion which of- fers steady, noise free playback at 1/10 normal speed. Frame by Frame Advance - Press the SLOW button during still playback to advance the tape one frame at a time.

  • Page 8: Location Of Controls

    13. MENU button - Press to display the on-screen menu function. 14. TIMER REC button - Used to set the VCR to start recording at a preset time. 15. SLOW button - Press to play back a tape in slow motion or to advance the tape one frame at a time during still playback.

  • Page 9: Fluorescent Display

    31. UHF/VHF OUT (TV) Jack - Use to output UHF/VHF or CATV signal to a TV. 32. 3/4 Channel Selector Switch - Selects the channel through which the VCR outputs its signal to a TV. 33. AC Power Cord - Connect to a 120V 60Hz outlet. POWER indicator...

  • Page 10: Basic Connections

    The VCR must be connected "between" the antenna and the TV. First, disconnect the antenna from the TV and connect it to the VCR. Then connect the VCR to the TV. Below are 3 common methods of connecting an antenna system to a VCR.

  • Page 11: Vcr To Tv Connection

    After you have connected the antenna to the VCR, you must connect the VCR to the TV. Below are 3 common methods of connecting your VCR to a TV. Find the type of TV you are using and follow the connection diagram.

  • Page 12: Catv (Cable Tv) Connections

    Many cable companies offer services permitting reception of extra channels including pay or subscription channels. This VCR has an extended tuning range and can be tuned to most cable channels without using a cable company supplied converter box, except for those channels which are intentionally scrambled. If you subscribe to a special channel which is scrambled, you must have a descrambler box for proper reception.
  • Page 13 IMPORTANT: Make sure the TV/CATV menu option is set to the "CATV" mode. This VCR cannot receive scrambled programs since it does not contain a descrambler. In order to receive scrambled programs, your existing descrambler must be used. Descrambler boxes are available from cable companies. Consult your local cable company for more information concerning connection to their descrambler equipment.

  • Page 14: Audio/Video Connections

    AUDIO/VIDEO CONNECTIONS If your TV has AUDIO IN and VIDEO IN jacks, you can connect your VCR to them to receive a higher quality picture and sound. If you have a stereo, you can connect a stereo amplifier to enjoy powerful sound.

  • Page 15: Setting The Video Channel

    For a push-button TV tuner If CH 3 or 4 corresponding to the video channel cannot be tuned on your TV, proceed as follows: set the VCR 3/ 4 channel selector and the TV to CH 3 or 4, play back a prerecorded tape and tune the TV to receive a sharp color picture from the video cassette recorder.

  • Page 16: Setting The Channels

    VCR’s memory. In addition to normal VHF and UHF channels, this VCR can receive up to 113 Cable TV channels. To use this VCR with an antenna, set the TV/CATV menu option to the TV mode. When shipped from the factory, this menu option is in the CATV mode.

  • Page 17: Loading And Unloading

    Turn ON the TV and set to the video channel 3 or 4. When a TV is connected with an audio/video cable, turn the TV and this VCR on and select the video input mode on the TV. Load a prerecorded tape...

  • Page 18: Special Playback

    • Press the TV/VCR selector button to select the VCR mode. When a TV is connected with an audio/video cable, turn the TV and this VCR on, and select the video input mode on the TV. MENU Press the MENU button.

  • Page 19: To Stop Recording

    4 seconds. NOTE: Since the VCR has its own TV tuner, it is not actually necessary to have the TV turned on in order to make a recording. Turning on the TV merely allows confirmation of the proper channel settings on your VCR.

  • Page 20: One-Touch Timer Recording (Otr)

    • Check that the clock and date are correct (see page 15). When a TV is connected with an audio/video cable, turn the TV and this VCR on and select the video input mode on the TV. Press the MENU button.

  • Page 21: On-Screen Function Display

    TRACKING/ SET + or – button. When finished, press the ENTER button. NOTES: • The VCR cannot be used while the T.REC indicator is lit. • After a power failure or disconnection of the...

  • Page 22: Stereo Recording And Playback

    • Press the TV/VCR selector button to select the VCR mode. When a TV is connected with an audio/video cable, turn the TV and this VCR on, and select the video input mode on the TV. CLOCK SET Press the MENU button.

  • Page 23: Duplicating A Video Tape

    If the heads require cleaning, use a equivalent high quality chemical non-abrasive (wet) head cleaning tape or have them cleaned professionally. If playing a head cleaning tape in the VCR once does not improve the picture, play it several times before requesting service.

  • Page 24: Before Requesting Service

    VCR does not appear on The TV is not set to the video the screen. channel 3 or 4. The TV/VCR selector is set at TV mode (The TV/VCR indicator is not lit). INPUT SELECT is set to the LINE mode.

  • Page 25: Specifications

    Operate within 15 feet (5 meters) reduce the light in the room. Clear the path of the beam. Replace the batteries. Insert correctly. Set to TV, or turn off the VCR power button. Hi-Fi Frequency Response: 100Hz to 10,000Hz at SP mode Hi-Fi Dynamic Range: More than 90dB F.
  • Page 26 MEMO 4E40401A E P20-25 4/1/01, 5:04 PM...
  • Page 27 4E40401A E P20-25 4/1/01, 5:04 PM...
  • Page 28 4E40401A E P20-25 4/1/01, 5:04 PM...
  • Page 29 4E40401A E P20-25 4/1/01, 5:04 PM...
