Attention
Adjust the following three settings when using the unit for the first time.
Adjust the black-balance setting when using the unit for the first time. (Refer to page 50)
The unit is delivered from the factory with the color TV standard not yet specified. To revise the settings for frame
frequency according to the TV standard, refer to the procedures described on page 13.
Set VF TYPE on the <SYSTEM MODE> screen on the SYSTEM SETTING page depending on your viewfinder. The
factory setting is set to the HD viewfinder.
The unit is a solid CCD camera recorder integrating 2/3-inch 2.2-megapixel components that support interlaced/progressive
drive (reading all pixels) and record/playback that supports the compression format for AVC-Intra100, AVC-Intra50 and
DVCPRO HD, DVCPRO50, DVCPRO and DV.
The unit supports the HD and SD methods shown in the following table. The unit is also equipped with CAC (chromatic
aberration correction function for the magnification ratio chromatic aberration of lenses), Scan Reverse (corrects images when
Anamo lenses or lenses for film applications are used), and the film-like gamma function.
For recording, the compression and recording methods are selectable among AVC-Intrra100, AVC-Intra50, DVCPRO HD,
DVCPRO50, DVCPRO and DV. Since minimal image deterioration occurs when recording with AVC-Intra 100 compression in
particular, high image quality can be retained.
_ Supported formats
Mode
SYSTEM MODE
1080-59.94i
HD
1080-50i
480-59.94i
SD
576-50i
General
Shooting/Recording method
AVC-Intra100
59.94i
29.97P (Native)
AVC-Intra50
23.98P (Native)
59.94i
29.97P Over 59.94i
DVCPRO HD
23.98P Over 59.94i (2-3 Pull down)
23.98PA Over 59.94i (2-3-3-2 Pull down)
AVC-Intra100
50i
25P (Native)
AVC-Intra50
50i
DVCPRO HD
25P over 50i
59.94i
DVCPRO50
29.97P Over 59.94i
DVCPRO
23.98P Over 59.94i (2-3 Pull down)
DV
23.98PA Over 59.94i (2-3-3-2 Pull down)
DVCPRO50
50i
DVCPRO
25P Over 50i
DV
7
General ：
