- Page 1 CMP-2DTO3DCONV 2D to 3D video converter ANLEITUNG MANUAL MODE D’EMPLOI GEBRUIKSAANWIJZING MANUALE MANUAL DE USO HASZNÁLATI ÚTMUTATÓ KÄYTTÖOHJE NÁVOD K POUŽITÍ BRUKSANVISNING...
- Page 2 Introduction Welcome to the 3D Converter Box User Manual. To get the best results from the 3D Converter Box, it is recommended that you first read this manual. Components and Contents New 3D Converter Box Components 3D Converter Box Power Supply 3D Glasses Remote Control HDMI Cable...
- Page 3 Other Components that are Required A Regular HD TV with at least one HDMI input An existing HDMI Cable Blu-ray Player, Set-Top-Box, Media player etc. Converter Box – Front Panel...
- Page 4 Converter Box – Back Panel Converter Box – Remote Control...
-
Page 5: Installation
Installation Connection Diagram – The View After Installation HDMI IN Set Top Box Converter Box HDMI OUT HDMI HDMI Blu Ray Player HDMI HDMI OUT... -
Page 6: Converter Box
The 3D Converter Box supports Hot-Plugging of Devices. Devices can be connected in any order and at any time. Follow the procedure below carefully to step through and view each stage of the installation. Please refer to the Appendix for more advanced connectivity options which handle multichannel audio and other compressed audio formats. - Page 7 Step 2: Connect the 3D Converter Box Output to your TV Connect one end of the first HDMI Cable to the “HDMI Out” port of the 3D Converter Box. Connect the other end of this first HDMI Cable to one of the HDMI input channels on your HDMI IN Converter Box HDMI...
- Page 8 On your TV note that a 3D Startup Message screen will appear immediately. Note that you can skip the 3D Startup Message screen by pressing “OK” on your remote control. The screen will then show a message saying that ‘No Video Input Source Found’. Your TV is now connected.
- Page 9 HDMI IN Set Top Box Converter Box HDMI OUT HDMI HDMI HDMI Note the LEDs show: Note the On-Screen Message remains as follows: Switch on this Input Video Device. The video from the source device will now appear on the screen.
- Page 10 Your 3D Converter Box is now connected and installed correctly and ready for action! Step 4: Determining the Current Status of the Converter Box At any time when using the 3D Converter Box press “OK” on the remote control to display the information screen.
- Page 11 3D Converter Box Operation All the functions of the 3D Converter Box can be controlled using either the remote control or the 2 buttons on the 3D Converter Box (the Mode Button and the Source Button). 2DTV 2D Inputs 3D Inputs Using the 3D Converter Box with 3D Content (3D Auto Detect) 3D Source Devices include: 3D Blu-Ray Players, TV Set-Top-Box, Gaming Consoles 4.1.1...
- Page 12 4. Pressing the “Mode Button” on the Remote Control or on the 3D Converter Box moves through the available modes when playing 3D content. 5. There are 2 modes as shown below 6. Press the “OK” button to see the 3D Mode and Status 7.
- Page 13 Put on your 3D Glasses and enjoy the experience! 8. 3D-2D Mode : Press the “Mode Button” again. This changes the mode to “3D to 2D Mode”. This converts the 3D movie to 2D and you can watch it on your TV as normal 2D. You do not need to wear your glasses for this.
- Page 14 The LEDs on the front of the 3D Converter Box will show different patterns depending on the 3D Format that is currently being used. Using the 3D Converter Box with other 3D Content e.g. Media Players Other 3D Source Devices include: Media Players, some Set-Top-Boxes and some Gaming Consoles In this case the 3D Content may not be fully HDMI 1.4a compliant so the 3D Converter Box will be unable to detect the 3D format.
- Page 15 Bypass (Default) 3D (TAB)->Anaglyph-3D Conversion 2D->Anaglyph-3D MODE Conversion 3D (SBS)->Anaglyph-3D Conversion 4. For example if you know the input content is in Side-by-Side 3D Format and the Converter Box does not Auto-Detect this mode, you can put the converter box into this mode using the mode button.
