OWNER'S MANUAL
MANUAL DE INSTRUCCIONES
VIDEO CASSETTE RECORDER
VIDEOGRABADOR DE CASSETTE
MVR4051/MVR4052
If you purchase a universal remote control from your local retailer, please contact the
remote manufacturer for the required programming code.
Si usted a comprado un control remoto universal, por favor comunicace con el fabricante
para el codico de programaccion requerido.
When shipped from the factory, the TV/CATV menu option is set to the "CATV" (Cable
Television) mode.
If not using CATV (Cable TV), set this menu option to the "TV" mode.
Al salir la unidad de fábrica, la opción de menú de TV/CATV se ajusta al modo de
"CATV" (Televisión por cable).
Si no utiliza CATV, ajuste esta opción de menú al modo de "TV".
Before operating the unit, please read this manual thoroughly.
Antes de usar la unidad, lea detenidadmente este manual de instrucciones.
4F21301B E COV-07
ATTENTION
ATENCION
TV/CATV MODE SELECTION
SELECCION DE MODO DE TV/CATV
1
6/26/02, 3:56 PM
1
Advertisement
Table of Contents
Related Manuals for Memorex MVR4051/MVR4052
Summary of Contents for Memorex MVR4051/MVR4052
- Page 1 MANUAL DE INSTRUCCIONES VIDEO CASSETTE RECORDER VIDEOGRABADOR DE CASSETTE MVR4051/MVR4052 If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the required programming code. Si usted a comprado un control remoto universal, por favor comunicace con el fabricante para el codico de programaccion requerido.
-
Page 2: Important Safeguards
NOTE: Please keep all packaging material for at least 90 days in case you need to return this product to your place of purchase or Memorex. WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 3 IMPORTANT SAFEGUARDS 9. VENTILATION Slots and openings in the cabinet back or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface.
- Page 4 IMPORTANT SAFEGUARDS 19. DAMAGE REQUIRING SERVICE Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power-supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen into the unit.
-
Page 5: Precautions
This is called moisture condensation. MOISTURE WILL CONDENSE ON THE UNIT IN THE FOLLOWING CASES; • When you move this VCR from a cold to a warm place. • After heating a cold room or under extremely humid conditions. -
Page 6: Features
Remote Sensor, the remote operation may be unstable. • When there is an obstacle between the VCR and the remote control, the remote control may not operate. 4F21301B E COV-07... -
Page 7: Table Of Contents
Stereo/SAP Reception - This VCR is designed to receive stereo and separate audio program (SAP) broadcasts where available. Front Audio/Video In Jacks - A VCR or other video device may be hooked up for dubbing. 4F21301B E COV-07 TABLE OF CONTENTS CAUTIONS IMPORTANT SAFEGUARDS ... -
Page 8: Location Of Controls
5. F. FWD button - In the STOP mode, this button rapidly winds the tape forward. In the PLAY mode, this button activates Forward Search. 6. POWER button - Turns the VCR power on and off. 7. REC/OTR button - Press once to start normal recording. Additional presses activate One-touch Timer Recording. - Page 9 18. TRACKING SET + / – buttons - During playback, they are used to adjust tracking manually. Used to set or adjust in the menu mode. 19. TIMER REC button - Used to set the VCR to start recording at a preset time (Timer program must be set).
-
Page 10: Basic Connections
The VCR must be connected "between" the antenna and the TV. First, disconnect the antenna from the TV and connect it to the VCR. Then connect the VCR to the TV. Below are 3 common methods of connecting an antenna system to a VCR. -
Page 11: Vcr To Tv Connection
After you have connected the antenna to the VCR, you must connect the VCR to the TV. Below are 3 common methods of connecting your VCR to a TV. Find the type of TV you are using and follow the connection diagram. -
Page 12: Catv (Cable Tv) Connections
Many cable companies offer services permitting reception of extra channels including pay or subscription channels. This VCR has an extended tuning range and can be tuned to most cable channels without using a cable company supplied converter box, except for those channels which are intentionally scrambled. If you subscribe to a special channel which is scrambled, you must have a descrambler box for proper reception. - Page 13 IMPORTANT: Make sure the TV/CATV menu option is set to the "CATV" mode. This VCR cannot receive scrambled programs since it does not contain a descrambler. In order to receive scrambled programs, your existing descrambler must be used. Descrambler boxes are available from cable companies. Consult your local cable company for more information concerning connection to their descrambler equipment.