- Page 16 Bypass (Default) 3D (TAB)->Anaglyph-3D Conversion 2D->Anaglyph-3D MODE Conversion 3D (SBS)->Anaglyph-3D Conversion When the “Mode Button” is pressed the following Menu will appear with the mode options. 4. When you connect first, the default mode is “Bypass Mode”. You can watch TV as usual (without the glasses) and the LEDs will look like this: 5.
- Page 17 Note that other modes are available via the Mode Button as described in the other sections. If other modes are selected with 2D content then the colors and video on the screen may look strange. Changing the Input Video Source Input Video Source devices can be connected to either HDMI 1 input port or HDMI 2 Input Port or you can connect 2 devices to the ports simultaneously.
- Page 18 Using the Menu System to Navigate The 3D Converter Box has a menu system built-in to help the user navigate through the functions. This menu system can be operated using the supplied remote control or by using the “Mode Button” and “Source Button” on the 3D Converter Box. Main Menu Screen Call up the Main Menu by either pressing the “MENU”...
- Page 19 Mode Menu Screen Use the 3D Mode Menu to change the 3D mode depending on the type of source content. Select a highlighted option by pressing “OK” on the remote control. 3D Adjust Menu Screen Use the 3D Adjust Menu Screen to change the settings related to the 3D effect. Select “Restore Defaults”...
- Page 20 Note that the 3D Adjust settings are only available in 3D Modes. If the user tries to select this option during any other mode the user will get an error message as shown below. 3D Brightness Menu Screen Use the 3D Brightness Menu Screen to change the amount of 3D brightness in the scene.
- Page 21 3D Strength Menu Screen Use the 3D Strength Menu Screen to change the strength of the 3D effect. Min3D, the total amount of 3D in the video is quite small Normal3D, a balanced amount of 3D appears in the scene Max3D, a large of amount of 3D, some objects look very near others look far away 3D Offset Menu Screen Use the 3D Offset Menu Screen to change the amount of 3D parallax in the scene.
- Page 22 Language Menu Screen Select a language for all OSD messages on the Language Menu Screen. Select “Back” or press “LEFT ARROW” to return to the Main Menu.
- Page 23 Version Screen Show the Hardware and Software and Product Number of this 3D Converter Box. May be required if support is needed for your equipment. Upgrading the 3D Converter Box Contact your 3D Converter Box distributor or local retail shop to find out where to download or access the latest USB Upgrade file for the 3D Converter Box.
-
Page 24: Troubleshooting
Troubleshooting The following table shows some problems you may encounter when installing and using the 3D Converter Box. If these suggestions do not fix your problems then please contact your 3D Converter Box sales agent or retailer. Problem Meaning How to Fix I get an “Unsupported Video The Input Video Device (your Go into the settings menu of... - Page 25 Appendix - Compatible Devices The 3D Converter Box is compatible with most major 2D and 3D input video devices. Compatible 2D Devices Compatible 3D Devices Blu-ray Players 3D Blu-ray Players TV Set-Top-Boxes 3D TV Set-Top-Boxes Gaming Consoles 3D Games on Gaming Consoles 2D Tablets Appendix - Notes on Resolutions The 3D Converter Box supports the resolutions listed in the table below.
- Page 26 Appendix - Notes on 3D Terminology Meaning Positive Parallax The objects look like they are behind your screen or look like they are pushed into your screen Negative Parallax The objects look like they are in front of your screen or look like they are jumping out of your screen Appendix - Advanced Installation and Connectivity Options For received content that uses multichannel audio or compressed audio formats or non-PCM...
- Page 27 Safety precautions: Some people may have problems watching 3D content which can cause headache or other effects. To reduce risk of electric shock, this product should ONLY be opened by an authorized technician when service is required. Disconnect the product from mains and other equipment if a problem should occur.
- Page 28 / merke: KÖNIG ELECTRONIC Model: / Modell: / Modèle: / Modello: / Modelo: / Típusa: / Malli: / Μοντέλο: CMP-2DTO3DCONV Description: / Beschreibung: / Description: / Omschrijving: / Descrizione: / Descripción: / Megnevezése: / Kuvaus: / Beskrivning: / Popis: / Descriere: / Περιγραφή: / Beskrivelse:...