-
Page 14: Audio/Video Connections
AUDIO/VIDEO CONNECTIONS If your TV has AUDIO IN and VIDEO IN jacks, you can connect your VCR to them to receive a higher quality picture and sound. If you have a stereo, you can connect a stereo amplifier to enjoy powerful sound. -
Page 15: Setting The Video Channel
For a push-button TV tuner If CH 3 or 4 corresponding to the video channel cannot be tuned on your TV, proceed as follows: set the VCR 3/ 4 channel selector and the TV to CH 3 or 4, play back a prerecorded tape and tune the TV to receive a sharp color picture from the video cassette recorder. -
Page 16: Setting The Channels
VCR’s memory. In addition to normal VHF and UHF channels, this VCR can receive up to 113 Cable TV channels. To use this VCR with an antenna, set the TV/CATV menu option to the TV mode. When shipped from the factory, this menu option is in the CATV mode. -
Page 17: Loading And Unloading
Turn ON the TV and set to the video channel 3 or 4. When a TV is connected with an audio/video cable, turn the TV and this VCR on and select the video input mode on the TV. Load a prerecorded tape... -
Page 18: Special Playback
• Press the TV/VCR selector button to select the VCR mode. When a TV is connected with an audio/video cable, turn the TV and this VCR on, and select the video input mode on the TV. Press the MENU button. -
Page 19: To Stop Recording
4 seconds and the REC indicator will light. NOTE: Since the VCR has its own TV tuner, it is not actually necessary to have the TV turned on in order to make a recording. Turning on the TV merely allows confirmation of the proper channel settings on your VCR. -
Page 20: One-Touch Timer Recording (Otr)
• Check that the clock and date are correct (see page 15). When a TV is connected with an audio/video cable, turn the TV and this VCR on and select the video input mode on the TV. Press the MENU button. -
Page 21: On-Screen Function Display
TRACKING SET + or - button. When finished, press the ENTER button. NOTES: • The VCR cannot be used while the T.REC indicator is lit. • After a power failure or disconnection of the... -
Page 22: Stereo Recording And Playback
• Press the TV/VCR selector button to select the VCR mode. When a TV is connected with an audio/video cable, turn the TV and this VCR on, and select the video input mode on the TV. CLOCK SET TIMER REC SET Press the MENU button. -
Page 23: Duplicating A Video Tape
If the heads require cleaning, use a equivalent high quality chemical non-abrasive (wet) head cleaning tape or have them cleaned professionally. If playing a head cleaning tape in the VCR once does not improve the picture, play it several times before requesting service. -
Page 24: Before Requesting Service
VCR does not appear on The TV is not set to the video the screen. channel 3 or 4. The TV/VCR selector is set at TV mode (The TV/VCR indicator is not lit). INPUT SELECT is set to the LINE mode. -
Page 25: Specifications
WWW.MEMCORPINC.COM OR CONTACT CUSTOMER SERVICE AT 1-800-919-3647. PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INT'L AT 1-800-321-6993. - Page 26 MEMO 4F21301A E P20-25 6/26/02, 3:53 PM...
- Page 27 MEMO 4F21301A E P20-25 6/26/02, 3:53 PM...
- Page 28 Memcorp,Inc. Weston,FL 33331 Printed in Thailand Impreso en Tailandia Visit our website at www.memcorpinc.com 4F21301B U Visite nuestro portal de internet en www.memcorpinc.com 02/04 4F21301B S P20-BACK 6/26/02, 3:57 PM...
